Ingersoll Rand 47602382001 47621424001 6-Month 4,000-Hour High-Dust Maintenance Service Kit

Where It Excels in Industrial Use

• Built for compatible Ingersoll Rand RM220i fixed-speed rotary screw compressors operating under high-dust conditions where intake filtration requires particular attention.

• Supports the scheduled 6-month / 4,000-hour maintenance interval, helping maintenance teams keep routine service aligned with the compressor operating schedule.

• Incorporates 47621424001 as the coolant/oil filter element, supporting effective lubricant filtration and helping maintain clean oil circulation through the compressor system.

• Well suited to manufacturing facilities, fabrication areas, processing plants, workshops, and other industrial locations where airborne particulate can accelerate filter loading.

• Provides a practical service-kit configuration for technicians who need the correct high-dust maintenance consumables available together for a planned service event.

Key Strengths at a Glance

• High-Dust Service Configuration: Developed around the maintenance requirements of RM220i compressors exposed to higher particulate levels.

• 4,000-Hour Maintenance Coverage: Corresponds to the 6-month / 4,000-hour service cycle for applicable machines.

• Dual Filter Supply: Includes two 47621424001 coolant/oil filter elements for the specified maintenance configuration.

• Lubrication System Support: Helps maintain effective filtration of compressor lubricant and supports dependable oil-system operation.

• Simplified Parts Management: Groups key service consumables into a single maintenance reference, reducing the need to source each item independently.

Technical FAQs

1. Which compressor platform is compatible with 47602382001?

The 47602382001 service kit is intended for compatible Ingersoll Rand RM220i fixed-speed rotary screw compressors using the applicable high-dust maintenance configuration.

2. What is the purpose of 47621424001 in this service kit?

47621424001 is a coolant/oil filter element used to remove contaminants from the compressor lubricant circuit and support proper oil-system operation.

3. How many 47621424001 filter elements are included?

The specified 47602382001 configuration includes two 47621424001 filter elements.

4. What maintenance interval does 47602382001 represent?

The kit corresponds to the 6-month / 4,000-hour maintenance service interval for applicable RM220i fixed-speed compressors.

5. Why is the high-dust version different from the standard RM220i service configuration?

The high-dust configuration is intended for operating environments with greater airborne particulate exposure, where intake filtration can experience higher loading than under standard industrial conditions.

6. What should be checked before replacing the oil/coolant filters?

The technician should confirm the compressor service configuration, isolate and depressurize the machine according to the applicable service procedure, and inspect the filter mounting area and sealing surfaces before installing the replacement elements.

7. Does replacing 47621424001 address the compressor air intake filter?

No. 47621424001 addresses the coolant/oil filtration function. The air intake filter is a separate component and should be serviced according to the applicable RM220i maintenance configuration and operating environment.

8. Can 47602382001 be substituted directly for the standard-duty 4,000-hour kit?

The high-dust kit should be selected when the compressor's operating conditions call for the high-dust maintenance configuration. Standard-duty and high-dust kits should be matched to the machine's specified service requirements rather than substituted solely by service interval.

9. What system symptoms may indicate deteriorated oil filtration performance?

Unusual pressure behavior, lubricant contamination, abnormal operating temperatures, or maintenance indications can justify inspection of the oil filtration system, although these symptoms should be evaluated together with operating data rather than attributed to the filter alone.

10. Why is coordinated maintenance important for a screw compressor?

The intake, lubrication, filtration, separation, and cooling systems operate as an integrated package, so servicing the prescribed components together helps maintain stable compressor performance and reduces the likelihood of one neglected maintenance item affecting the wider system.
