The Yokogawa ADV569-P01 Power Supply Module is a high-performance, reliable, and efficient solution designed to provide seamless power to your industrial automation systems. This module is integral to maintaining consistent power flow and ensuring system uptime in a wide range of control applications, including process automation, energy management, and manufacturing systems. With a compact design and protective features, it ensures that your operation runs smoothly, even under demanding conditions.

Built for integration with Yokogawa’s advanced control and monitoring systems, the ADV569-P01 module is engineered for flexibility, offering robust performance across diverse industries. Whether you're upgrading an existing system or installing a new setup, the ADV569-P01 promises to deliver stable power and exceptional reliability.

Technical Specifications

Model: Yokogawa ADV569-P01
Module Type: Power Supply Module
Input Voltage: 100-240 V AC (50/60 Hz)
Output Voltage: 24 V DC
Output Current: 10 A
Power Output: 240 W
Dimensions: 6.1 x 5.5 x 3.8 inches (155 x 140 x 97 mm)
Weight: 1.4 kg (3.09 lbs)
Operating Temperature: 0°C to 50°C
Storage Temperature: -20°C to 85°C
Humidity: 5% to 95% RH (non-condensing)
Protection Features: Overvoltage, Overcurrent, and Short Circuit Protection
Certifications: UL Listed, CE, RoHS Compliant

Recommended Related Models

Yokogawa ADV551-P01 – 24V DC Power Supply Unit
Yokogawa ADV541-P01 – DC Output Power Module
Yokogawa ADV650-P01 – Advanced I/O Module
Yokogawa ADV500-P01 – Main Control Unit Module
Yokogawa ADV300-P01 – Communication Interface Module

These related models are ideal companions for the ADV569-P01, providing enhanced capabilities and robust support for your automation system.

Popular Yokogawa Models

Yokogawa’s wide range of modules work seamlessly with the ADV569-P01, offering additional functionalities to ensure your control systems are scalable, efficient, and reliable. Popular models include:

Yokogawa DCS Centum VP - Distributed Control System for process automation
Yokogawa STARDOM - Remote Automation Control System for small and medium-sized operations
Yokogawa FAM (Field Asset Management) - Monitoring and diagnostics tool for asset optimization
Yokogawa VAU Series - Signal conditioning units for accurate data processing

These models are used extensively across industries such as oil & gas, chemical processing, and energy management, ensuring seamless integration with the ADV569-P01 Power Supply Module.
