Siemens 6AG4104-4AA01-0XX0 SIMATIC IPC547G Industrial Rack PC
Siemens 6AG4104-4AA01-0XX0 SIMATIC IPC547G Industrial Rack PC
0.0
Points
Brand:Siemens Item No.: 6AG4104-4AA01-0XX0 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 446.6 mm Product Weight:17 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG4104-4AA01-0XX0 is a SIMATIC IPC547G industrial rack PC configured for practical, cost-conscious industrial computing. Its Intel Pentium G4400 processor, 4 GB of DDR4 memory, and 1 TB internal hard drive provide a foundation for compatible monitoring, visualization, and production-support applications.
Designed around a 19-inch, 4U rack architecture, this system combines network connectivity with extensive hardware expansion options. Its seven expansion slots make it useful for installations that rely on dedicated interface cards, legacy PCI hardware, or additional PCI Express peripherals.
The model is supplied without an operating system, allowing system integrators to select suitable software for their application. For maintenance teams and industrial equipment buyers, confirming software compatibility and the availability of replacement components helps support a smoother deployment and longer service life.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Order Number
6AG4104-4AA01-0XX0
Product Family
SIMATIC IPC547G
Product Type
Industrial Rack PC
Processor
Intel Pentium G4400
CPU Configuration
2 cores / 2 threads
Processor Frequency
3.3 GHz
Cache
3 MB
Chipset
Intel H110
Installed Memory
4 GB DDR4 SDRAM
Memory Configuration
1 × 4 GB, single channel
Storage
1 × 1 TB internal HDD
Ethernet
2 × Intel Gigabit Ethernet
Front Interfaces
2 × USB 3.0
Rear USB Interfaces
2 × USB 3.0 and 4 × USB 2.0
Display Interfaces
1 × DVI-D, 1 × DisplayPort 1.2
Additional Interfaces
2 × PS/2, audio
Expansion Slots
5 × PCI Express, 2 × PCI
Graphics
Integrated processor graphics
Power Supply
100–240 V AC industrial power supply
Operating System
Not included
Mounting Format
19-inch rack, 4U
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Net Weight
Approximately 17 kg
Intended Applications
Industrial visualization, production monitoring, data acquisition, PC-based automation
- Factory Automation and Production Monitoring: Provides a centralized industrial computing platform for production monitoring, machine data collection, and PC-based automation applications, helping operators maintain visibility across manufacturing processes.
- Industrial Visualization and Supervisory Systems: Supports compatible HMI, visualization, and supervisory software, giving engineering teams a practical platform for presenting process information and monitoring equipment status.
- Machine Control and Data Acquisition: Offers PCI Express and PCI expansion capabilities for compatible interface cards, making it suitable for applications that require additional communication or data acquisition hardware.
- Industrial Network Integration: Dual Gigabit Ethernet interfaces support connections to industrial networks and other computing equipment, helping integrate the PC into established automation architectures.
- Production Data Management: The configured 1 TB internal hard drive provides storage for compatible industrial applications, operational records, and production data, subject to software and storage-management requirements.
Key Strengths at a Glance
- Configured for Industrial Computing: The Siemens SIMATIC IPC547G combines an Intel Pentium G4400 processor with 4 GB DDR4 memory for compatible industrial monitoring and computing workloads.
- Extensive Expansion Options: Seven expansion slots, comprising five PCI Express and two PCI slots, provide flexibility for compatible industrial interface cards and specialized hardware.
- Practical Network Connectivity: Two Intel Gigabit Ethernet interfaces support network integration, while front-accessible USB 3.0 ports simplify connections to service tools and compatible peripherals.
- Integrated Display Connectivity: The onboard graphics system provides DVI-D and DisplayPort outputs for supported displays and industrial visualization setups.
- Industrial Rack Compatibility: The 19-inch, 4U enclosure is suitable for organized installation in industrial racks and equipment cabinets.
- Built-In System Monitoring: Temperature and fan monitoring, watchdog functionality, and card retention features help support equipment supervision and stable operation in properly maintained installations.
Technical FAQs
1. What processor is installed in the Siemens 6AG4104-4AA01-0XX0?
This configuration uses an Intel Pentium G4400 dual-core processor running at 3.3 GHz, with two processing threads and 3 MB of cache. It is intended for compatible industrial computing workloads rather than demanding modern parallel-processing applications.
2. How much memory and storage does this model provide?
The specified configuration includes 4 GB of DDR4 SDRAM and one internal 1 TB hard disk drive. Application memory requirements and storage performance should be evaluated before deployment.
3. Which communication interfaces are available?
The system provides two Intel Gigabit Ethernet interfaces, two front USB 3.0 ports, rear USB ports, two PS/2 interfaces, and audio connections. The motherboard also includes DVI-D and DisplayPort video outputs.
4. Can this industrial PC communicate with Siemens PLCs?
Yes. It can communicate with compatible Siemens PLCs through supported Ethernet connections and suitable automation software. Protocol configuration, driver support, and software licensing must be checked for the specific PLC and application.
5. How many expansion cards can the IPC547G accommodate?
The specified platform provides seven expansion slots: five PCI Express slots and two conventional PCI slots. Check card dimensions, interface requirements, operating system drivers, and power consumption before installing additional hardware.
6. Does the 6AG4104-4AA01-0XX0 include a preinstalled operating system?
No. This order-number configuration is specified without an operating system. The purchaser must select a compatible operating system and ensure that the required drivers and industrial application software are supported.
7. Does this model support redundant power supplies?
The specified configuration includes a 100–240 V AC industrial power supply. Redundant power is an option on selected IPC547G configurations, but it should not be assumed to be present on this particular model.
8. Can the internal hard drive be replaced with an SSD?
A compatible storage upgrade may be possible, subject to the drive interface, physical mounting arrangement, firmware compatibility, and operating system requirements. Back up application data and verify the replacement drive before changing the original storage device.
9. What environmental conditions should be considered?
The IPC547G family is intended for controlled industrial environments. The standard enclosure has a published operating temperature range that depends on configuration and operating conditions; confirm the applicable limits and provide adequate ventilation before installation.
10. Is this model suitable for replacing an existing IPC547G system?
It may be suitable when the existing system has compatible hardware, software, and interface requirements. Confirm the complete order number, expansion cards, operating system, storage configuration, and connected equipment before treating it as a direct replacement.
