Ingersoll Rand 47689371005 / 96749833 Airend Dowel Pin Module

Where It Fits in Industrial Applications

• Used in compressor airend replacement and major maintenance applications involving compatible Ingersoll Rand equipment.

• 47689371005 is associated with the CDM80 OJ airend replacement configuration.

• 96749833 is identified as a precision dowel pin used for component positioning in applicable compressor assemblies.

• Suitable for overhaul work where accurate alignment between mating compressor components is required.

• Appropriate for service applications where original locating hardware must be replaced during disassembly and reassembly.

Key Strengths at a Glance

• CDM80 OJ replacement reference — 47689371005 is associated with the CDM80 OJ airend replacement kit.

• Precision locating hardware — 96749833 is a dowel pin designed to maintain accurate component positioning.

• OEM compressor component — The part-number combination uses Ingersoll Rand replacement references.

• Alignment-focused function — A precision dowel helps maintain repeatable positioning between mating components.

• Service-specific fitment — Pin dimensions and installation location should be verified against the applicable parts breakdown.

Technical FAQs

1. What is the Ingersoll Rand 47689371005 / 96749833 configuration?

It is a user-supplied configuration combining the 47689371005 CDM80 OJ airend replacement kit with 96749833, a precision dowel pin.

2. What does 47689371005 represent?

47689371005 is identified as an airend replacement kit for the Ingersoll Rand CDM80 OJ configuration.

3. What is 96749833?

96749833 is a precision dowel pin used for accurate positioning of compatible compressor components.

4. What is the function of a dowel pin in an airend assembly?

A dowel pin provides accurate alignment and repeatable positioning between mating components, helping maintain the intended assembly geometry.

5. Is 96749833 specifically a CDM80 OJ airend dowel pin?

The part should be verified against the applicable machine parts breakdown before installation. A dowel pin is dimension-specific, and similar-looking pins are not necessarily interchangeable.

6. Can 96749833 be reused during airend replacement?

Reuse depends on the condition and the applicable service procedure. A dowel with wear, deformation, corrosion, or installation damage should be replaced.

7. What should be checked before installing 96749833?

The pin diameter, length, mating holes, component alignment, and condition of the surrounding assembly should be checked before installation.

8. Why is precision important for a dowel pin?

The dowel establishes the relative position of mating components. Incorrect dimensions can affect alignment and may prevent proper assembly.

9. Is 96749833 supplied as part of the 47689371005 kit?

The available references identify 47689371005 as the CDM80 OJ airend replacement kit and 96749833 separately as a dowel pin. The available information does not establish that the pin is a standard included component of the replacement kit.

10. Are fixed dimensions and weight available for the complete configuration?

Not reliably published as fixed values for the complete 47689371005 / 96749833 configuration.
