Product Overview and Engineering Design
The Siemens SIMATIC IPC527G is an industrial Box PC platform designed for automation, machine monitoring, visualization, and industrial data processing. Its combination of network interfaces, serial connectivity, display outputs, and expansion options makes it suitable for a variety of industrial integration projects.
The 6AG4025-0DF20-4AA0 order number could not be matched conclusively to a specific hardware configuration. Therefore, the following specifications distinguish general IPC527G family capabilities from details that require confirmation. This is particularly important when a project depends on a specific processor, SSD capacity, operating-system version, or expansion-slot arrangement.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | Siemens |
| Product family | SIMATIC IPC527G |
| Product type | Industrial Box PC |
| Order number | 6AG4025-0DF20-4AA0 |
| Processor | Requires confirmation |
| Installed memory | Requires confirmation |
| Memory technology | DDR4 |
| Maximum family memory | Up to 32 GB |
| Storage | HDD or SSD; exact configuration requires confirmation |
| Operating system | Requires confirmation |
| Ethernet | 2 × Gigabit Ethernet standard |
| Display interfaces | 1 × DisplayPort, 1 × VGA |
| USB interfaces | 4 × USB 3.0; additional USB 2.0 availability depends on configuration |
| Serial interfaces | Configurable RS232/RS485/RS422, depending on configuration |
| Expansion slots | PCI/PCI Express options depend on configuration |
| Power supply | IPC527G family supports 100/240 V AC, 50/60 Hz |
| Protection rating | IP20 |
| Dimensions | Family reference: approximately 260 × 135 × 225 mm |
| Mounting options | Desktop, wall, and portrait, subject to configuration |
| Power cable | Verify inclusion with the supplier |
Recommended Companion Models
| Model | Product name | Typical application |
|---|
| 6AG4025-0DF20-2BB0 | SIMATIC IPC527G, Core i7-6700, 8 GB RAM, 512 GB SSD, Windows 7 Ultimate 64-bit | Legacy Windows industrial applications |
| 6AG4025-0DF20-4BB0 | SIMATIC IPC527G, Core i7-6700, 8 GB RAM, 512 GB SSD, Windows 10 Enterprise 2016 LTSB | Windows 10 industrial computing |
| 6AG4025-0DE20-6CA0 | SIMATIC IPC527G, Core i7-6700, 8 GB RAM, 256 GB SSD, Windows 10 IoT Enterprise LTSC 2019 | Industrial applications using Windows 10 IoT |
| 6AG4025-0CE30-0BA0 | SIMATIC IPC527G, Core i5-6500, 16 GB RAM, 256 GB SSD, no OS | Alternative processor configuration |
Frequently Considered Alternatives
| Model | Product name | Main difference |
|---|
| 6AG4025-0CB20-0BB0 | SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 1 TB HDD, no OS | HDD-based storage configuration |
| 6AG4025-0CE20-3BB0 | SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 256 GB SSD, Windows 10 Enterprise 2016 LTSB | Alternative processor and operating system |
| 6AG4025-0CE20-5CA0 | SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 256 GB SSD, Windows 10 IoT Enterprise LTSC 2019 | Windows 10 IoT configuration |
| 6AG4025-0AB20-0CA0 | SIMATIC IPC527G, Pentium G4400, 8 GB RAM, 1 TB HDD, no OS | Entry-level processor configuration |
Technical FAQs
1. What is the Siemens 6AG4025-0DF20-4AA0?
It appears to be associated with the Siemens SIMATIC IPC527G product family, but its exact configuration could not be independently confirmed. Verify the full order number before purchasing.
2. Which processor does this model use?
The IPC527G family includes Intel Pentium G4400, Core i5-6500, and Core i7-6700 configurations. The processor assigned to this exact order number requires confirmation.
3. How much memory does it have?
The IPC527G family supports DDR4 memory in several capacities, with up to 32 GB supported at the family level. The installed memory for this specific model remains unverified.
4. What storage options are available?
The IPC527G range includes configurations with HDD and SSD storage. The exact storage type and capacity of this model should be checked against its product specification.
5. Does it include a preinstalled operating system?
Operating-system availability depends on the specific configuration. Confirm whether the unit includes Windows or is supplied without an operating system.
6. Which network interfaces are available?
The IPC527G family provides two Gigabit Ethernet ports as standard, with a third port available on supported configurations.
7. Which display connections does it support?
The platform includes one DisplayPort and one VGA interface for compatible displays.
8. Can it communicate with serial industrial devices?
Yes. The IPC527G platform supports configurable RS232, RS485, and RS422 communication interfaces, depending on the configuration.
9. Can additional expansion cards be installed?
The platform supports PCI and PCI Express expansion options, depending on the selected configuration. Confirm the available slots before choosing additional hardware.
10. What should be verified before ordering?
Check the complete order number, processor, memory, storage, operating system, expansion slots, power requirements, and included accessories.
