Brand:Allen Bradley PLC Item No.:20F11ND8P0JA0NNNNN Product Origin:USA Product Dimensions:424.2 x 134.5 x 212 mm Product Weight:7.8 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen-Bradley 20F11ND8P0JA0NNNNN PowerFlex 753 AC Drive is an 8 A industrial variable-frequency drive intended for applications where precise motor speed and torque control are required. As part of the PowerFlex 750-Series platform, it combines a modular drive architecture with flexible control and integration options.
The 20F11ND8P0JA0NNNNN is configured for 480 VAC three-phase operation and uses a Frame 2 enclosure format. Its integrated I/O, dynamic braking transistor, and filtered configuration make it suitable for a broad range of machine and process applications.
The drive is normally installed within a suitable control cabinet. When designing the installation, engineers should consider power distribution, motor cable routing, grounding, electromagnetic compatibility, ventilation, ambient temperature, and maintenance access.
For PLC-controlled equipment, the PowerFlex 753 platform can serve as the motor-control layer while exchanging commands, status information, feedback, and diagnostic data with the supervisory automation system.
Technical Specifications
Specification
Details
Brand
Allen-Bradley
Manufacturer
Rockwell Automation
Model
20F11ND8P0JA0NNNNN
Product Family
PowerFlex 753
Product Type
AC Drive / Variable Frequency Drive
Bulletin
20F
Input Voltage Class
480 VAC
Input Phase
Three Phase
Output Current
8 A
Frame Size
Frame 2
Cooling Method
Forced Air
Enclosure Type
IP20/IP00, NEMA/UL Open Type
EMC Configuration
Filtered
CM Jumper
Installed
Dynamic Braking
Internal DB Transistor
Embedded I/O
Yes
HIM Configuration
No HIM
Dimensions
424.2 × 134.5 × 212 mm
Weight
7.80 kg (17.20 lb)
The supplied physical dimensions are 424.2 × 134.5 × 212 mm, while the product weight is 7.80 kg (17.20 lb). Additional cabinet space should be provided around the drive for power and control wiring, cooling airflow, inspection, and maintenance.
Recommended Related Models
Model
Product Type
Typical Application
20F11ND3P0JA0NNNNN
PowerFlex 753 AC Drive
Lower-current motor control
20F11ND5P0JA0NNNNN
PowerFlex 753 AC Drive
5 A industrial drive applications
20F11ND8P0JA0NNNNN
PowerFlex 753 AC Drive
8 A motor control
20F11ND011P0JA0NNNNN
PowerFlex 753 AC Drive
Higher-current applications
20F11ND015P0JA0NNNNN
PowerFlex 753 AC Drive
Higher-power motor applications
Popular Related Models
Model
Product Family
Product Role
20F11ND5P0JA0NNNNN
PowerFlex 753
Industrial AC drive
20F11ND8P0JA0NNNNN
PowerFlex 753
8 A AC drive
20F11ND011P0JA0NNNNN
PowerFlex 753
Higher-capacity AC drive
20F11ND015P0JA0NNNNN
PowerFlex 753
Higher-power drive
20G11ND5P0JA0NNNNN
PowerFlex 755
Advanced industrial drive
20G11ND8P0JA0NNNNN
PowerFlex 755
Higher-performance drive applications
The Allen-Bradley 20F11ND8P0JA0NNNNN PowerFlex 753 AC Drive provides a practical combination of 8 A motor-control capability, 480 VAC three-phase operation, embedded I/O, dynamic braking support, and the flexible architecture of the PowerFlex 753 platform. It is a suitable choice for industrial OEM machinery, process equipment, conveyors, pumps, fans, and other automated systems requiring dependable AC motor control.
Applications
The Allen-Bradley 20F11ND8P0JA0NNNNN is a PowerFlex 753 AC Drive designed for industrial variable-speed motor control. With an 8 A output rating and 480 VAC three-phase input class, it is well suited to machinery and process applications that require reliable motor speed regulation, controlled acceleration and deceleration, and integration with a broader automation system.
Typical applications include:
Conveyor and material handling systems
Pumps and pumping skids
Industrial fans and blowers
Packaging and processing machinery
Machine tools
Production and assembly equipment
HVAC and industrial ventilation systems
Automated manufacturing lines
Process-control equipment
General-purpose three-phase motor applications
The compact Frame 2 format makes the drive suitable for control cabinets where efficient use of panel space is important.
Drive Benefits and Key Features
8 A output capability
The 20F11ND8P0JA0NNNNN provides an 8 A output rating and is designed for applications requiring dependable variable-frequency motor control in an industrial environment.
480 VAC three-phase operation
Its 480 VAC class input makes the drive suitable for common North American and international industrial power systems.
PowerFlex 753 architecture
The PowerFlex 753 platform provides a modular approach to industrial drive control, allowing users to configure communication, feedback, I/O, safety, and other functions according to system requirements.
Integrated I/O
Embedded I/O can simplify machine-level control wiring and reduce the need for additional interface equipment.
Dynamic braking transistor
The integrated dynamic braking transistor supports applications where controlled deceleration or braking is required. The appropriate external braking resistor must be selected according to the application.
EMC filtering
This catalog configuration includes the filtered drive configuration, which can help address electromagnetic compatibility requirements when installed according to the applicable system design.
Forced-air cooling
The drive uses forced-air cooling to manage heat during operation. Correct cabinet ventilation and installation clearances are important for maintaining reliable performance.
Industrial cabinet installation
The IP20/IP00, NEMA/UL Open Type construction is intended for installation inside an appropriate electrical enclosure.
Technical FAQs
1. What is the Allen-Bradley 20F11ND8P0JA0NNNNN?
It is a PowerFlex 753 AC drive designed for variable-speed control of three-phase industrial motors.
2. What is the rated output current?
The 20F11ND8P0JA0NNNNN has an 8 A output current rating.
3. What input voltage does this PowerFlex 753 use?
This model belongs to the 480 VAC class of PowerFlex 753 drives and is designed for three-phase industrial power.
4. What motor applications are suitable for this drive?
It can be used for conveyors, pumps, fans, packaging equipment, process machinery, machine tools, and other applications requiring variable-frequency motor control.
5. Does the 20F11ND8P0JA0NNNNN have embedded I/O?
Yes. The PowerFlex 753 architecture provides embedded I/O for integration with machine and process control systems.
6. Does this model support dynamic braking?
Yes. This configuration incorporates an internal dynamic braking transistor. An appropriately rated external braking resistor may be required depending on the motor load and deceleration requirements.
7. What type of cooling does the drive use?
The 20F11ND8P0JA0NNNNN uses forced-air cooling. Adequate airflow around the drive is essential for thermal management.
8. Can the drive communicate with a PLC or DCS?
Yes. The PowerFlex 753 family supports industrial automation communication through appropriate communication options and system configurations.
9. Is a HIM included with this catalog configuration?
The P0 option indicates the drive is configured without a standard mounted HIM. A compatible interface can be used when local drive operation or commissioning requires it.
10. What should be checked before commissioning this drive?
Verify the incoming voltage, motor nameplate data, motor wiring, grounding, overload settings, acceleration/deceleration parameters, braking requirements, control wiring, and communication configuration before placing the motor into service.
