Ingersoll Rand 47602381001 47576547001 6-Month 4,000-Hour Standard Maintenance Service Kit
Ingersoll Rand 47602381001 47576547001 6-Month 4,000-Hour Standard Maintenance Service Kit
0.0
Points
Brand:Ingersoll Rand Item No.:47602381001 47576547001 Product Origin:USA Product Dimensions:108 × 7.2 × 7.2 mm Product Weight:0.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 47602381001 47576547001 configuration is an intermediate preventive maintenance solution for compatible RM220i fixed-speed compressors. It is designed for the 6-month or 4,000-hour standard service interval and incorporates the 47576547001 oil separator element as a key component of the maintenance package.
The separator element has an important function within a rotary screw compressor. During compression, oil is introduced into the air/oil mixture for lubrication and cooling, after which the separator removes most of that oil from the compressed-air stream and supports its recovery back into the compressor circuit. Maintaining the separator in suitable condition is therefore important for controlling oil carryover and preserving efficient operation.
At the 4,000-hour service point, replacing the specified separator provides maintenance personnel with an opportunity to refresh a critical component before reaching the longer annual service interval. For standard-duty RM220i installations, the 47602381001 47576547001 configuration supports a structured approach to maintaining separation performance and overall compressor reliability.
Technical Specifications
Specification
Details
Brand
Ingersoll Rand
Complete Reference
47602381001 47576547001
Primary Service Kit
47602381001
Service Type
Standard preventive maintenance
Service Interval
6 months / 4,000 hours
Compressor Platform
RM220i
Compressor Configuration
Fixed-speed
Duty Configuration
Standard-duty
Included Component
47576547001
Component Type
Oil separator / separator tank element
Separator Dimensions
Approximately 378 mm diameter × 506 mm height
Application
Industrial compressed-air systems
Installation
Qualified compressor maintenance personnel
Complete Configuration Dimensions
Not separately specified
Complete Configuration Weight
Not separately specified
Compatibility Verification
Compressor model, production configuration, and serial number
Recommended Companion Models
Model
Product Name
Typical Role
47602379001
3-Month / 2,000-Hour Standard Maintenance Service Kit
Earlier scheduled service stage for compatible RM220i units
47602383001
1-Year / 8,000-Hour Standard Maintenance Service Kit
Major annual maintenance package for standard-duty RM220i systems
47602382001
6-Month / 4,000-Hour High-Dust Maintenance Service Kit
Equivalent intermediate service for high-dust operating conditions
88089743
Breather Filter
Supports crankcase or oil-system ventilation filtration on applicable configurations
Frequently Selected Alternatives
Model
Product Name
Typical Selection
47602382001
6-Month / 4,000-Hour High-Dust Maintenance Service Kit
Selected for compatible RM220i units operating in high-dust environments
47602379001
3-Month / 2,000-Hour Standard Maintenance Service Kit
Used for the preceding routine service interval
47602383001
1-Year / 8,000-Hour Standard Maintenance Service Kit
Selected for the major annual service interval
47576547001
Oil Separator / Separator Tank Element
Component-level replacement when separator service is required
Where It Excels in Industrial Use
• RM220i Intermediate Maintenance — Designed for compatible Ingersoll Rand RM220i fixed-speed compressors at the 6-month or 4,000-hour scheduled service interval.
• Oil Separation System Service — Incorporates the 47576547001 separator element to support efficient oil and compressed-air separation during routine maintenance.
• Continuous-Duty Industrial Operation — Well suited to production facilities where compressor availability, stable operating conditions, and predictable servicing are important.
• Scheduled Separator Replacement — Provides a practical maintenance point for replacing the separator element before extended operation can compromise separation performance.
• Standard-Duty Applications — Intended for applicable RM220i installations operating under standard environmental conditions rather than specialized high-dust service requirements.
Key Strengths at a Glance
• 6-Month / 4,000-Hour Service Coverage — Built around the intermediate maintenance interval for compatible RM220i fixed-speed compressor systems.
• 47576547001 Separator Element — Includes the specified oil separator element used in the applicable maintenance configuration.
• RM220i Compatibility — Designed around the service requirements of compatible RM220i equipment manufactured after the applicable production cutoff.
• Oil Carryover Control — Supports the compressor's air/oil separation process and helps maintain appropriate oil recovery during operation.
• Standard-Duty Configuration — Provides the normal maintenance specification for applicable operating environments.
• Planned Reliability Support — Helps maintenance personnel address separator condition before deterioration develops into a larger operating concern.
Technical FAQs
1. What is the purpose of the 47602381001 47576547001 configuration?
This configuration supports the 6-month or 4,000-hour standard preventive maintenance service of compatible Ingersoll Rand RM220i fixed-speed compressors and includes the 47576547001 separator element.
2. What function does 47576547001 perform?
The 47576547001 separator element separates entrained compressor oil from compressed air within the air/oil separation system, allowing recovered oil to return to the lubrication circuit.
3. Why is the separator element important to compressor performance?
An effective separator helps control oil carryover into the compressed-air stream while supporting oil recovery and stable operation of the compressor's lubrication system.
4. Is 47576547001 specific to the RM220i platform?
The part is associated with compatible Ingersoll Rand RM220i configurations, but final selection should always be confirmed against the compressor model, production generation, and serial number.
5. Can separator condition affect oil consumption?
Yes, a deteriorated, damaged, or incorrectly installed separator can contribute to increased oil carryover and abnormal oil consumption.
6. What should technicians verify before installing 47576547001?
Technicians should confirm the separator part number, isolate and depressurize the compressor, inspect the separator vessel and sealing surfaces, and verify that all related connections are clean and undamaged.
7. Can an incorrect separator element affect pressure drop?
Yes, an unsuitable or incorrectly installed separator can alter flow resistance within the air/oil separation system and may contribute to abnormal pressure behavior or reduced system efficiency.
8. Should the separator be replaced during the 4,000-hour service?
Where the maintenance specification calls for 47576547001 at the 4,000-hour interval, scheduled replacement should be performed as part of the service rather than relying solely on visual inspection.
9. What should be checked after installing the separator?
The technician should inspect for leakage, verify correct assembly and sealing, monitor operating pressure and temperature, and observe oil carryover and compressor alarms after returning the machine to service.
10. How should the 47602381001 47576547001 configuration be selected?
Selection should be based on the RM220i fixed-speed configuration, production or serial-number applicability, operating environment, accumulated hours, and the service parts specified for the individual compressor.
