Product Overview and Engineering Design
The Siemens SIMATIC IPC527G is an industrial Box PC platform intended for automation, machine monitoring, industrial visualization, and system integration. Its combination of computing capability and industrial connectivity makes it suitable for applications requiring communication between software systems, industrial networks, and connected equipment.
The 6AG4025-0DF10-0BB0 designation could not be matched conclusively to a specific hardware configuration. Consequently, the specifications below distinguish family-level characteristics from details that still require verification. This approach helps avoid selecting a unit with the wrong processor, storage capacity, or operating-system configuration.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | Siemens |
| Product family | SIMATIC IPC527G |
| Product type | Industrial Box PC |
| Order number | 6AG4025-0DF10-0BB0 |
| Processor | Requires exact model verification |
| Installed memory | Requires verification |
| Memory technology | DDR4 |
| Maximum family memory | Up to 32 GB |
| Storage | HDD/SSD configuration requires verification |
| Operating system | Requires verification |
| Ethernet | 2 × Gigabit Ethernet standard; third port optional on supported configurations |
| Display interfaces | 1 × DisplayPort, 1 × VGA |
| USB | 4 × USB 3.0; USB 2.0 availability depends on configuration |
| Serial interfaces | Configurable RS232/RS485/RS422; exact configuration requires verification |
| Expansion | PCI/PCI Express options depend on configuration |
| Power supply | IPC527G family: 100/240 V AC, 50/60 Hz |
| Protection rating | IP20 for the family |
| Operating temperature | Confirm against the exact configuration |
| Storage temperature | Confirm against the exact configuration |
| Dimensions | Family reference: approximately 260 × 135 × 225 mm |
| Mounting options | Desktop, wall, and portrait, subject to configuration |
| Power cable | Verify inclusion before ordering |
Recommended Companion Models
| Model | Product name | Typical application |
|---|
| 6AG4025-0DE20-6CA0 | SIMATIC IPC527G, Core i7-6700, 8 GB RAM, 256 GB SSD, Windows 10 IoT Enterprise LTSC 2019 | Windows-based industrial computing |
| 6AG4025-0CE20-5CA0 | SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 256 GB SSD, Windows 10 IoT Enterprise LTSC 2019 | Industrial visualization and automation |
| 6AG4025-0DF20-4BB0 | SIMATIC IPC527G, Core i7-6700, 8 GB RAM, 512 GB SSD, Windows 10 Enterprise 2016 LTSB | Alternative storage configuration |
| 6AG4025-0CB20-0BB0 | SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 1 TB HDD, no OS | Industrial applications using HDD storage |
Frequently Considered Alternatives
| Model | Product name | Main difference |
|---|
| 6AG4025-0AB10-0BB0 | SIMATIC IPC527G, Pentium G4400, 4 GB RAM, 1 TB HDD, no OS | Entry-level processor configuration |
| 6AG4025-0AB20-0CA0 | SIMATIC IPC527G, Pentium G4400, 8 GB RAM, 1 TB HDD, no OS | Higher-memory Pentium configuration |
| 6AG4025-0CE20-3BB0 | SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 256 GB SSD, Windows 10 Enterprise 2016 LTSB | Alternative processor and operating system |
| 6AG4025-0DE20-6CA0 | SIMATIC IPC527G, Core i7-6700, 8 GB RAM, 256 GB SSD, Windows 10 IoT Enterprise LTSC 2019 | i7 configuration with a preinstalled OS |
Technical FAQs
1. What is the Siemens 6AG4025-0DF10-0BB0?
The model number appears to belong to the Siemens SIMATIC IPC527G product-number family, but its exact configuration could not be independently confirmed. Verify the complete order number before purchasing.
2. Which processor does this model use?
The IPC527G family includes Intel Pentium G4400, Core i5-6500, and Core i7-6700 processor configurations. The processor installed in this specific model requires confirmation.
3. How much memory does it support?
The IPC527G family supports DDR4 memory, with configurations ranging from 4 GB to 16 GB and family-level support for up to 32 GB. The installed memory for this order number remains unverified.
4. What storage capacity does it provide?
Storage varies by configuration, with HDD and SSD options available across the IPC527G range. Confirm the exact drive type and capacity for this model.
5. Does it include a preinstalled operating system?
Operating-system availability depends on the individual configuration. Confirm whether the unit is supplied without an operating system or with a supported Windows version.
6. Which network interfaces are available?
The IPC527G family provides two Gigabit Ethernet ports as standard, with an additional Ethernet interface available on certain configurations.
7. Which display interfaces does the platform support?
The IPC527G family includes one DisplayPort and one VGA interface.
8. Can it communicate with serial industrial equipment?
The platform supports configurable RS232, RS485, and RS422 interfaces. The exact interface count and configuration should be checked against the device specification.
9. Does the IPC527G support expansion cards?
Yes. Depending on the configuration, the platform supports PCI and PCI Express expansion. Confirm the available slots before selecting additional hardware.
10. What should be verified before ordering?
Verify the complete order number, processor, installed memory, storage, operating system, expansion slots, power requirements, and included accessories.
