Siemens 6AG4010-6EB33-1DX5 High-Performance Industrial Rack Computer

Where It Excels in Industrial Use

- Factory automation: Supports industrial computing tasks such as production monitoring, process visualization, and equipment coordination.

- Centralized control rooms: Provides rack-mounted computing for supervisory applications, manufacturing dashboards, and operator workstations.

- Production data processing: Can run compatible applications for data collection, production reporting, and operational analysis.

- PLC integration: Supports communication with compatible automation controllers through Ethernet and serial interfaces.

- Industrial system integration: Provides a computing platform for connecting factory networks, peripheral equipment, and supervisory software.

- Legacy application support: Can help maintain established industrial computing environments when the hardware, operating system, and software requirements are compatible.

Key Strengths at a Glance

- Intel Core i7 processing: Equipped with an Intel Core i7-6700 processor featuring four cores, four threads, and a maximum turbo frequency of 4.0 GHz.

- 8 GB DDR4 memory: Provides memory capacity for compatible industrial visualization, monitoring, and data-processing applications.

- 1 TB hard drive: Offers local storage for application software, production records, and operational data.

- Extensive connectivity: Includes Ethernet, serial, COM, USB, VGA, DisplayPort, PS/2, and audio interfaces.

- Additional communications and USB capacity: The listed configuration specifies two additional COM interfaces and four additional USB ports.

- Rack-ready design: Uses a 19-inch, 4U industrial rack format suitable for compatible control cabinets and equipment racks.

Technical FAQs

1. What is the Siemens 6AG4010-6EB33-1DX5?

It is a Siemens SIMATIC IPC3000 SMART V3 industrial rack computer intended for industrial computing and automation-support applications.

2. Which processor does it use?

The listed configuration uses an Intel Core i7-6700 with four cores, four threads, a 3.4 GHz base frequency, up to 4.0 GHz turbo frequency, and 8 MB cache.

3. How much memory is installed?

The listed configuration includes 8 GB of DDR4 SDRAM. Confirm the installed memory before planning upgrades.

4. What storage capacity does it provide?

It is listed with a 1 TB hard disk drive. For a used or refurbished unit, check the drive's condition and remaining service life.

5. Does it include an operating system?

No. The listed configuration is supplied without an operating system. The appropriate operating system, license, and compatible drivers must be sourced separately.

6. Which communication interfaces are available?

The listed configuration includes two Ethernet LAN ports, two serial interfaces, two COM interfaces supporting RS232/422/485, four rear USB ports, and two front USB ports. It also specifies additional COM and USB interfaces.

7. Which display outputs does it support?

The listed configuration provides one VGA output and one DisplayPort output. Confirm monitor compatibility and resolution requirements before installation.

8. Can it communicate with Siemens PLCs?

Yes, it can potentially communicate with compatible SIMATIC PLCs through supported Ethernet or serial interfaces. Actual compatibility depends on the PLC model, protocol, driver, and installed engineering or supervisory software.

9. What are its dimensions and weight?

The listed net weight is 14.1 kg. Exact chassis dimensions were not verified for this order number; confirm the mechanical drawing before planning rack clearance.

10. What should be checked before commissioning?

Verify the full order number, electrical supply, interface configuration, operating-system compatibility, software licensing, cooling, and network-security requirements. This configuration is listed for the Chinese market and comes with a China-specific power cable, so regional suitability should also be confirmed.
