Allen Bradley 20F11NE022AA0NNNNN PowerFlex 753 AC Drive
Allen Bradley 20F11NE022AA0NNNNN PowerFlex 753 AC Drive
0.0
Points
Brand:Allen Bradley PLC Item No.:20F11NE022AA0NNNNN Product Origin:USA Product Dimensions:454 x 190 x 212 mm Product Weight:11.8 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen-Bradley 20F11NE022AA0NNNNN PowerFlex 753 AC Drive is an industrial variable-frequency drive designed for applications requiring controlled operation of three-phase AC motors. Its 22 A configuration provides higher current capacity for industrial machinery and process equipment.
The PowerFlex 753 family uses a modular architecture that allows the drive to be adapted to different automation requirements. Depending on the application, communication, feedback, safety, and other functional options can be incorporated into the system.
The 20F11NE022AA0NNNNN is designed for cabinet-based installation and can serve as the motor-control component within a larger automation panel. Proper installation should address power distribution, motor cabling, grounding, ventilation, electromagnetic compatibility, ambient temperature, and maintenance access.
For commissioning and replacement projects, the complete catalog number should be matched carefully with the existing drive. Option codes can affect the drive's electrical and functional configuration, so a visually similar PowerFlex model should not automatically be considered a direct replacement.
Correct motor data and application parameters are also important for reliable operation. Motor protection, acceleration and deceleration, current limits, control mode, braking, and communication settings should be configured according to the actual application.
Technical Specifications
Specification
Details
Brand
Allen-Bradley
Manufacturer
Rockwell Automation
Model
20F11NE022AA0NNNNN
Product Family
PowerFlex 753
Product Type
AC Drive / Variable Frequency Drive
Bulletin
20F
Input Voltage Class
480 VAC
Input Phase
Three Phase
Output Current
22 A
Frame Size
Frame 2
Cooling Method
Forced Air
Enclosure Type
Open Type
Control Platform
PowerFlex 753
Embedded I/O
Yes
Dynamic Braking Support
Yes
Dimensions
454 × 190 × 212 mm
Weight
11.80 kg (26.01 lb)
The specified physical dimensions are 454 × 190 × 212 mm, and the supplied product weight is 11.80 kg (26.01 lb). Additional cabinet space should be allowed for power connections, control wiring, airflow, inspection, and maintenance.
Recommended Related Models
Model
Product Type
Typical Application
20F11ND8P0JA0NNNNN
PowerFlex 753 AC Drive
8 A industrial motor control
20F11NE011AA0NNNNN
PowerFlex 753 AC Drive
11 A motor-control applications
20F11NE017AA0NNNNN
PowerFlex 753 AC Drive
17 A industrial motor control
20F11NE022AA0NNNNN
PowerFlex 753 AC Drive
22 A industrial motor control
20F11ND027P0JA0NNNNN
PowerFlex 753 AC Drive
Higher-current motor applications
Popular Related Models
Model
Product Family
Product Role
20F11ND5P0JA0NNNNN
PowerFlex 753
Compact industrial AC drive
20F11ND8P0JA0NNNNN
PowerFlex 753
8 A variable-frequency drive
20F11NE011AA0NNNNN
PowerFlex 753
11 A AC drive
20F11NE017AA0NNNNN
PowerFlex 753
17 A AC drive
20F11NE022AA0NNNNN
PowerFlex 753
22 A AC drive
20G11ND8P0JA0NNNNN
PowerFlex 755
Advanced industrial drive applications
The Allen-Bradley 20F11NE022AA0NNNNN PowerFlex 753 AC Drive provides a 22 A motor-control configuration within the PowerFlex 753 platform. With 480 VAC class three-phase operation, embedded I/O, forced-air cooling, and a flexible automation architecture, it is well suited to conveyors, pumps, fans, packaging systems, process machinery, and other demanding industrial motor-control applications.
Applications
The Allen-Bradley 20F11NE022AA0NNNNN is a PowerFlex 753 AC Drive designed for industrial variable-frequency motor control. With a 22 A output configuration and 480 VAC class three-phase operation, it is suitable for applications requiring reliable motor speed regulation, controlled acceleration and deceleration, and integration with PLC-based automation systems.
Typical applications include:
Conveyor and material handling systems
Pumps and pumping equipment
Fans and blowers
Packaging and converting machinery
Machine tools
Production and assembly lines
Process-control equipment
Industrial HVAC systems
Automated manufacturing equipment
General-purpose industrial AC motor control
The Frame 2 form factor is well suited to centralized electrical cabinets where the drive operates alongside PLCs, HMIs, circuit protection, contactors, and other automation components.
High-Capacity PowerFlex 753 Drive Features
22 A output configuration
The 20F11NE022AA0NNNNN provides a 22 A output rating, making it appropriate for higher-current motor-control applications within the PowerFlex 753 family.
480 VAC class operation
The drive is designed for three-phase industrial power systems in the 480 VAC class and can be incorporated into common industrial electrical architectures.
Flexible PowerFlex 753 platform
The PowerFlex 753 architecture provides a modular foundation for industrial motor control. Communication, feedback, safety, I/O, and other functions can be configured according to the automation system.
Embedded I/O
Integrated I/O functionality helps connect the drive with machine-level control circuits and can simplify the overall control-panel design.
Dynamic braking capability
The PowerFlex 753 platform supports dynamic braking applications where controlled motor deceleration is required. Braking components should be selected based on the motor, load, and required stopping performance.
PLC and automation integration
The drive can operate as part of a larger automation system, allowing motor-control functions to be coordinated with PLC logic, operator interfaces, and other field devices.
Forced-air cooling
Forced-air cooling provides thermal management during operation. Correct cabinet ventilation and adequate airflow are important for maintaining reliable drive performance.
Industrial cabinet installation
The open-type construction is intended for installation inside a suitable electrical enclosure that provides the necessary environmental protection.
Technical FAQs
1. What is the Allen-Bradley 20F11NE022AA0NNNNN?
It is a PowerFlex 753 AC Drive designed for variable-speed control of industrial three-phase AC motors.
2. What is the output current rating?
The 20F11NE022AA0NNNNN is configured for a 22 A output current rating.
3. What input voltage does this model use?
This model is designed for a 480 VAC class, three-phase industrial power supply.
4. What applications are suitable for this drive?
It is suitable for conveyors, pumps, fans, blowers, packaging machinery, process equipment, machine tools, and automated production systems.
5. Can the 20F11NE022AA0NNNNN be connected to a PLC?
Yes. The PowerFlex 753 platform is designed for integration with PLCs and other industrial automation controllers through appropriate communication and I/O configurations.
6. Does the drive support dynamic braking?
Yes. Dynamic braking can be used when the application requires controlled motor deceleration. The braking resistor and associated equipment must be correctly sized.
7. Does the PowerFlex 753 provide integrated I/O?
Yes. The PowerFlex 753 architecture incorporates embedded I/O for machine and process-control applications.
8. What cooling system does the drive use?
The drive uses forced-air cooling. Adequate airflow and suitable cabinet ventilation should be maintained during operation.
9. Can the drive be used for continuous motor operation?
Yes, provided the motor load, ambient conditions, power supply, installation, ventilation, and drive parameters remain within the applicable operating limits.
10. What should be checked before commissioning?
Verify the incoming power, grounding, motor wiring, motor nameplate information, protection settings, acceleration and deceleration parameters, current limits, control signals, braking requirements, and communication configuration before starting the motor.
