Brand:Allen Bradley PLC Item No.:MPL-A1530U-EJ74AA Product Origin:USA Product Dimensions:Frame Size: 63 mm Product Weight:1.6 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley MPL-A1530U-EJ74AA belongs to the MP-Series MPL family of low-inertia brushless servo motors. It is designed for high-performance motion systems where compact dimensions and dynamic motor response are important.
The model uses a 63 mm frame with a 76.2 mm magnet stack and has a 7000 RPM speed rating. Its single-turn high-resolution encoder supports closed-loop feedback, while the keyed shaft extension provides a conventional mechanical connection for compatible machine components.
The 24 V DC brake is integrated into this configuration, making the motor suitable for applications where controlled holding of the axis is required. The right-angle SpeedTEC DIN connector also provides greater flexibility when installing the motor in space-constrained equipment.
For replacement projects, the complete catalog number should be checked carefully. Similar-looking MPL motors may differ in voltage, feedback, shaft, connector, brake, or other configuration details, so frame size alone should not be used to determine interchangeability.
Technical Specifications
Specification
Details
Brand
Allen Bradley
Model
MPL-A1530U-EJ74AA
Product Family
MP-Series MPL
Product Type
AC Rotary Servo Motor
Motor Design
Low-Inertia Brushless Servo Motor
Rated Voltage
230 V AC
Frame Size
63 mm
Magnet Stack Length
76.2 mm
Speed Rating
7000 RPM
Feedback
Single-Turn High-Resolution Encoder
Shaft
Keyed Shaft Extension
Connector
SpeedTEC DIN, Right Angle
Brake
24 V DC Brake
Mounting
IEC Metric, Free Mounting Holes
Weight
1.60 kg / 3.53 lb
The 63 mm frame and 76.2 mm magnet stack provide a compact configuration for industrial motion applications. The 1.60 kg weight should be considered when calculating the total moving mass and dynamic characteristics of the machine axis.
