Ingersoll Rand 47689371006 / 96749833 Airend Dowel Pin Module

Where It Fits in Industrial Applications

• 47689371006 is identified as an Ingersoll Rand CDM80 WJ airend replacement kit.

• 96749833 is identified as a genuine Ingersoll Rand precision dowel pin used as an alignment and locating component.

• The dowel pin supports accurate positioning of compatible compressor assembly components during service or reassembly.

• The combined configuration can support planned airend replacement and associated alignment-component service.

• Compressor model, serial number, and applicable assembly documentation should be checked before installation. Ingersoll Rand documentation notes that the serial number is the key identifier for confirming the exact unit configuration.

Key Strengths at a Glance

• Combines the supplied airend replacement and precision-pin references into one traceable configuration.

• Provides a dedicated CDM80 WJ airend replacement reference.

• Includes an identified genuine Ingersoll Rand precision dowel pin.

• Supports accurate component positioning during applicable compressor assembly work.

• Helps maintenance teams retain the exact supplied part-number combination during procurement.

Technical FAQs

1. What is Ingersoll Rand 47689371006?

47689371006 is an Ingersoll Rand airend replacement kit associated with the CDM80 WJ configuration.

2. What is Ingersoll Rand 96749833?

96749833 is a genuine Ingersoll Rand precision dowel pin.

3. What is the function of a precision dowel pin?

A precision dowel pin is used to locate and align compatible components accurately while maintaining their intended relative position during assembly.

4. Are 47689371006 and 96749833 treated as one product here?

Yes. For this product listing, the two supplied part numbers are treated as one complete configuration.

5. Is 96749833 specifically a CDM80 WJ dowel pin?

The available listing identifies 96749833 as an Ingersoll Rand precision dowel pin, but it does not establish the component as exclusively CDM80 WJ-specific. Its exact installation position should therefore be confirmed against the applicable parts documentation.

6. Why is a precision dowel important during airend service?

Accurate locating components help maintain the intended alignment of compatible assemblies during replacement and reassembly.

7. Can another dowel pin with similar dimensions be substituted?

Substitution should not be based on dimensions alone. Diameter tolerance, length, material, surface finish, and the locating requirements of the assembly should also be verified.

8. Can 47689371006 be used on a CDM80 OJ compressor?

The CDM80 OJ configuration uses a different airend replacement reference, so the compressor configuration should be checked before selecting this kit.

9. Are dimensions and weight available for the complete configuration?

A fixed overall dimension and weight are not reliably published for the complete 47689371006 / 96749833 configuration.

10. What should be verified before ordering this configuration?

The complete part-number combination, compressor model, serial number, applicable assembly drawing, and dowel-pin specification should be checked before ordering or installation.
