Siemens 6AG4025-0DE30-0BA0 Powerful Industrial Box PC
Siemens 6AG4025-0DE30-0BA0 Powerful Industrial Box PC
0.0
Points
Brand:Siemens Item No.:6AG4025-0DE30-0BA0 Product Origin: Germany Product Dimensions:260 × 135 × 225 mm Product Weight:14 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens SIMATIC IPC527G is an industrial Box PC designed for automation engineers, machine builders, and system integrators who need a flexible computing platform for industrial environments.
The 6AG4025-0DE30-0BA0 configuration combines an Intel Core i7-6700 processor, 16 GB DDR4 memory, and a 256 GB SSD. Its Ethernet, serial, USB, and display interfaces facilitate integration with compatible industrial equipment, monitoring systems, and machine-level applications.
Supplied without a preinstalled operating system, the unit gives system integrators flexibility when preparing the software environment. Its PCI Express expansion capability also supports selected application-specific hardware.
For new installations, verify software compatibility, operating temperature requirements, and the availability of replacement components before finalizing the system design.
Technical Specifications
Specification
Details
Manufacturer
Siemens
Product family
SIMATIC IPC527G
Product type
Industrial Box PC
Order number
6AG4025-0DE30-0BA0
Processor
Intel Core i7-6700
Processor cores
4
Processor threads
8
Base frequency
3.4 GHz
Maximum turbo frequency
Up to 4.0 GHz
Processor cache
8 MB
Installed memory
16 GB DDR4
Storage
256 GB SSD
Preinstalled operating system
None
Ethernet
2 × Gigabit Ethernet
Display interfaces
1 × DisplayPort, 1 × VGA
USB interfaces
4 × USB 3.0; internal USB 2.0 availability depends on configuration
Serial interfaces
2 × configurable RS232/RS485/RS422
Expansion slot
1 × PCIe x16
Power supply
100/240 V AC, autoranging, 50/60 Hz
Protection rating
IP20
Operating temperature
0°C to 45°C
Storage temperature
-20°C to 60°C
Dimensions (W × H × D)
Approximately 260 × 135 × 225 mm
Installation options
Desktop, wall, portrait
Power cable
Confirm inclusion with the supplier
Recommended Companion Models
Model
Product name
Typical application
6AG4025-0CE30-0BA0
SIMATIC IPC527G, Core i5-6500, 16 GB RAM, 256 GB SSD, no OS
Flexible mounting options: The IPC527G platform supports desktop, wall, and portrait installation.
Operating-system flexibility: The configuration without a preinstalled operating system allows integrators to select a suitable software environment.
Technical FAQs
1. What is the Siemens 6AG4025-0DE30-0BA0?
It is a Siemens SIMATIC IPC527G industrial Box PC configured with an Intel Core i7-6700 processor, 16 GB DDR4 memory, and a 256 GB SSD.
2. Which processor does this model use?
It uses the Intel Core i7-6700, a four-core processor with a base frequency of 3.4 GHz, a maximum turbo frequency of 4.0 GHz, and 8 MB of cache.
3. How much memory is installed?
This configuration includes 16 GB of DDR4 memory, supporting multitasking and industrial application workloads.
4. What storage capacity does it provide?
The unit is configured with a 256 GB solid-state drive for application files, system software, and local data storage.
5. Does the device include a preinstalled operating system?
No. This configuration is supplied without a preinstalled operating system. The selected operating system and drivers should be validated against the intended application.
6. Which Ethernet interfaces are available?
The IPC527G configuration includes two Gigabit Ethernet interfaces for industrial networking and communication with compatible devices.
7. Which display connections does it support?
It provides one DisplayPort and one VGA interface for connecting compatible displays.
8. Can the unit communicate with serial industrial equipment?
Yes. The standard platform supports two configurable RS232/RS485/RS422 interfaces. Confirm the selected interface mode and electrical requirements before connecting equipment.
9. Can expansion cards be installed?
Yes. This configuration provides one PCIe x16 expansion slot for compatible hardware. Check the card's dimensions, power requirements, and driver compatibility before installation.
10. What should be verified before purchasing?
Confirm the complete order number, processor, memory, storage capacity, operating-system status, expansion slots, power requirements, and included accessories to ensure the unit matches the intended application.
