Brand:Siemens Item No.:6AG1222-1BF32-4XB0 Product Origin:Germany Product Dimensions:45 × 100 × 75 mm Product Weight:0.162 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1222-1BF32-4XB0 Digital Output Module belongs to the SIPLUS S7-1200 product family. It expands the output capability of compatible PLC systems, enabling the controller to switch field devices through eight 24 V DC transistor outputs.
The conformal coating distinguishes this SIPLUS version from its standard counterpart and supports operation under the specified environmental conditions. Its digital outputs are suitable for applications such as machine control, production equipment, and automated material handling.
Before installing or replacing this module, confirm compatibility with the S7-1200 CPU, verify load requirements, and provide appropriate external protection because the outputs do not have built-in short-circuit protection.
Technical Specifications
Parameter
Specification
Brand
Siemens
Model
6AG1222-1BF32-4XB0
Product Series
SIPLUS SIMATIC S7-1200
Product Type
SM 1222 Digital Output Module
Standard Base Model
6ES7222-1BF32-0XB0
Number of Digital Outputs
8
Output Type
Transistor
Rated Output Voltage
24 V DC
Permitted Supply Voltage
20.4–28.8 V DC
Rated Output Current
0.5 A per channel
Maximum Resistive Load Current
0.5 A
Short-Circuit Protection
No; external protection required
Conformal Coating
Yes
Operating Temperature
-20°C to +60°C
Minimum Cold-Start Temperature
0°C
Typical Power Loss
1.5 W
Protection Rating
IP20
Dimensions
45 × 100 × 75 mm
Weight
0.162 kg / 0.36 lb
Recommended Related Models
Siemens 6ES7222-1BF32-0XB0 Digital Output Module – Standard S7-1200 SM 1222 version on which this SIPLUS model is based.
Siemens 6AG1222-1BF32-2XB0 Digital Output Module – SIPLUS version with an extended temperature range of -40°C to +70°C.
Siemens 6AG1222-1BH32-4XB0 Digital Output Module – SIPLUS S7-1200 module with 16 transistor output channels.
Siemens 6AG1222-1HF32-4XB0 Digital Output Module – SIPLUS S7-1200 module with eight relay outputs.
Siemens 6AG1221-1BF32-4XB0 Digital Input Module – SIPLUS S7-1200 module with eight digital input channels.
Popular Related Models
Siemens 6ES7222-1BF32-0XB0 Digital Output Module
Siemens 6AG1222-1BF32-2XB0 Digital Output Module
Siemens 6AG1222-1BH32-4XB0 Digital Output Module
Siemens 6AG1222-1HF32-4XB0 Relay Output Module
Siemens 6AG1221-1BF32-4XB0 Digital Input Module
Siemens 6AG1223-1BH32-4XB0 Digital I/O Module
Applications
Factory Automation: Controls compatible electrical loads on automated production lines.
Machine Control: Switches suitable DC devices according to PLC program logic.
Packaging Equipment: Provides digital control signals for machine sequences and production operations.
Industrial Process Control: Interfaces PLC outputs with compatible field devices.
Control Cabinet Integration: Expands the digital output capacity of compatible S7-1200 systems.
Industrial Equipment Maintenance: Serves as a replacement or spare module when the existing hardware configuration has been verified.
Advantages
Eight Digital Outputs: Provides eight transistor output channels in a single module.
24 V DC Operation: Supports common industrial control applications.
0.5 A Rated Output Current: Controls compatible loads within the specified electrical limits.
Conformal Coating: Adds protection to electronic assemblies against environmental contaminants.
Diagnostic Support: Supports module diagnostics and supply-voltage monitoring.
TIA Portal Integration: Can be configured within the applicable Siemens STEP 7 engineering environment.
Technical FAQs
Q1: What is the Siemens 6AG1222-1BF32-4XB0 used for?
It provides eight digital transistor outputs for controlling compatible devices in a SIMATIC S7-1200 PLC system.
Q2: How many output channels does this module provide?
The module provides eight digital outputs arranged in one group.
Q3: What is the rated output voltage?
The rated output voltage is 24 V DC. The permitted DC supply voltage range is 20.4–28.8 V.
Q4: What is the rated output current per channel?
The rated output current is 0.5 A per channel for a compatible load. Check the applicable group-current and installation limits before use.
Q5: Does the module use relay or transistor outputs?
It uses transistor outputs, making it suitable for electronic switching of compatible DC loads.
Q6: What is the operating temperature range?
The specified operating temperature range is -20°C to +60°C. The minimum cold-start temperature is 0°C.
Q7: What is the purpose of the conformal coating?
It provides an additional protective layer over the electronic assemblies to help withstand specified environmental conditions.
Q8: Does the module include short-circuit protection?
No. The outputs are not short-circuit protected, so suitable external protection and correct load selection are necessary.
Q9: Which standard Siemens model is the SIPLUS version based on?
It is based on the Siemens 6ES7222-1BF32-0XB0 SM 1222 digital output module.
Q10: What should be checked before replacing an existing module?
Verify the complete part number, PLC compatibility, output wiring, load current, temperature requirements, and the required external circuit protection.
