Brand:Ingersoll Rand Item No.: 47689371004 96749833 Product Origin:USA Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.11 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The 47689371004 / 96749833 configuration is intended for airend replacement and associated precision locating work on compatible Ingersoll Rand CDM134 WJ oil-free compressor systems. The primary part number, 47689371004, identifies the CDM134 WJ airend replacement kit, while 96749833 identifies the associated 10 × 28 mm precision dowel pin.
Dowel pins are used where repeatable positioning between mating components is required. During major airend service, the specified locating hardware can therefore be relevant to correct component alignment and reassembly.
The exact installation location and compatibility should be confirmed against the compressor serial number and applicable Ingersoll Rand service documentation before installation.
Technical Specifications
Specification
Details
Brand
Ingersoll Rand
Primary Part Number
47689371004
Associated Part Number
96749833
Primary Component Type
Airend Replacement Kit
Associated Component Type
Precision Dowel Pin
Airend Platform
CDM134
Configuration
WJ
Compressor Type
Oil-free screw compressor
Dowel Pin Diameter
10 mm
Dowel Pin Length
28 mm
Dowel Pin Size
10 × 28 mm
Application
Compatible CDM134 WJ service configuration
Dimensions
Not reliably published as a fixed value for the complete configuration
Weight
Not reliably published as a fixed value for the complete configuration
Recommended Companion Models
Model
Product Name
CDM134 WJ
Airend Replacement Module
CDM134 OJ
Airend Replacement Module
CDM80 WJ
Airend Replacement Module
CDM80 OJ
Airend Replacement Module
Frequently Selected Alternatives
Model
Product Name
CDM134 OJ
47689371003 Airend Replacement Module
CDM80 WJ
47689371006 Airend Replacement Module
CDM80 OJ
47689371005 Airend Replacement Module
CDM134
24780462 CDM134 Airend
Where It Fits in Industrial Applications
• Designed for compatible Ingersoll Rand CDM134 WJ airend replacement and assembly applications.
• Suitable for major compressor overhaul work where airend replacement is accompanied by renewal of specified locating hardware.
• Supports accurate positioning of compatible compressor components during assembly.
• Appropriate for industrial oil-free compressor maintenance where correct alignment and component location are required.
• Useful for planned refurbishment and reassembly work involving the CDM134 WJ airend configuration.
Key Strengths at a Glance
• Airend replacement configuration — Combines the 47689371004 CDM134 WJ airend replacement kit with the 96749833 dowel pin.
• Precision locating function — 96749833 is identified as a precision dowel pin for accurate component positioning.
• Defined dimensions — The dowel pin is specified at 10 × 28 mm.
• Assembly support — Provides dedicated locating hardware for compatible compressor components.
• CDM134 WJ application focus — The primary replacement kit is associated with the CDM134 WJ airend configuration.
Technical FAQs
1. What is Ingersoll Rand 47689371004?
Ingersoll Rand 47689371004 is identified as the CDM134 WJ airend replacement kit.
2. What is part number 96749833?
Part number 96749833 is an Ingersoll Rand precision dowel pin specified at 10 × 28 mm.
3. How should 47689371004 and 96749833 be interpreted together?
For this product listing, the two supplied part numbers are treated as one configuration, with 47689371004 identifying the airend replacement kit and 96749833 identifying the associated locating component.
4. What is the function of a precision dowel pin?
A precision dowel pin provides repeatable location and alignment between mating components during assembly.
5. What are the dimensions of 96749833?
The listed dimensions of 96749833 are 10 mm in diameter and 28 mm in length.
6. Is 96749833 a compression component?
No. It is a locating and alignment component rather than a compression element, bearing, seal, or fastener.
7. Why can dowel pins be important during airend service?
Accurate component positioning can be important when reassembling precision compressor components, helping maintain the intended relationship between mating parts.
8. Can 96749833 be replaced with any 10 × 28 mm pin?
Replacement should not be based on dimensions alone. The pin's tolerance, material, surface condition, and application requirements should match the applicable Ingersoll Rand specification.
9. Is 96749833 intended for every CDM134 configuration?
Not necessarily. The correct application depends on the specific compressor build and assembly location. The machine serial number and service documentation should be checked before installation.
10. What should be verified before ordering this configuration?
The compressor model, serial number, airend identification, dowel-pin location, dimensions, and applicable Ingersoll Rand service documentation should be verified before ordering.
