Ingersoll Rand 47579352001 39331061 8,000-Hour Water-Cooled Service and High-Temperature Flange Gasket Configuration
Ingersoll Rand 47579352001 39331061 8,000-Hour Water-Cooled Service and High-Temperature Flange Gasket Configuration
0.0
Points
Brand:Ingersoll Rand Item No.: 47579352001 39331061 Product Origin:USA Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.08 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 47579352001 39331061 8,000-Hour Water-Cooled Service and High-Temperature Flange Gasket Configuration combines a scheduled maintenance package with the specified 39331061 gasket for compatible Sierra oil-free compressor systems. The primary service reference, 47579352001, is associated with the 8,000-hour water-cooled maintenance program, while 39331061 provides sealing support at an applicable 2-inch flange connection.
Flange gaskets are critical sealing components in industrial compressor systems. Maintaining a properly sealed joint helps prevent unwanted leakage and supports the integrity of the connected piping or equipment interface. The high-temperature specification of 39331061 makes correct material and application verification particularly important during service.
This configuration is intended for professional preventive maintenance and service planning. Before installation, maintenance personnel should verify the compressor model, serial number, flange arrangement, gasket specification, and current Ingersoll Rand parts documentation.
Technical Specifications
Specification
Details
Brand
Ingersoll Rand
Complete Configuration
47579352001 39331061
Primary Maintenance Reference
47579352001
Maintenance Package
8,000-hour water-cooled maintenance package
Associated Component
39331061
Component Type
High-temperature flange gasket
Gasket Size Reference
2-inch
Application
Sierra compressor flange connection
Compressor Platform
Sierra 37–75 kW oil-free compressor systems
Cooling Configuration
Water-cooled
Service Interval
8,000 hours
Primary Function
Scheduled maintenance and flange sealing
Installation
Applicable compressor flange interface
Dimensions
Not separately specified for the complete configuration; verify current parts documentation
Weight
Not separately specified for the complete configuration; verify current parts documentation
Compatibility
Verify compressor model, serial number, flange arrangement, and current parts documentation
Recommended Companion Models
Model
Product Name
L50
Ingersoll Rand Sierra L50 37 kW Oil-Free Rotary Screw Compressor
L60
Ingersoll Rand Sierra L60 45 kW Oil-Free Rotary Screw Compressor
L75
Ingersoll Rand Sierra L75 55 kW Oil-Free Rotary Screw Compressor
L100
Ingersoll Rand Sierra L100 75 kW Oil-Free Rotary Screw Compressor
Frequently Selected Alternatives
Model / Part Number
Product Name
47579611001
Sierra 37–75 8,000-Hour Air-Cooled Maintenance Package
47579185001
Sierra 37–75 4,000-Hour Maintenance Package
47578983001
Sierra 37–75 2,000-Hour Maintenance Package
39331038
2.5-Inch High-Temperature Flange Gasket for Applicable Sierra Configurations
Where It Excels in Industrial Use
• Designed for scheduled 8,000-hour maintenance on compatible Ingersoll Rand Sierra 37–75 kW oil-free compressor systems in water-cooled configurations.
• Combines the 47579352001 water-cooled maintenance package with the specified 39331061 high-temperature 2-inch flange gasket as one complete service configuration.
• Supports maintenance work involving flanged connections where reliable sealing is important for maintaining the intended integrity of the compressor system.
• Well suited to production plants, process-air installations, utilities, and other industrial facilities operating oil-free compressors under continuous or demanding service conditions.
• Helps maintenance teams coordinate scheduled compressor service with replacement of a specified gasket at the applicable flange interface.
Key Strengths at a Glance
• Water-cooled service focus: 47579352001 provides the scheduled 8,000-hour maintenance reference for applicable Sierra 37–75 kW water-cooled systems.
• High-temperature sealing: 39331061 is identified as a 2-inch high-temperature flange gasket for Sierra applications.
• Flange integrity: A correctly fitted gasket helps maintain a sealed connection and reduce the risk of leakage at the applicable joint.
• Integrated maintenance planning: Combining the service package and gasket reference provides a practical configuration for scheduled maintenance preparation.
• Sierra-specific application: The gasket reference is associated with Sierra equipment, making model and configuration verification important before installation.
Technical FAQs
1. What is the 47579352001 39331061 configuration used for?
It combines the 47579352001 8,000-hour water-cooled maintenance package with the specified 39331061 high-temperature flange gasket as one complete service configuration for compatible Sierra compressor systems.
2. What maintenance interval is associated with 47579352001?
47579352001 is associated with an 8,000-hour scheduled maintenance interval for applicable Sierra 37–75 kW water-cooled compressor configurations.
3. What is the function of 39331061?
39331061 is a 2-inch high-temperature flange gasket designed to provide sealing at the applicable Sierra flange connection.
4. Why is the flange gasket important during compressor maintenance?
The gasket maintains sealing between mating flange surfaces, helping prevent leakage and preserve the intended operating condition of the connected system.
5. What should be inspected before installing 39331061?
The technician should inspect the mating flange faces, gasket seating surfaces, fasteners, alignment, and surrounding components for contamination, damage, distortion, or corrosion.
6. Can a used 39331061 gasket be reused after flange disassembly?
A removed gasket should not be reused unless the applicable Ingersoll Rand service procedure specifically permits reuse. Replacement with a new gasket is generally appropriate when the sealed flange joint has been opened.
7. What symptoms can indicate a failed flange gasket?
Visible leakage, residue around the flange, pressure loss, abnormal operating conditions, or evidence of gasket extrusion or deterioration can indicate that the sealing joint requires inspection.
8. Can another 2-inch gasket be substituted for 39331061?
Not solely on the basis of nominal size. Material, temperature capability, thickness, flange design, pressure conditions, and compressor-specific application should all be verified before selecting an alternative.
9. Is 39331061 the complete flange assembly?
No. 39331061 is the gasket component associated with the applicable flange connection and does not represent the complete flange assembly.
10. What should be verified after installing the gasket?
The technician should confirm correct gasket seating and flange alignment, tighten the joint according to the applicable procedure, inspect for leakage, and complete the required compressor service checks before returning the equipment to operation.
