Ingersoll Rand 47602383001 47576547001 1-Year 8,000-Hour Standard Maintenance Service Kit

Where It Excels in Industrial Use

• Designed for compatible Ingersoll Rand RM220i fixed-speed rotary screw compressors approaching the scheduled 1-year / 8,000-hour preventive maintenance interval.

• Features 47576547001, an oil separator element designed to support effective separation of entrained oil from compressed air within the separator system.

• Well suited to continuous-duty manufacturing, process plants, workshops, and other industrial compressed-air installations where stable oil separation is important to downstream air quality and compressor reliability.

• Supports planned annual maintenance by addressing a key component of the compressor's oil-management system alongside the other scheduled filtration and service items.

• Provides a practical choice for maintenance teams seeking to keep separator performance aligned with the compressor's prescribed long-interval service schedule.

Key Strengths at a Glance

• 8,000-Hour Service Focus: Intended for the annual maintenance cycle of applicable RM220i fixed-speed compressors.

• Oil Separation Support: Incorporates 47576547001 to help maintain effective oil separation within the compressor system.

• Standard-Duty Configuration: Suited to normal industrial operating environments where the standard RM220i service configuration is specified.

• Extended-Interval Maintenance: Helps address an important oil-management component during scheduled annual servicing.

• Integrated Service Compatibility: Designed to work with the other filtration and maintenance components specified for the 47602383001 configuration.

Technical FAQs

1. Which compressor platform is associated with 47602383001?

The 47602383001 service configuration is associated with compatible Ingersoll Rand RM220i fixed-speed rotary screw compressors using the standard-duty annual maintenance schedule.

2. What is the function of 47576547001?

47576547001 is an oil separator or separator tank element that helps separate oil from compressed air before the air leaves the separator system.

3. Why is the oil separator important to compressor operation?

Effective oil separation helps control lubricant carryover in the compressed-air stream while allowing separated oil to remain within the compressor's lubrication circuit.

4. What maintenance interval does 47602383001 represent?

The configuration is associated with the 1-year / 8,000-hour scheduled maintenance interval for applicable RM220i fixed-speed compressors.

5. What are the approximate dimensions of 47576547001?

The oil separator element is approximately 378 mm in diameter and 506 mm in height.

6. What should be checked before installing the replacement separator element?

Technicians should verify the part reference, inspect the separator housing and sealing surfaces, remove contamination from the mounting area, and follow the compressor-specific isolation and depressurization procedure.

7. Can an oil separator be replaced without inspecting the separator system?

A separator replacement should normally be accompanied by an inspection of the housing, seals, connections, and associated oil-return components so that installation problems or system restrictions are not overlooked.

8. What operating symptoms can indicate an oil-separation problem?

Increased oil carryover, abnormal separator differential pressure, excessive lubricant consumption, or changes in compressed-air quality can indicate that the oil-separation system requires inspection.

9. What other components are associated with the 47602383001 annual service?

The annual standard configuration includes the applicable air filter elements, two 47621424001 coolant/oil filter elements, the 47576547001 oil separator element, and the 88089743 breather filter.

10. Is 47576547001 intended specifically for high-dust service?

47576547001 is the oil separator element used in the specified annual standard-service configuration; high-dust operating conditions primarily affect the appropriate intake air-filter configuration rather than changing the basic separator function.
