Brand:Ingersoll Rand Item No.: 47689371004 96748157 Product Origin:USA Product Dimensions:109 × 64 × 58 mm Product Weight:0.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The 47689371004 / 96748157 configuration is intended for airend replacement and associated threaded-port service on compatible Ingersoll Rand CDM134 WJ oil-free compressor systems. The primary part number, 47689371004, identifies the CDM134 WJ airend replacement kit, while 96748157 identifies the associated hexagon socket pipe plug.
The 96748157 plug is specified as a DIN 906 M16 × 1.5 steel component. Its defined thread and plug configuration make it suitable for the corresponding application when confirmed against the machine's service documentation.
Because threaded plugs can vary by location and compressor configuration, the exact installation position should be verified before replacement.
Technical Specifications
Specification
Details
Brand
Ingersoll Rand
Primary Part Number
47689371004
Associated Part Number
96748157
Primary Component Type
Airend Replacement Kit
Associated Component Type
Hexagon Socket Pipe Plug
Airend Platform
CDM134
Configuration
WJ
Compressor Type
Oil-free screw compressor
Plug Standard
DIN 906
Thread Size
M16 × 1.5
Plug Material
Steel
Application
Compatible CDM134 WJ service configuration
Dimensions
Not reliably published as a fixed value for the complete configuration
Weight
Not reliably published as a fixed value for the complete configuration
Recommended Companion Models
Model
Product Name
CDM134 WJ
Airend Replacement Module
CDM134 OJ
Airend Replacement Module
CDM80 WJ
Airend Replacement Module
CDM80 OJ
Airend Replacement Module
Frequently Selected Alternatives
Model
Product Name
CDM134 OJ
47689371003 Airend Replacement Module
CDM80 WJ
47689371006 Airend Replacement Module
CDM80 OJ
47689371005 Airend Replacement Module
CDM134
24780462 CDM134 Airend
Where It Fits in Industrial Applications
• Designed for compatible Ingersoll Rand CDM134 WJ airend replacement and service applications.
• Suitable for major compressor overhaul work involving airend replacement and renewal of specified pipe-plug hardware.
• Supports sealing and closure of the applicable threaded port during compressor assembly or service.
• Appropriate for industrial oil-free compressor maintenance where the correct threaded plug specification is required.
• Useful for planned airend refurbishment and reassembly work on compatible compressor configurations.
Key Strengths at a Glance
• Airend service configuration — Combines the 47689371004 CDM134 WJ airend replacement kit with the 96748157 pipe plug.
• Defined thread specification — 96748157 is identified as an M16 × 1.5 pipe plug.
• DIN-standard hardware — The plug conforms to DIN 906 hexagon socket pipe-plug form.
• Steel construction — The 96748157 component is identified as a steel pipe plug.
• CDM134 WJ focus — The primary replacement kit is associated with the CDM134 WJ airend configuration.
Technical FAQs
1. What is Ingersoll Rand 47689371004?
Ingersoll Rand 47689371004 is identified as the CDM134 WJ airend replacement kit.
2. What is part number 96748157?
Part number 96748157 is an Ingersoll Rand hexagon socket pipe plug specified to DIN 906, with an M16 × 1.5 thread and steel construction.
3. How should 47689371004 and 96748157 be interpreted together?
For this product listing, the two supplied part numbers are treated as one configuration, with 47689371004 identifying the airend replacement kit and 96748157 identifying the associated pipe-plug component.
4. What is the thread size of 96748157?
The 96748157 pipe plug is specified with an M16 × 1.5 metric thread.
5. What standard is associated with 96748157?
The component is identified as a DIN 906 hexagon socket pipe plug.
6. What material is 96748157 made from?
The available specification identifies the plug as steel.
7. What is the function of a hexagon socket pipe plug?
A pipe plug closes a compatible threaded port and helps maintain the intended sealed condition of the associated compressor circuit or housing.
8. Can 96748157 be replaced with any M16 × 1.5 plug?
Replacement should not be based on thread size alone. The plug standard, material, sealing arrangement, dimensions, and service requirements should match the applicable Ingersoll Rand specification.
9. Is 96748157 a complete airend component?
No. It is a threaded pipe-plug component used in the applicable compressor assembly rather than a compression element or complete airend.
10. What should be checked before ordering this configuration?
The compressor model, serial number, airend configuration, plug location, thread specification, and applicable Ingersoll Rand service documentation should be verified before ordering.
