The ABB AFPS-11C Power Supply Module is a crucial component designed to provide continuous and reliable power to the control circuits of ABB drives. As part of the ABB drive system, this power supply module ensures that the drive operates optimally by providing the necessary power for the drive's control and protection circuits. The AFPS-11C is designed to be highly efficient, compact, and durable, offering reliable performance in various industrial applications. It is particularly suited for ABB's variable frequency drives (VFDs) and other automation systems requiring a stable power supply for operation.

The AFPS-11C ensures minimal downtime, reduces maintenance costs, and increases the reliability of your system, making it an ideal solution for industrial automation, HVAC systems, material handling, water treatment plants, and energy management applications.

Technical Specifications

Model: AFPS-11C
Type: Power Supply Module
Input Voltage: 200V to 240V AC
Output Voltage: 24V DC
Power Output: 2.5A (Maximum)
Dimensions (L x W x H): 5.8 x 3.2 x 2.5 inches (147 x 81 x 63 mm)
Weight: 0.52 kg (1.15 lbs)
Operating Temperature Range: -10°C to 50°C (14°F to 122°F)
Humidity Range: 5% to 95%, non-condensing
Mounting Type: Din rail or direct panel mounting
Certifications: CE, UL, RoHS Compliant
LED Indicators: Power Status, Fault/Error, Output Status

Recommended Related Models

ABB ACS580 VFD Series: A versatile variable frequency drive that seamlessly integrates with the AFPS-11C Power Supply Module to ensure continuous and efficient operation of control systems.
ABB ACH580 HVAC Drive: Specifically designed for HVAC applications, this drive works effectively with the AFPS-11C to power control circuits and maintain optimal system performance.
ABB 07AC91-0030 Communication Card: Works in conjunction with the AFPS-11C to provide enhanced communication capabilities, enabling the integration of control systems and drives for complex automation.
ABB 07KT98-0045 Communication Module: Expands the communication functionalities in ABB's systems, complementing the power supply module for comprehensive automation control.

Popular ABB Models

ABB ACS880 Drives: High-performance drives that benefit from the stable power supply provided by the AFPS-11C, ensuring the drives operate without interruptions and with maximum efficiency.
ABB ACH550 Drive: Ideal for HVAC systems, integrating seamlessly with the AFPS-11C Power Supply Module to maintain reliable control and power across HVAC applications.
ABB 07KT98-0045 Communication Module: This module complements the power supply module for added communication and control functions, ideal for industrial automation setups.
ABB 07AC91-0030 Communication Card: Supports ABB drives by providing additional communication capabilities, working seamlessly with the AFPS-11C to improve control and monitoring functions.

Applications

The ABB AFPS-11C Power Supply Module is designed to ensure continuous and stable power for ABB drives in a wide variety of industrial applications. Some of its primary uses include:

Industrial Automation: Provides steady power to ABB drives, ensuring uninterrupted operation in manufacturing lines, production processes, and industrial machinery.
HVAC Systems: The AFPS-11C powers ABB HVAC drives, allowing for optimal control of environmental parameters such as temperature, humidity, and air quality.
Water Treatment Plants: Ensures reliable power for pumps, motors, and other critical systems in water treatment plants, improving operational reliability and system performance.
Material Handling Systems: Provides continuous power to control systems in material handling equipment, including conveyors, lifts, and sorting systems, ensuring smooth and efficient operation.
Energy Management: Powers energy monitoring systems and energy meters, optimizing energy consumption, and reducing operational costs in industrial settings.

Advantages

Reliable Power Supply: The AFPS-11C ensures continuous power to the control section of ABB drives, preventing system failures and downtime by delivering a stable 24V DC output.
Flexible Installation: The module supports both DIN rail and direct panel mounting, providing flexibility for installation in various system configurations.
Efficient and Energy-Saving: Designed for energy efficiency, the AFPS-11C minimizes power loss while providing the necessary voltage for optimal drive operation.
Compact and Rugged Design: The small form factor makes the AFPS-11C ideal for space-limited installations, and its robust construction ensures reliability in harsh industrial environments.
Minimal Maintenance: By providing consistent power, the AFPS-11C reduces the need for frequent maintenance and minimizes the risk of power-related failures in your system.
International Certifications: The module is CE, UL, and RoHS compliant, ensuring high quality, safety, and environmental responsibility.

Technical FAQs

What is the output voltage of the AFPS-11C?
- The AFPS-11C provides a stable 24V DC output, ensuring reliable power for ABB control circuits.
How is the AFPS-11C powered?
- The module operates on 200V to 240V AC input, which it converts into a stable 24V DC output for the control sections of ABB drives.
What is the maximum power output of the AFPS-11C?
- The AFPS-11C has a maximum output of 2.5A, providing adequate power for the control circuits of ABB drives.
What are the dimensions of the AFPS-11C?
- The module measures 5.8 x 3.2 x 2.5 inches (147 x 81 x 63 mm), compact enough to fit in various control panels.
What certifications does the AFPS-11C have?
- The AFPS-11C is CE, UL, and RoHS certified, ensuring compliance with international safety, environmental, and quality standards.
Is the AFPS-11C compatible with all ABB drives?
- Yes, the AFPS-11C works with a range of ABB drive systems, including the ACS580, ACS880, and ACH550 series.
What is the weight of the AFPS-11C?
- The module weighs approximately 0.52 kg (1.15 lbs), making it easy to handle and install.
Can the AFPS-11C be used in high-humidity environments?
- Yes, the module operates in environments with 5% to 95% humidity, non-condensing.
How does the AFPS-11C improve system reliability?
- By providing continuous, stable power to the control sections of ABB drives, the AFPS-11C ensures that systems remain operational and minimizes the risk of power-related disruptions.
What should I do if the AFPS-11C is not functioning correctly?
- Check the LED indicators for status and fault information. Ensure all connections are secure and consult the manual for troubleshooting steps.
