Brand:Siemens Item No.:6AG4010-6BC40-0XX5 Product Origin: Germany Product Dimensions:481 × 177 × 509 mm Product Weight:14.1 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG4010-6BC40-0XX5 SIMATIC IPC3000 SMART V3 is a 19-inch, 4U industrial rack PC intended for computing tasks in manufacturing and automation environments. Its listed Intel Core i5-6500 processor, 16 GB of DDR4 memory, and dual 1 TB hard drives provide a foundation for suitable industrial visualization, production monitoring, data storage, and supervisory applications.
The system includes a range of connections for networking, serial communication, USB peripherals, and displays. It is listed without a DVD drive or operating system and uses a 350 W power supply. The variant is designated for the Chinese market, so confirm the regional specification and the full hardware configuration before ordering or integrating it into an existing installation.
Technical Specifications
Specification
Details
Manufacturer
Siemens
Model number
6AG4010-6BC40-0XX5
Product family
SIMATIC IPC3000 SMART V3
Device type
Industrial rack PC
Rack format
19-inch, 4U
Processor
Intel Core i5-6500
Processor cores / threads
4 cores / 4 threads
Maximum Turbo frequency
3.6 GHz
Cache
6 MB
Memory
16 GB DDR4 SDRAM
Storage
2 × 1 TB HDD
Ethernet
2 × LAN
Serial / COM
2 serial interfaces; 2 additional COM connections listed
USB
6 ports: 2 front, 4 rear
Display outputs
VGA, DisplayPort
Other interfaces
2 × PS/2; audio
Optical drive
None
Operating system
Not included
Power supply
350 W
Regional designation
Chinese market; China-specific power cable
Dimensions (mm)
Exact dimensions unverified for this configuration
Weight (kg)
Approximately 14.1 kg
Recommended Companion Models
Model number
Product name
6AG4010-6BC40-0DX5
Siemens SIMATIC IPC3000 SMART V3 Rack PC
6AG4010-6BC40-0FX5
Siemens SIMATIC IPC3000 SMART V3 Rack PC
6AG4010-6BC31-0XX5
Siemens SIMATIC IPC3000 SMART V3 Rack PC
6AG4010-6BC30-0XX5
Siemens SIMATIC IPC3000 SMART V3 Rack PC
Frequently Selected Alternatives
Model number
Product name
6AG4010-6BC21-0XX5
Siemens SIMATIC IPC3000 SMART V3 Rack PC
6AG4010-6BC21-0DX5
Siemens SIMATIC IPC3000 SMART V3 Industrial PC
6AG4010-6BB30-0XX5
Siemens SIMATIC IPC3000 SMART V3 Industrial PC
6AG4010-4AA20-0XX5
Siemens SIMATIC IPC3000 SMART Industrial PC
Where It Excels in Industrial Use
- Industrial visualization and monitoring: Provides a platform for HMI software, production dashboards, and equipment-status displays in compatible industrial environments.
- Centralized factory computing: Its 19-inch, 4U rack format is suitable for control rooms, equipment racks, and centralized industrial computing installations.
- Production data management: The dual 1 TB hard drives provide local storage for operational records, application data, and production reports.
- Industrial communication: Ethernet, serial/COM, USB, and display connections support integration with compatible equipment and peripherals.
- Manufacturing support systems: Its Intel Core i5 processor and 16 GB of memory can support suitable supervisory, visualization, and data-processing workloads.
Key Strengths at a Glance
- Intel Core i5 performance: Uses an Intel Core i5-6500 processor with four cores, four threads, a maximum Turbo frequency of 3.6 GHz, and 6 MB of cache.
- 16 GB DDR4 memory: Provides memory capacity for compatible industrial applications and multitasking.
- Dual 1 TB storage: Two hard drives provide 2 TB of nominal combined capacity, subject to formatting and the configured storage arrangement.
- Broad connectivity: Includes two Ethernet LAN ports, serial/COM connections, six USB ports, VGA, DisplayPort, PS/2, and audio interfaces.
- Industrial rack integration: Uses a 19-inch, 4U chassis format and is listed with a 350 W power supply.
Technical FAQs
1. Which processor is installed in the Siemens 6AG4010-6BC40-0XX5?
The listed configuration uses an Intel Core i5-6500 processor with four cores, four threads, a maximum Turbo frequency of 3.6 GHz, and 6 MB of cache.
2. How much memory and storage does it provide?
This configuration includes 16 GB of DDR4 SDRAM and two 1 TB hard drives. The usable storage capacity depends on formatting and the drive configuration.
3. Does it support Ethernet networking?
Yes. The listed configuration includes two Ethernet LAN interfaces for communication with compatible industrial networks and connected devices.
4. Which serial communication interfaces are available?
The configuration lists two serial interfaces and two additional COM connections supporting RS-232, RS-422, or RS-485 modes as applicable. Verify the precise port arrangement before connecting equipment.
5. What display outputs does the system provide?
The listed configuration includes VGA and DisplayPort outputs for compatible monitors and industrial displays.
6. Is an operating system included?
The listed configuration is supplied without an operating system. A compatible operating system, drivers, and any required software licenses must be arranged separately.
7. Does it include an optical drive?
No DVD drive is listed. Software installation may require USB media or another supported installation method.
8. What power supply does this model use?
The listed configuration includes a 350 W power supply. Check the unit's electrical requirements and local power-cable compatibility before installation.
9. Can it be used outside China?
This variant is listed as released for the Chinese market and supplied with a China-specific power cable. Confirm regional approvals, electrical compatibility, and supplier support before using it elsewhere.
10. What should be checked before replacing an existing industrial PC?
Compare the processor, memory, storage, interface layout, power requirements, operating-system support, and regional designation. Verify that the existing industrial application and connected equipment will work with the replacement.
