Name: Siemens 6AG4025-0DF20-2BB0 High-Performance Industrial Box PC
Brand: Siemens
SKU: 22760
Availability: InStock
Rating: 5.0 (1 reviews)

Product Overview and Industrial Design

The Siemens SIMATIC IPC527G is an industrial Box PC designed for automation engineering, machine monitoring, and industrial computing applications. Model 6AG4025-0DF20-2BB0 combines an Intel Core i7-6700 processor with 8 GB of DDR4 memory and a 512 GB SSD.

Its broad selection of interfaces supports integration with industrial networks, serial devices, displays, and expansion hardware. The preinstalled Windows 7 Ultimate 64-bit operating system can be relevant for established installations that rely on legacy software, provided application and driver compatibility is confirmed.

For new deployments, users should also consider Windows 7's end-of-support status and the security requirements of the intended environment. Isolated industrial networks and appropriate compensating security controls may be necessary where legacy software must remain in service.

Technical Specifications

Specification	Details
Manufacturer	Siemens
Product family	SIMATIC IPC527G
Product type	Industrial Box PC
Order number	6AG4025-0DF20-2BB0
Processor	Intel Core i7-6700
Processor cores / threads	4 cores / 8 threads
Base frequency	3.4 GHz
Maximum turbo frequency	Up to 4.0 GHz
Cache	8 MB
Chipset	Intel H110
Installed memory	8 GB DDR4
Maximum family memory	Up to 32 GB
Storage	512 GB internal SSD
Operating system	Windows 7 Ultimate 64-bit, MUI
Ethernet	2 × Gigabit Ethernet (IE/PN)
Display interfaces	1 × DisplayPort, 1 × VGA
USB interfaces	4 × USB 3.0, 2 × USB 2.0 listed externally
Configurable serial interfaces	2 × RS232/RS485/RS422
Additional serial interfaces	2 × RS232
Digital I/O	1 × 8-bit DIO
Expansion slots	2 × PCI, 1 × PCIe x16, 1 × PCIe x1
Power supply	100/240 V AC, autoranging, 50/60 Hz
Power cable	Not included in the listed configuration
Protection rating	IP20
Dimensions (W × H × D)	Approximately 260 × 135 × 225 mm
Mounting options	Desktop, wall, portrait
Operating temperature	Confirm installation requirements against the applicable technical documentation

Recommended Companion Models

Model	Product name	Typical application
6AG4025-0DF20-4BB0	SIMATIC IPC527G, Core i7-6700, 8 GB RAM, 512 GB SSD, Windows 10 Enterprise 2016 LTSB	Similar hardware with a different operating system
6AG4025-0DE20-6CA0	SIMATIC IPC527G, Core i7-6700, 8 GB RAM, 256 GB SSD, Windows 10 IoT Enterprise LTSC 2019	Windows 10 IoT-based industrial computing
6AG4025-0CE20-2BB0	SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 256 GB SSD, Windows 7 Ultimate 64-bit	Windows 7 configuration with a different processor
6AG4025-0CE20-3BB0	SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 256 GB SSD, Windows 10 Enterprise 2016 LTSB	Alternative processor and operating-system configuration

Frequently Considered Alternatives

Model	Product name	Main difference
6AG4025-0CB20-2BB0	SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 1 TB HDD, Windows 7 Ultimate 64-bit	Larger HDD capacity and a different processor
6AG4025-0CB20-0BB0	SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 1 TB HDD, no OS	HDD-based configuration without a preinstalled OS
6AG4025-0CE20-5CA0	SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 256 GB SSD, Windows 10 IoT Enterprise LTSC 2019	Windows 10 IoT configuration
6AG4025-0DF20-4BB0	SIMATIC IPC527G, Core i7-6700, 8 GB RAM, 512 GB SSD, Windows 10 Enterprise 2016 LTSB	Same processor and SSD capacity with a different OS

Industrial Applications and Use Cases

Industrial automation systems requiring dependable computing and local data processing.
Machine monitoring and production-line visualization.
Factory applications that rely on Windows-based industrial software.
Industrial networking and communication with compatible automation equipment.
Data acquisition and equipment monitoring using serial communication interfaces.
Industrial control systems requiring PCI and PCI Express expansion.
Legacy automation installations that depend on compatible Windows 7 applications.

Key Benefits and Features

Intel Core i7 processing: The Core i7-6700 processor supports industrial computing, visualization, and multitasking workloads.
8 GB DDR4 memory: Provides memory for compatible industrial software and system applications.
512 GB SSD storage: Offers solid-state storage for the operating system, applications, and local data.
Windows 7 Ultimate: Supplied with Windows 7 Ultimate 64-bit, MUI, for compatible legacy applications.
Industrial Ethernet connectivity: Two Gigabit Ethernet interfaces support communication with compatible industrial networks.
Versatile serial communication: Configurable RS232/RS485/RS422 interfaces support a range of industrial devices.
Expansion flexibility: PCI and PCI Express slots accommodate compatible expansion cards.
Flexible installation: Supports desktop, wall, and portrait mounting.

Technical FAQs

1. What is the Siemens 6AG4025-0DF20-2BB0?

It is a Siemens SIMATIC IPC527G industrial Box PC equipped with an Intel Core i7-6700 processor, 8 GB DDR4 memory, a 512 GB SSD, and Windows 7 Ultimate 64-bit.

2. Which processor does this model use?

It uses the Intel Core i7-6700, a four-core, eight-thread processor with a base frequency of 3.4 GHz, a maximum turbo frequency of 4.0 GHz, and 8 MB of cache.

3. How much memory is installed?

The system includes 8 GB of DDR4 memory and supports up to 32 GB at the IPC527G family level.

4. What storage capacity does it provide?

This configuration includes an internal 512 GB solid-state drive for system software, applications, and local data.

5. Which operating system is preinstalled?

The unit is supplied with Windows 7 Ultimate 64-bit, MUI. Compatibility with required applications, drivers, and security policies should be assessed before deployment.

6. Which Ethernet interfaces are available?

It includes two Gigabit Ethernet interfaces supporting industrial Ethernet and PROFINET-related connectivity.

7. Which display connections does it support?

The computer provides one DisplayPort and one VGA interface for compatible displays.

8. Which serial interfaces are available?

It includes two selectable RS232/RS485/RS422 interfaces and two additional RS232 interfaces for connecting compatible industrial equipment.

9. Can expansion cards be installed?

Yes. The configuration includes two PCI slots, one PCIe x16 slot, and one PCIe x1 slot. Confirm card dimensions, power requirements, and software compatibility before installation.

10. What should be checked before purchasing?

Confirm the complete order number, installed hardware, Windows 7 software requirements, expansion-card compatibility, power-cable inclusion, and the availability of replacement units or service support.
