Product Overview and Industrial Design
The Siemens SIMATIC IPC527G is an industrial Box PC designed for automation engineering, machine monitoring, industrial visualization, and local data processing.
The 6AG4025-0DF20-4BB0 configuration combines an Intel Core i7-6700 processor with 8 GB of DDR4 memory and a 512 GB SSD. Its range of communication interfaces supports integration with industrial networks, serial devices, displays, and compatible expansion hardware.
The included Windows 10 Enterprise 2016 LTSB operating system is suited to applications that require a consistent software environment. Because this is an older operating-system release, users should assess application compatibility, security requirements, and lifecycle considerations before deploying it in a new installation.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Siemens |
| Product family | SIMATIC IPC527G |
| Product type | Industrial Box PC |
| Order number | 6AG4025-0DF20-4BB0 |
| Processor | Intel Core i7-6700 |
| Processor cores / threads | 4 cores / 8 threads |
| Base frequency | 3.4 GHz |
| Maximum turbo frequency | Up to 4.0 GHz |
| Processor cache | 8 MB |
| Chipset | Intel H110 |
| Graphics | Integrated Intel HD Graphics 530/510, depending on processor configuration |
| Installed memory | 8 GB DDR4 |
| Maximum family memory | Up to 32 GB |
| Storage | 512 GB internal SSD |
| Operating system | Windows 10 Enterprise 2016 LTSB, 64-bit, MUI |
| Ethernet | 2 × Gigabit Ethernet (IE/PN), RJ45 |
| Display interfaces | 1 × DisplayPort, 1 × VGA |
| USB interfaces | 4 × USB 3.0, 2 × external USB 2.0 |
| Configurable serial interfaces | 2 × RS232/RS485/RS422 |
| Additional serial interfaces | 2 × RS232 |
| Digital I/O | 1 × 8-bit DIO |
| Expansion slots | 2 × PCI, 1 × PCIe x16, 1 × PCIe x1 |
| Power supply | 100/240 V AC, autoranging, 50/60 Hz |
| Power cable | Not included in the listed configuration |
| Protection rating | IP20 |
| Operating temperature | Confirm installation conditions against the applicable technical documentation |
| Storage temperature | -20°C to 60°C |
| Dimensions (W × H × D) | Approximately 260 × 135 × 225 mm |
| Net weight | Approximately 5.5 kg |
| Mounting options | Desktop, wall, portrait |
Recommended Companion Models
| Model | Product name | Typical application |
|---|---|---|
| 6AG4025-0DF20-2BB0 | SIMATIC IPC527G, Core i7-6700, 8 GB RAM, 512 GB SSD, Windows 7 Ultimate 64-bit | Legacy Windows industrial applications |
| 6AG4025-0DE20-6CA0 | SIMATIC IPC527G, Core i7-6700, 8 GB RAM, 256 GB SSD, Windows 10 IoT Enterprise LTSC 2019 | Industrial applications using Windows 10 IoT |
| 6AG4025-0CE20-3BB0 | SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 256 GB SSD, Windows 10 Enterprise 2016 LTSB | Alternative processor configuration |
| 6AG4025-0CE20-5CA0 | SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 256 GB SSD, Windows 10 Enterprise LTSC 2019 | Alternative Windows-based configuration |
Frequently Considered Alternatives
| Model | Product name | Main difference |
|---|---|---|
| 6AG4025-0DF20-2BB0 | SIMATIC IPC527G, Core i7-6700, 8 GB RAM, 512 GB SSD, Windows 7 Ultimate 64-bit | Same processor and storage with a different operating system |
| 6AG4025-0DE20-6CA0 | SIMATIC IPC527G, Core i7-6700, 8 GB RAM, 256 GB SSD, Windows 10 IoT Enterprise LTSC 2019 | Smaller SSD and Windows 10 IoT |
| 6AG4025-0CB20-0BB0 | SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 1 TB HDD, no OS | Alternative processor and HDD storage |
| 6AG4025-0CE30-0BA0 | SIMATIC IPC527G, Core i5-6500, 16 GB RAM, 256 GB SSD, no OS | Higher memory with a different processor and no preinstalled OS |
