Siemens 6AG4104-4AA01-0XX3 SIMATIC IPC547G Industrial Rack PC
Siemens 6AG4104-4AA01-0XX3 SIMATIC IPC547G Industrial Rack PC
0.0
Points
Brand:Siemens Item No.:6AG4104-4AA01-0XX3 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 446.6 mm Product Weight:23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG4104-4AA01-0XX3 SIMATIC IPC547G is a rack-mounted industrial computer designed for established automation environments that require flexible expansion and reliable PC-based computing. Its Intel Pentium G4400 processor, 4 GB DDR4 memory, and 1 TB internal HDD provide a practical starting point for compatible production monitoring, visualization, and industrial data-processing applications.
The system combines dual Gigabit Ethernet connectivity with seven expansion slots, allowing integrators to connect compatible industrial peripherals and specialized interface cards. Its 19-inch, 4U rack format also supports organized installation in control cabinets and centralized computing enclosures.
Supplied without an operating system, this configuration gives system integrators flexibility when selecting software for a particular installation. Before ordering, verify the hardware configuration, Chinese power cable, software requirements, and availability of compatible replacement components to ensure the product meets the needs of the intended application.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Order Number
6AG4104-4AA01-0XX3
Product Family
SIMATIC IPC547G
Product Type
Industrial Rack PC
Processor
Intel Pentium G4400
CPU Configuration
2 cores / 2 threads
Processor Frequency
3.3 GHz
Cache
3 MB
Mainboard Chipset
Intel H110
Installed Memory
4 GB DDR4 SDRAM
Memory Arrangement
1 × 4 GB, single channel
Internal Storage
1 × 1 TB HDD
Ethernet Interfaces
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
2 × USB 3.0, 4 × USB 2.0
Display Interfaces
1 × DVI-D, 1 × DisplayPort 1.2
Other Interfaces
2 × PS/2, audio
Expansion Slots
5 × PCI Express, 2 × PCI
Graphics
Integrated graphics
Power Supply
100–240 V AC
Power Cable
China configuration
Operating System
Not included
Mounting Format
19-inch rack, 4U
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Net Weight
15–23 kg, depending on equipment
Typical Applications
Industrial visualization, production monitoring, data acquisition, PC-based automation
- Production Monitoring and Factory Automation: Provides an industrial computing platform for production monitoring, equipment status visualization, and compatible PC-based automation applications, helping operators maintain a clearer view of manufacturing operations.
- Industrial Data Acquisition: Supports compatible PCI Express and PCI interface cards for connecting specialized acquisition hardware, enabling application-specific collection and processing of industrial data.
- Machine Visualization and Supervisory Control: Offers a practical foundation for compatible HMI, SCADA, and supervisory applications, subject to operating system and software requirements.
- Industrial Network Communication: Dual Gigabit Ethernet interfaces support connections to factory networks, engineering systems, and compatible automation equipment.
- Centralized Rack-Based Computing: The 19-inch, 4U enclosure suits control rooms, industrial cabinets, and equipment racks where organized installation and expansion flexibility are important.
Key Strengths at a Glance
- Intel Pentium Processing: The IPC547G configuration associated with this model uses an Intel Pentium G4400 dual-core processor operating at 3.3 GHz, suitable for compatible industrial computing workloads.
- Flexible Expansion Architecture: Seven expansion slots—five PCI Express and two PCI—allow the system to accommodate compatible interface cards and application-specific peripherals.
- Integrated Network Connectivity: Two Intel Gigabit Ethernet ports support industrial network integration without requiring a separate network adapter for standard dual-port connectivity.
- Practical Storage Capacity: The associated configuration includes a 1 TB internal hard drive, providing storage for supported applications and operational data.
- Industrial Monitoring Features: Temperature and fan monitoring, watchdog functionality, and card retainers support system supervision and hardware stability.
- Configurable Software Deployment: The associated configuration is supplied without an operating system, allowing integrators to select compatible software for the intended installation.
Technical FAQs
1. Which processor is installed in the Siemens 6AG4104-4AA01-0XX3?
The specified configuration uses an Intel Pentium G4400 dual-core processor operating at 3.3 GHz, with two threads and 3 MB of cache. It is suitable for compatible industrial monitoring, visualization, and general-purpose computing applications.
2. How much memory and internal storage does the system provide?
The configured system includes 4 GB of DDR4 SDRAM in a single-channel arrangement and one internal 1 TB hard disk drive. Memory and storage requirements should be evaluated against the intended application workload.
3. Which communication interfaces are available?
The system provides two Intel Gigabit Ethernet interfaces, two front USB 3.0 ports, rear USB 3.0 and USB 2.0 ports, two PS/2 interfaces, and audio connections. Display connectivity includes DVI-D and DisplayPort 1.2.
4. Can this industrial PC communicate with SIMATIC PLCs?
Yes. It can communicate with compatible SIMATIC controllers through supported Ethernet interfaces and suitable automation software. Protocol configuration, driver availability, and software licensing must be checked for the target controller.
5. How many expansion cards can be installed?
The IPC547G platform provides seven expansion slots, comprising five PCI Express slots and two PCI slots. Compatibility depends on the card interface, slot configuration, physical clearance, power consumption, and driver support.
6. Is an operating system included with this model?
No. The specified configuration is supplied without an operating system. The selected operating system must be compatible with the hardware and support the required industrial application software and peripheral drivers.
7. Does the 6AG4104-4AA01-0XX3 support RAID?
The specified H110-based configuration should not be assumed to include the onboard RAID capabilities available on selected C236-based IPC547G variants. Confirm the storage controller and motherboard configuration before planning a RAID implementation.
8. Can the internal HDD be replaced with an SSD?
A compatible SSD upgrade may be possible, subject to the drive interface, mounting arrangement, firmware, and operating system requirements. Verify compatibility and back up important application data before replacing the original drive.
9. What power supply does the system require?
The specified model includes a 100–240 V AC industrial power supply. Confirm the local mains supply, protective grounding, connector arrangement, and supplied power cable before commissioning.
10. Is this model appropriate for continuous industrial operation?
It can support continuous-duty industrial computing applications when operated within its specified environmental and electrical limits. Adequate cooling, regular maintenance, storage monitoring, and stable software configuration remain important for dependable operation.
