Allen Bradley 20DC170A0ENNANANE PowerFlex 700S AC Drive
Allen Bradley 20DC170A0ENNANANE PowerFlex 700S AC Drive
0.0
Points
Brand:Allen Bradley PLC Item No.:20DC170A0ENNANANE Product Origin:USA Product Dimensions:850.0 x 403.9 x 275.5 mm Product Weight:71.44 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 20DC170A0ENNANANE belongs to the PowerFlex 700S family of industrial AC drives. The PowerFlex 700S series was developed for applications requiring advanced drive control and coordination with industrial automation systems.
Compared with a basic variable-speed drive, the PowerFlex 700S is intended for applications where motor behavior must be carefully controlled and coordinated with machine operation. This makes it particularly relevant to production machinery, process equipment, and automated material-handling systems.
The 20DC170A0ENNANANE can be considered when replacing or maintaining an existing PowerFlex 700S installation. For a successful replacement, technicians should compare the complete model number and application requirements rather than selecting a drive based only on physical appearance or nominal power rating.
Proper installation, grounding, motor cabling, parameter configuration, and commissioning procedures are important for achieving dependable operation. The drive should always be matched to the motor and electrical system according to the requirements of the specific application.
Technical Specifications
Specification
Details
Brand
Allen Bradley
Model
20DC170A0ENNANANE
Product Family
PowerFlex 700S
Product Type
AC Drive
Drive Series
PowerFlex 700S
Application
Industrial AC motor control
Control Function
Variable-speed motor control
Dimensions
850.0 × 403.9 × 275.5 mm
Weight
71.44 kg / 157.50 lb
The 850.0 × 403.9 × 275.5 mm dimensions should be considered when planning cabinet installation, replacement work, ventilation, cable routing, and service access. The 71.44 kg unit weight should also be taken into account when designing mounting arrangements and handling the drive during installation or maintenance.
Recommended Related Models
For PowerFlex 700S applications and related Allen Bradley drive systems, the following models may be considered depending on the required drive rating and system configuration:
Model
Product Type
20DC085A0ENNANANE
PowerFlex 700S AC Drive
20DC125A0ENNANANE
PowerFlex 700S AC Drive
20DC170A0ENNANANE
PowerFlex 700S AC Drive
20DC180A0ENNANANE
PowerFlex 700S AC Drive
These models should not be treated as direct drop-in replacements solely on the basis of the model family. Electrical ratings, motor requirements, enclosure configuration, control options, and application parameters should be verified before substitution.
Popular Related Models
For broader PowerFlex drive maintenance and automation projects, commonly encountered related Allen Bradley models include:
Model
Product Type
20BE125A0ANNAND0
PowerFlex 700 AC Drive
20BR125A3ANNANC0
PowerFlex 700 AC Drive
20BR156A0ANNANC0
PowerFlex 700 AC Drive
20BR180A0ANNANC1
PowerFlex 700 AC Drive
20BT144A0ANNAND0
PowerFlex 700 AC Drive
20BW052A0ANNANC0
PowerFlex 700 AC Drive
20BW098A0ANNANC0
PowerFlex 700 AC Drive
20BW142A0ANNANC0
PowerFlex 700 AC Drive
The Allen Bradley 20DC170A0ENNANANE is a substantial PowerFlex 700S drive intended for industrial applications where controlled motor performance and integration with automation equipment are important. For replacement or modernization projects, confirming the complete catalog number and application requirements is the best way to ensure compatibility.
