Brand:Ingersoll Rand Item No.:47689371004 96751516 Product Origin:USA Product Dimensions:108 × 7.2 × 7.2 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The 47689371004 / 96751516 configuration is intended for airend replacement and associated mechanical retention work on compatible Ingersoll Rand CDM134 WJ oil-free compressor systems. The primary part number, 47689371004, identifies the CDM134 WJ airend replacement kit, while 96751516 identifies the associated DIN 981 KM10 lock nut.
The 96751516 lock nut uses an M50 × 1.5 thread and follows the DIN 981 KM10 dimensional format. Its slotted design is intended for use with the appropriate locking arrangement in compatible mechanical assemblies.
The exact installation position and required locking method should be confirmed against the compressor serial number and applicable Ingersoll Rand service documentation before installation.
Technical Specifications
Specification
Details
Brand
Ingersoll Rand
Primary Part Number
47689371004
Associated Part Number
96751516
Primary Component Type
Airend Replacement Kit
Associated Component Type
Lock Nut
Lock Nut Standard
DIN 981
Lock Nut Designation
KM10
Thread Size
M50 × 1.5
Lock Nut Outside Diameter
Approx. 70 mm
Lock Nut Reference Diameter
Approx. 61 mm
Lock Nut Height
Approx. 11 mm
Airend Platform
CDM134
Configuration
WJ
Compressor Type
Oil-free screw compressor
Application
Compatible CDM134 WJ service configuration
Complete Configuration Dimensions
Not reliably published as a fixed value
Complete Configuration Weight
Not reliably published as a fixed value
Recommended Companion Models
Model
Product Name
CDM134 WJ
Airend Replacement Module
CDM134 OJ
Airend Replacement Module
CDM80 WJ
Airend Replacement Module
CDM80 OJ
Airend Replacement Module
Frequently Selected Alternatives
Model
Product Name
CDM134 OJ
47689371003 Airend Replacement Module
CDM80 WJ
47689371006 Airend Replacement Module
CDM80 OJ
47689371005 Airend Replacement Module
CDM134
24780462 CDM134 Airend
Where It Fits in Industrial Applications
• Designed for compatible Ingersoll Rand CDM134 WJ airend replacement and assembly applications.
• Suitable for major compressor overhaul work where the airend assembly and specified locking hardware are serviced together.
• Supports secure retention of compatible rotating or assembled components during compressor reassembly.
• Appropriate for industrial oil-free compressor maintenance where the correct lock-nut specification is required.
• Useful for planned airend refurbishment and precision mechanical assembly work.
Key Strengths at a Glance
• Airend retention configuration — Combines the 47689371004 CDM134 WJ airend replacement kit with the 96751516 lock nut.
• DIN 981 specification — 96751516 is identified as a KM10 lock nut conforming to DIN 981.
• Defined metric thread — KM10 corresponds to an M50 × 1.5 thread.
• Precision mechanical retention — The slotted lock-nut design is intended for secure positioning of compatible shaft-mounted components.
• CDM134 WJ focus — The primary replacement kit is specifically associated with the CDM134 WJ airend configuration.
Technical FAQs
1. What is Ingersoll Rand 47689371004?
Ingersoll Rand 47689371004 is identified as the CDM134 WJ airend replacement kit.
2. What is part number 96751516?
Part number 96751516 is a genuine Ingersoll Rand DIN 981 KM10 lock nut.
3. How should 47689371004 and 96751516 be interpreted together?
For this product listing, the two supplied part numbers are treated as one configuration, with 47689371004 identifying the airend replacement kit and 96751516 identifying the associated locking component.
4. What does KM10 mean for the 96751516 lock nut?
KM10 is the DIN 981 designation corresponding to an M50 × 1.5 metric thread.
5. What are the standard dimensions of a DIN 981 KM10 lock nut?
The standard KM10 dimensions are approximately 70 mm outside diameter, 61 mm internal reference diameter, and 11 mm height.
6. What is the function of a DIN 981 lock nut?
A DIN 981 lock nut provides axial retention for compatible shaft-mounted components and can be secured with a matching tab washer or locking arrangement.
7. Is 96751516 a bearing or airend component?
No. It is a mechanical locking component rather than a bearing or complete airend assembly.
8. Can another M50 × 1.5 nut be substituted for 96751516?
Thread size alone is not sufficient for substitution. The lock-nut design, dimensions, locking method, material, and applicable assembly requirements should match the specified component.
9. Is 96751516 suitable for every CDM134 configuration?
Not necessarily. The correct application depends on the exact compressor build and assembly location. The machine serial number and service documentation should be checked before installation.
10. What should be verified before ordering this configuration?
The compressor model, serial number, airend identification, lock-nut location, thread specification, locking arrangement, and applicable Ingersoll Rand service documentation should be verified before ordering.
