Siemens 6AG4012-2BB40-0AX0 SIMATIC IPC347G Industrial Rack PC

Where It Strengthens Industrial Computing Infrastructure

• Designed for industrial computing applications including production supervision, equipment monitoring, and factory data processing.

• Combines an Intel Core i5-6500 processor with 32 GB of DDR4 memory for compatible applications that benefit from greater memory capacity.

• Uses a 19-inch, 4U rack-mounted design suited to compatible industrial cabinets and control-room installations.

• Provides dual Gigabit Ethernet for connecting to industrial networks and Ethernet-enabled equipment.

• Supports a range of displays and peripherals through DisplayPort, VGA, USB, serial, PS/2, and audio interfaces.

• Uses a 256 GB solid-state drive for operating-system files, application software, and frequently accessed data.

• Includes Windows 10 IoT Enterprise, providing an operating-system foundation for compatible industrial applications.

Core Advantages for Industrial Deployment

• Quad-core processing: The Intel Core i5-6500 operates at 3.2 GHz, with turbo frequencies up to 3.6 GHz and 6 MB cache.

• 32 GB DDR4 memory: The installed memory configuration supports multitasking and applications with higher memory demands.

• Solid-state storage: A 256 GB SSD provides responsive storage for the operating system, application files, and system data.

• Windows-based operation: The 0AX0 configuration is supplied with Windows 10 IoT Enterprise for compatible Core i5 systems.

• Extensive connectivity: Dual Gigabit Ethernet, multiple USB ports, serial interfaces, and two display outputs support integration with compatible industrial equipment.

• Rack-friendly format: The 4U chassis is designed for compatible 19-inch rack installations.

• Industrial AC input: A 350 W power supply supports 100–240 V AC; the power cable is not included.

Technical FAQs

1. What is the Siemens 6AG4012-2BB40-0AX0 used for?

It is a SIMATIC IPC347G industrial rack PC designed for compatible industrial computing, production monitoring, supervisory applications, and factory data processing.

2. Which processor does this model use?

It features an Intel Core i5-6500 processor with four cores, four threads, a 3.2 GHz base frequency, turbo speeds up to 3.6 GHz, and 6 MB cache.

3. How much memory is installed?

This configuration includes 32 GB of DDR4 memory, arranged as two 16 GB modules.

4. What storage capacity does it provide?

It is configured with a 256 GB solid-state drive (SSD) for the operating system, application software, and local data.

5. Which operating system is included?

The 0AX0 variant includes Windows 10 IoT Enterprise for compatible Core i5 configurations.

6. Does the IPC347G support Ethernet networking?

Yes. It includes two Gigabit Ethernet interfaces for connecting to industrial networks and other compatible Ethernet-enabled equipment.

7. Which display connections are available?

The system provides one DisplayPort and one VGA interface for compatible monitors and display equipment.

8. What peripheral interfaces does it offer?

It includes two front USB ports, four rear USB ports, two internal USB connections, two serial COM ports, two COM pin headers, two PS/2 connections, and audio interfaces.

9. What are its power requirements?

The computer uses a 350 W industrial power supply with a 100–240 V AC input range. The power cable is not included.

10. What installation conditions should be considered?

Install the PC in a compatible 19-inch rack with sufficient airflow and servicing clearance. The specified operating temperature range is 5–40 °C, and the unit has IP20 protection; it is not designed for direct exposure to water or excessive dust.
