Brand:Allen Bradley PLC Item No.:MPL-A1530U-VJ72AA Product Origin:USA Product Dimensions:Frame Size: 63 mm Product Weight:1.6 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley MPL-A1530U-VJ72AA is part of the MP-Series MPL family of low-inertia servo motors. Its 63 mm frame and 76.2 mm magnet stack provide a compact form factor, while the 7000 RPM capability supports high-speed motion applications.
One of the most important characteristics of this model is its multi-turn high-resolution absolute feedback. Compared with incremental feedback configurations, an absolute multi-turn encoder provides the motion-control system with detailed position information over multiple rotations, making it valuable for applications where precise position tracking is important.
The motor uses a keyed shaft extension and IEC metric mounting configuration for mechanical integration into compatible machinery. Its right-angle SpeedTEC DIN connector can be rotated 180 degrees, providing additional flexibility when arranging motor cables.
The MPL-A1530U-VJ72AA is an active MP-Series model and can be considered for new or existing Allen Bradley motion-control applications where its electrical, feedback, mechanical, and connector characteristics match the system requirements.
Technical Specifications
Specification
MPL-A1530U-VJ72AA
Brand
Allen Bradley
Product Family
MP-Series MPL
Product Type
Rotary Servo Motor
Model
MPL-A1530U-VJ72AA
Armature Voltage
230 V
AC Voltage Class
240 V AC
Motor Type
Low-Inertia Brushless Servo Motor
Frame Size
63 mm
MP-Series Frame
Frame 15
Magnet Stack Length
76.2 mm
Stack Designation
30
Rated Speed
7000 RPM
Feedback
Multi-Turn High-Resolution Absolute Encoder
Shaft Type
Keyed Shaft Extension
Brake
No Brake
Connector
SpeedTEC DIN Connector
Connector Position
Right Angle
Connector Rotation
180° Rotatable
Mounting Standard
IEC Metric
Mounting Holes
Free Mounting Holes, Type FF
Approx. Dimensions
190 × 60 × 100 mm
Weight
1.60 kg / 3.53 lb
Lifecycle
Active
The 1.60 kg construction provides a compact servo solution for machine builders and maintenance teams working with space-sensitive motion assemblies.
Recommended Related Models
Model
Product Type
Relationship
MPL-A1530U-VJ74AA
Servo Motor
Similar multi-turn feedback configuration with 24 V DC brake
MPL-A1530U-EJ72AA
Servo Motor
Similar 1530U configuration with single-turn high-resolution feedback
MPL-A1530U-EJ74AA
Servo Motor
Similar 1530U configuration with single-turn feedback and brake
MPL-A1530U-HJ72AA
Servo Motor
Related 1530U configuration with incremental feedback and no brake
MPL-A1530U-HJ74AA
Servo Motor
Related 1530U configuration with incremental feedback and brake
Popular Related Models
MPL-A1520U-VJ72AA — MP-Series MPL 240 V AC Rotary Servo Motor
MPL-A1520U-VJ74AA — MP-Series MPL 240 V AC Rotary Servo Motor
MPL-A1530U-EJ72AA — MP-Series MPL 240 V AC Rotary Servo Motor
MPL-A1530U-EJ74AA — MP-Series MPL 240 V AC Rotary Servo Motor
MPL-A1530U-VJ74AA — MP-Series MPL 240 V AC Rotary Servo Motor
MPL-B1530U-VJ72AA — MP-Series MPL 480 V AC Rotary Servo Motor
When replacing or specifying the MPL-A1530U-VJ72AA, particular attention should be given to the multi-turn absolute encoder, 63 mm frame, 76.2 mm magnet stack, 7000 RPM speed rating, no-brake configuration, keyed shaft, and SpeedTEC DIN connector to ensure complete compatibility with the associated motion-control system.
Industrial Motion Control Applications
The MPL-A1530U-VJ72AA can be integrated into industrial automation equipment where precise rotary movement and high-speed positioning are required.
Typical applications include:
Packaging and filling machinery
Automated assembly equipment
Pick-and-place systems
Material handling machines
Conveyor positioning systems
Printing and converting machinery
Labeling and dispensing equipment
Machine-tool auxiliary axes
Automated inspection equipment
Electronics manufacturing systems
High-speed indexing mechanisms
General-purpose industrial motion systems
Its multi-turn absolute feedback is particularly useful in applications where the control system needs reliable position information across multiple motor revolutions.
Key Performance Advantages
Low-Inertia Brushless Design
The MPL-A1530U-VJ72AA uses a low-inertia brushless servo construction that supports rapid changes in speed and direction. This makes it appropriate for machinery with frequent acceleration and deceleration cycles.
7000 RPM High-Speed Operation
The motor is designed for speeds up to 7000 RPM, providing the high rotational performance needed for fast automated processes and positioning operations.
Multi-Turn High-Resolution Absolute Feedback
The VJ72AA configuration incorporates a multi-turn high-resolution absolute encoder. This provides detailed motor position feedback and allows the motion-control system to track position across multiple revolutions.
Compact 63 mm Frame
The 63 mm frame helps integrate the servo motor into equipment with limited installation space while retaining the performance expected from an industrial motion motor.
Keyed Shaft Extension
The keyed shaft provides a secure mechanical interface for compatible couplings, gears, pulleys, and other transmission components.
Flexible Connector Orientation
The SpeedTEC DIN connector uses a right-angle configuration and can be rotated through 180 degrees, helping machine builders manage motor cabling in compact installations.
No-Brake Configuration
The MPL-A1530U-VJ72AA is supplied without an integrated holding brake. This configuration is suitable for applications where a motor brake is not required.
Technical FAQs
1. What type of motor is the MPL-A1530U-VJ72AA?
It is an Allen Bradley MP-Series MPL low-inertia brushless rotary servo motor designed for closed-loop industrial motion applications.
2. What is the frame size of this servo motor?
The MPL-A1530U-VJ72AA uses a 63 mm frame, corresponding to MP-Series frame size 15.
3. What is the magnet stack length?
The motor has a 76.2 mm magnet stack length, corresponding to the MP-Series stack length 30 designation.
4. What is the maximum speed of the MPL-A1530U-VJ72AA?
The motor has a rated speed capability of 7000 RPM.
5. What type of encoder does this model use?
It uses a multi-turn high-resolution absolute encoder for position feedback. This feedback configuration is different from the incremental encoder used by some other MPL motor variants.
6. Does the MPL-A1530U-VJ72AA have an integrated brake?
No. The VJ72AA configuration is a no-brake servo motor. Applications requiring a holding brake should use a compatible brake-equipped motor configuration.
7. What shaft configuration does the motor have?
The motor uses a keyed shaft extension. The keyway allows compatible mechanical drive components to be securely coupled to the motor.
8. What connector is used on this servo motor?
It uses a SpeedTEC DIN connector with a right-angle configuration and 180-degree rotational adjustment for flexible cable routing.
9. What voltage is associated with the MPL-A1530U-VJ72AA?
The motor belongs to the MP-Series 240 V AC family and has a 230 V armature voltage specification.
10. What should be checked when selecting a replacement motor?
The replacement should be matched for voltage, frame and stack size, feedback technology, brake configuration, shaft design, connector arrangement, mounting configuration, and compatibility with the existing servo drive and motion controller.
