Brand:Siemens Item No.:6AG1222-1BD30-5XB0 Product Origin:Germany Product Dimensions:38 × 62 × 21 mm Product Weight:0.03 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1222-1BD30-5XB0 SIPLUS S7-1200 SB 1222 Digital Output Module is designed for compact automation systems that require reliable electronic switching and high-speed digital signals. Its four 24 V DC outputs support compatible control tasks, while the MOSFET output design enables solid-state switching.
The SIPLUS version adds conformal coating and an extended operating temperature range compared with standard industrial configurations. This makes it an option for applications where environmental conditions require additional protection.
Before installation, verify compatibility with the S7-1200 CPU, the available signal-board interface, the required output current, and the TIA Portal project configuration. The outputs are not short-circuit protected, so appropriate external protection should be included in the control design.
Technical Specifications
Parameter
Specification
Brand
Siemens
Model
6AG1222-1BD30-5XB0
Product Series
SIPLUS S7-1200
Product Type
SB 1222 Digital Output Signal Board
Base Model
6ES7222-1BD30-0XB0
Number of Digital Outputs
4
Output Voltage
24 V DC
Permitted Output Supply Voltage
20.4–28.8 V DC
Output Technology
Solid-state MOSFET
Rated Output Current
0.1 A per channel
Maximum Output Frequency
200 kHz
Short-Circuit Protection
No
Conformal Coating
Yes
Operating Temperature
-40°C to +60°C
Startup Temperature
-25°C
Typical Power Loss
0.5 W
Engineering Software
STEP 7 / TIA Portal
Dimensions
38 × 62 × 21 mm
Weight
0.03 kg / 0.07 lb
Recommended Related Models
Siemens 6ES7222-1BD30-0XB0 Digital Output Signal Board – The standard S7-1200 SB 1222 version on which this SIPLUS model is based.
Siemens 6AG1222-1BH32-2XB0 Digital Output Module – A SIPLUS S7-1200 digital output option; verify channel configuration and electrical specifications.
Siemens 6ES7222-1BF32-0XB0 Digital Output Module – An S7-1200 digital output expansion option with a different channel configuration.
Siemens 6ES7223-0BD30-0XB0 Digital I/O Signal Board – A compact signal-board option combining digital inputs and outputs.
Siemens 6ES7231-4HD32-0XB0 Analog Input Module – An S7-1200 analog signal module for compatible measurement applications.
Popular Related Models
Siemens 6ES7222-1BD30-0XB0 Digital Output Signal Board
Siemens 6AG1222-1BD30-5XB0 SIPLUS Digital Output Module
Siemens 6ES7222-1BF32-0XB0 Digital Output Module
Siemens 6ES7223-0BD30-0XB0 Digital I/O Signal Board
Siemens 6ES7231-4HD32-0XB0 Analog Input Module
Siemens 6ES7214-1AG40-0XB0 S7-1200 CPU Module
Applications
Factory Automation: Controls compatible digital devices on automated production lines.
High-Speed Switching: Supports suitable applications requiring digital output frequencies up to 200 kHz.
Machine Control: Provides switching signals for compatible control circuits and automation equipment.
Industrial Equipment: Supports compact control panels and distributed machine-control applications.
Harsh-Environment Automation: The conformal coating and extended temperature specification support use in demanding environments.
PLC Signal Expansion: Adds four digital output channels to a compatible S7-1200 configuration.
Advantages
Four Digital Outputs: Provides four 24 V DC output channels in a compact signal board.
High-Speed Operation: Supports output frequencies up to 200 kHz under applicable operating conditions.
Solid-State Switching: Uses MOSFET outputs for electronic switching.
Extended Temperature Range: Designed for operation from -40°C to +60°C, with startup specified at -25°C.
Conformal Coating: Helps protect circuit assemblies against environmental contaminants.
TIA Portal Integration: Supports configuration within the Siemens S7-1200 engineering environment.
Technical FAQs
Q1: What is the main function of the Siemens 6AG1222-1BD30-5XB0?
It provides four digital output channels for controlling compatible devices in a Siemens S7-1200 PLC system.
Q2: What output voltage does this module support?
The rated output voltage is 24 V DC, with an output supply range of 20.4–28.8 V DC.
Q3: How many digital output channels are available?
The SB 1222 signal board provides four digital outputs.
Q4: What type of output technology does it use?
It uses solid-state MOSFET transistor outputs, suitable for electronic switching applications.
Q5: What is the maximum output current per channel?
The rated output current is 0.1 A per channel. Check the load requirements and manufacturer's derating guidance before connecting equipment.
Q6: Does the module support high-speed output signals?
Yes. Its product designation specifies operation up to 200 kHz for suitable applications and configurations.
Q7: What is the operating temperature range?
The specified operating temperature range is -40°C to +60°C, with startup permitted at -25°C under the stated conditions.
Q8: What is the purpose of the conformal coating?
The coating helps protect the electronic circuit assemblies against environmental contaminants and supports use in demanding industrial environments.
Q9: Which engineering software is used to configure the module?
The module is configured through STEP 7 in TIA Portal, subject to the supported software version and device configuration.
Q10: Does the module provide short-circuit protection?
No. The published specifications indicate that the outputs do not have short-circuit protection. External circuit protection and proper load selection are therefore important.
