Siemens 6AG4012-2BB40-0XX0 SIMATIC IPC347G Industrial Rack PC

Where It Fits in Industrial Computing Environments

• Designed for industrial computing tasks such as production monitoring, equipment supervision, and manufacturing data processing.

• Combines an Intel Core i5-6500 processor with a 32 GB DDR4 memory configuration for compatible applications that benefit from higher memory capacity.

• Uses a 19-inch, 4U rack format suitable for compatible industrial cabinets and control-room equipment racks.

• Provides two Gigabit Ethernet interfaces for connections to industrial networks and Ethernet-enabled devices.

• Supports displays and peripherals through DisplayPort, VGA, USB, serial, PS/2, and audio interfaces.

• Offers a flexible software deployment path because the 0XX0 variant is supplied without an operating system.

• Uses a 350 W industrial power supply designed for 100–240 V AC input.

Main Advantages for System Integration

• Quad-core Intel processing: The Core i5-6500 operates at 3.2 GHz, with turbo speeds up to 3.6 GHz and 6 MB cache.

• 32 GB DDR4 memory: Provides substantial memory capacity for compatible industrial applications and multitasking workloads.

• Configurable storage: The IPC347G family supports hard-drive and solid-state storage configurations; confirm the drive fitted to the exact order number.

• Operating-system choice: The no-OS configuration allows integrators to install a compatible operating system and required application software.

• Versatile connectivity: Dual Gigabit Ethernet, multiple USB connections, serial interfaces, and two display outputs accommodate a range of industrial peripherals.

• Rack-oriented design: The 4U chassis supports installation in compatible 19-inch rack systems.

• Industrial power input: Supports 100–240 V AC; the power supply cable is not included.

Technical FAQs

1. What is the Siemens 6AG4012-2BB40-0XX0 designed for?

It is a SIMATIC IPC347G industrial rack PC intended for compatible factory computing, production monitoring, supervisory applications, and industrial data processing.

2. Which processor does it use?

This model belongs to the Core i5-6500 configuration family, featuring four cores, four threads, a 3.2 GHz base frequency, turbo speeds up to 3.6 GHz, and 6 MB cache.

3. How much memory does it support?

The model designation corresponds to the 32 GB memory configuration. Confirm the installed modules and memory arrangement when ordering.

4. Does it include an operating system?

No. The 0XX0 suffix identifies a configuration supplied without an operating system. Compatible software must be installed separately.

5. What storage is available?

The IPC347G family supports internal SATA storage options, including a 1 TB hard disk drive and solid-state drives. Confirm the storage fitted to this exact order number before purchase.

6. Which network interfaces are included?

The computer provides two Gigabit Ethernet interfaces for connecting to compatible industrial networks and other network-enabled equipment.

7. What display outputs are available?

It provides one DisplayPort and one VGA interface for compatible monitors and display equipment.

8. Which peripheral interfaces does it provide?

The system includes two front USB ports, four rear USB ports, two internal USB connections, two serial COM ports, two COM pin headers, two PS/2 connections, and audio interfaces.

9. What power supply does it require?

It uses a 350 W industrial power supply with a 100–240 V AC input range. The power supply cable is not included.

10. What environmental requirements should be considered?

The IPC347G family is specified for operation from 5–40 °C with IP20 protection at the front and rear. Provide adequate airflow and protect the unit from water and excessive dust.
