Allen Bradley 20F11NE017AA0NNNNN PowerFlex 753 AC Drive
Allen Bradley 20F11NE017AA0NNNNN PowerFlex 753 AC Drive
0.0
Points
Brand:Allen Bradley PLC Item No.:20F11NE017AA0NNNNN Product Origin:USA Product Dimensions:454 x 190 x 212 mm Product Weight:11.8 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen-Bradley 20F11NE017AA0NNNNN PowerFlex 753 AC Drive is an industrial variable-frequency drive designed for applications requiring controlled operation of three-phase AC motors. Its 17 A output configuration makes it suitable for motor loads that require greater current capacity than smaller PowerFlex 753 models.
The PowerFlex 753 family uses a modular architecture intended for integration into larger automation systems. Communication, feedback, safety, and other functions can be incorporated according to the requirements of the machine or process.
The 20F11NE017AA0NNNNN is well suited to centralized control cabinets. During installation, engineers should consider incoming power, motor cable routing, grounding, heat dissipation, electromagnetic compatibility, ambient temperature, and maintenance clearance.
The complete catalog number should always be checked when selecting a replacement drive. Differences in voltage class, current rating, enclosure configuration, HIM arrangement, filtering, and other options can affect interchangeability.
For commissioning, accurate motor nameplate information and properly configured drive parameters are essential. Acceleration, deceleration, current limits, motor protection, and the selected control mode should be adjusted according to the actual load and operating requirements.
Technical Specifications
Specification
Details
Brand
Allen-Bradley
Manufacturer
Rockwell Automation
Model
20F11NE017AA0NNNNN
Product Family
PowerFlex 753
Product Type
AC Drive / Variable Frequency Drive
Bulletin
20F
Input Voltage Class
480 VAC
Input Phase
Three Phase
Output Current
17 A
Frame Size
Frame 2
Cooling Method
Forced Air
Enclosure Type
Open Type
Control Platform
PowerFlex 753
Embedded I/O
Yes
Dynamic Braking Support
Yes
Dimensions
454 × 190 × 212 mm
Weight
11.80 kg (26.01 lb)
The specified dimensions are 454 × 190 × 212 mm, with a product weight of 11.80 kg (26.01 lb). Additional cabinet clearance should be provided for power connections, control wiring, airflow, inspection, and maintenance.
Recommended Related Models
Model
Product Type
Typical Application
20F11ND8P0JA0NNNNN
PowerFlex 753 AC Drive
8 A industrial motor control
20F11NE011AA0NNNNN
PowerFlex 753 AC Drive
11 A motor-control applications
20F11NE011JA0NNNNN
PowerFlex 753 AC Drive
11 A industrial AC drive
20F11NE017AA0NNNNN
PowerFlex 753 AC Drive
17 A industrial motor control
20F11ND018P0JA0NNNNN
PowerFlex 753 AC Drive
Higher-capacity motor applications
Popular Related Models
Model
Product Family
Product Role
20F11ND5P0JA0NNNNN
PowerFlex 753
Compact industrial AC drive
20F11ND8P0JA0NNNNN
PowerFlex 753
8 A variable-frequency drive
20F11NE011AA0NNNNN
PowerFlex 753
11 A AC drive
20F11NE011JA0NNNNN
PowerFlex 753
11 A AC drive
20F11NE017AA0NNNNN
PowerFlex 753
17 A AC drive
20G11ND8P0JA0NNNNN
PowerFlex 755
Advanced industrial drive applications
The Allen-Bradley 20F11NE017AA0NNNNN PowerFlex 753 AC Drive is a higher-current solution within the PowerFlex 753 family, combining a 17 A output configuration with 480 VAC class three-phase operation and a flexible industrial automation architecture. Its design makes it suitable for conveyors, pumps, fans, packaging equipment, process machinery, and other PLC-controlled motor applications.
Applications
The Allen-Bradley 20F11NE017AA0NNNNN is a PowerFlex 753 AC Drive designed for industrial variable-frequency motor control. With a 17 A output configuration and 480 VAC class three-phase operation, it is suitable for machinery and process systems that require dependable motor speed regulation, controlled acceleration and deceleration, and integration with PLC-based automation.
Typical applications include:
Conveyor and material handling systems
Pumps and pumping stations
Industrial fans and blowers
Packaging and converting machinery
Machine tools
Production and assembly equipment
Process-control systems
Industrial HVAC equipment
Automated manufacturing lines
General-purpose AC motor applications
The Frame 2 format provides a practical solution for control cabinets where motor control equipment must be installed together with PLCs, HMIs, contactors, circuit protection, and other automation components.
17 A PowerFlex 753 for Industrial Motor Control
17 A output capacity
The 20F11NE017AA0NNNNN is configured for 17 A output current, providing a higher-capacity option within the PowerFlex 753 family for industrial motor applications.
480 VAC class, three-phase operation
The drive is designed for industrial three-phase power systems in the 480 VAC class, making it suitable for common plant electrical architectures.
Flexible PowerFlex 753 platform
The PowerFlex 753 architecture provides a modular foundation for motor control and can accommodate suitable communication, feedback, I/O, safety, and other functional options.
Embedded I/O
Integrated I/O functionality helps simplify machine-control interfaces and can reduce the amount of additional interface hardware required in some installations.
Dynamic braking support
The PowerFlex 753 platform supports dynamic braking applications where controlled motor deceleration is important. External braking components should be selected according to the motor and load requirements.
Industrial automation integration
The drive can be incorporated into PLC-controlled systems for coordinated motor control, status monitoring, parameter management, and diagnostics.
Forced-air cooling
Forced-air cooling provides thermal management for the drive. Proper cabinet ventilation and sufficient airflow are important for maintaining reliable operating temperatures.
Cabinet installation
The open-type construction is intended for installation inside a suitable electrical enclosure designed for the environmental conditions of the application.
Technical FAQs
1. What is the Allen-Bradley 20F11NE017AA0NNNNN?
It is a PowerFlex 753 AC Drive designed for variable-speed control of industrial three-phase AC motors.
2. What is the output current rating of this model?
The 20F11NE017AA0NNNNN has a 17 A output current configuration.
3. What input voltage does the drive use?
This model is designed for a 480 VAC class, three-phase industrial power supply.
4. What applications are suitable for the 20F11NE017AA0NNNNN?
Typical applications include conveyors, pumps, fans, blowers, packaging equipment, machine tools, process machinery, and automated production systems.
5. Can this PowerFlex 753 be integrated with a PLC?
Yes. The PowerFlex 753 platform is designed for integration with PLCs and other industrial automation controllers through appropriate communication and I/O configurations.
6. Does the drive support dynamic braking?
Yes. The PowerFlex 753 platform supports dynamic braking applications. The braking resistor and related equipment must be correctly selected for the specific motor and load.
7. Does the drive provide integrated I/O?
Yes. Embedded I/O is available within the PowerFlex 753 architecture for machine and process control applications.
8. What cooling method is used?
The drive uses forced-air cooling. Adequate airflow and appropriate cabinet ventilation should be provided during installation.
9. Can the drive be used for variable-speed motor control?
Yes. Variable-frequency operation allows the drive to regulate motor speed according to the application's control requirements.
10. What should be checked before commissioning?
Verify the incoming power, grounding, motor wiring, motor nameplate data, protection parameters, acceleration and deceleration settings, control signals, braking requirements, and communication configuration before operating the motor under load.
