Brand:Allen Bradley PLC Item No.:MPL-B330F-M-X223 Product Origin:USA Product Dimensions:Frame Size: 63 mm Product Weight:5.44 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley MPL-B330F-M-X223 is part of the MP-Series replacement motor family developed for MP-Series electric cylinders. Rockwell Automation documentation identifies this motor as the replacement motor for MPAR-B3xxxE-x2x electric-cylinder configurations, with a 400 V class, 63 mm frame, 10 mm/rev pitch, and no brake.
Its application-specific design is important because the motor is not simply selected according to electrical characteristics. The motor's mechanical relationship with the electric cylinder and its ball-screw pitch must also be maintained to ensure the resulting linear motion remains correct.
The multi-turn high-resolution feedback system provides the position information required by the motion-control system, while the low-inertia brushless construction supports responsive actuator movement.
For maintenance teams working with legacy MP-Series electric-cylinder equipment, the MPL-B330F-M-X223 can serve as a direct replacement component when the existing actuator configuration matches the motor's specified characteristics.
Technical Specifications
Specification
MPL-B330F-M-X223
Brand
Allen Bradley
Product Family
MP-Series
Product Type
Electric Cylinder Replacement Motor
Model
MPL-B330F-M-X223
Voltage Class
400 V
Motor Type
Low-Inertia Brushless Servo Motor
Frame Size
63 mm
Pitch
10 mm/rev
Feedback
Multi-Turn High-Resolution Encoder
Brake
None
Application
MP-Series Electric Cylinder Replacement
Compatible Electric Cylinder Family
MPAR-B3xxxE-x2x
Approx. Dimensions
230 × 90 × 130 mm
Weight
5.44 kg / 11.99 lb
Mounting Application
Electric Cylinder Replacement
The motor's 5.44 kg weight reflects its larger electric-cylinder replacement configuration compared with smaller MPL rotary servo motors.
Recommended Related Models
Model
Product Type
Relationship
MPL-B330F-M-X224
Electric Cylinder Replacement Motor
400 V version with 24 V DC brake
MPL-A330F-M-X211
Electric Cylinder Replacement Motor
200 V class, 63 mm frame, 10 mm/rev, no brake
MPL-A330F-M-X212
Electric Cylinder Replacement Motor
200 V class, 63 mm frame, 10 mm/rev, 24 V brake
MPL-B420F-M-X225
Electric Cylinder Replacement Motor
400 V class, 63 mm frame, 20 mm/rev, no brake
MPL-B420F-M-X226
Electric Cylinder Replacement Motor
400 V class, 63 mm frame, 20 mm/rev, 24 V brake
Popular Related Models
MPL-B330F-M-X224 — MP-Series Electric Cylinder Replacement Motor
MPL-B420F-M-X225 — MP-Series Electric Cylinder Replacement Motor
MPL-B420F-M-X226 — MP-Series Electric Cylinder Replacement Motor
MPL-A330F-M-X211 — MP-Series Electric Cylinder Replacement Motor
MPL-A330F-M-X212 — MP-Series Electric Cylinder Replacement Motor
MPL-A420F-M-X213 — MP-Series Electric Cylinder Replacement Motor
MPL-A420F-M-X214 — MP-Series Electric Cylinder Replacement Motor
When replacing the MPL-B330F-M-X223, the most important compatibility points are the 400 V class, 63 mm frame, 10 mm/rev pitch, multi-turn high-resolution feedback, and no-brake configuration. These parameters should match the existing electric-cylinder assembly before installation and commissioning.
Industrial Linear Motion Applications
The MPL-B330F-M-X223 is primarily intended for MP-Series electric cylinder replacement applications. It can be used where an existing electric-cylinder assembly requires a compatible replacement motor while retaining the original mechanical actuator arrangement.
Typical applications include:
Electric cylinder systems
Automated linear positioning equipment
Industrial material handling
Automated assembly machinery
Packaging equipment
Pick-and-place mechanisms
Pressing and clamping systems
Linear indexing equipment
Machine automation
Production-line positioning systems
Motion-controlled actuator systems
Replacement and maintenance of MP-Series electric cylinders
Its 10 mm/rev pitch configuration makes it particularly relevant to compatible MPAR-B3xxxE electric-cylinder assemblies.
Key Performance Advantages
Dedicated Electric-Cylinder Replacement Design
The MPL-B330F-M-X223 is designed specifically as a replacement motor for compatible MP-Series electric cylinders. This makes it a practical maintenance component for existing linear motion systems.
400 V Voltage Class
The motor belongs to the 400 V class MP-Series family, making it suitable for compatible higher-voltage industrial motion systems.
Low-Inertia Brushless Construction
The low-inertia motor design supports responsive acceleration and deceleration, which is important for controlled linear positioning and repetitive actuator movement.
Multi-Turn High-Resolution Feedback
The integrated multi-turn high-resolution encoder provides detailed position feedback to the motion-control system. This allows the associated actuator to maintain accurate position information across multiple motor revolutions.
63 mm Frame Size
The 63 mm frame provides a compact motor package while maintaining compatibility with the corresponding MP-Series electric-cylinder configuration.
10 mm/rev Pitch Compatibility
The motor is specified for the 10 mm/rev pitch configuration associated with compatible MPAR-B3xxxE electric cylinders. This mechanical relationship is important when selecting a replacement.
No Integrated Brake
The MPL-B330F-M-X223 is the no-brake version. Applications requiring a 24 V DC brake should use the corresponding brake-equipped replacement motor.
Technical FAQs
1. What is the MPL-B330F-M-X223?
It is an Allen Bradley MP-Series electric cylinder replacement motor designed for compatible MPAR-Series linear actuator systems.
2. What frame size does the motor use?
The MPL-B330F-M-X223 uses a 63 mm frame size.
3. What voltage class does this motor belong to?
It belongs to the 400 V voltage class used by the MP-Series electric-cylinder replacement motor family.
4. What type of feedback does the MPL-B330F-M-X223 use?
The motor uses a multi-turn high-resolution encoder for position feedback.
5. Does the MPL-B330F-M-X223 include a brake?
No. This model is the no-brake configuration. The corresponding brake-equipped replacement is MPL-B330F-M-X224.
6. What electric-cylinder pitch is associated with this motor?
The MPL-B330F-M-X223 is associated with a 10 mm/rev pitch configuration.
7. Which electric cylinders is this replacement motor designed for?
It is intended for compatible MPAR-B3xxxE-x2x electric-cylinder configurations.
8. What is the difference between MPL-B330F-M-X223 and MPL-B330F-M-X224?
The primary configuration difference is the brake. The X223 is the no-brake version, while the X224 is equipped with a 24 V DC brake.
9. Is this motor intended to be used as a standalone rotary servo motor?
Its primary purpose is replacement within a compatible MP-Series electric-cylinder assembly. Mechanical compatibility with the actuator, ball screw, mounting arrangement, feedback system, and motion controller should be verified before using it in another application.
10. What should be checked before replacing an MPL-B330F-M-X223?
Verify the voltage class, 63 mm frame, 10 mm/rev pitch configuration, feedback type, brake requirement, mechanical mounting, and compatibility with the existing MPAR electric cylinder and servo-control system.
