Siemens 6AG4104-4AA01-3BX0 SIMATIC IPC547G Industrial Rack PC
Siemens 6AG4104-4AA01-3BX0 SIMATIC IPC547G Industrial Rack PC
0.0
Points
Brand:Siemens Item No.: 6AG4104-4AA01-3BX0 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 356.6 mm Product Weight:23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG4104-4AA01-3BX0 is associated with the SIMATIC IPC547G industrial rack PC family, a platform developed for PC-based automation and industrial computing environments. Its rack-mounted architecture, network connectivity, and expansion capabilities make this product family suitable for manufacturing systems that depend on centralized computing and equipment integration.
The IPC547G platform supports applications ranging from industrial visualization and production monitoring to specialized data acquisition and communication tasks. Its combination of PCI Express and PCI expansion slots offers flexibility when integrating compatible interface cards into established automation installations.
For industrial buyers, the most important consideration is matching the precise hardware configuration to the intended application. Confirming the processor, memory, storage, power supply, and operating system helps ensure appropriate performance, reliable integration, and manageable long-term maintenance.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Order Number
6AG4104-4AA01-3BX0
Product Family
SIMATIC IPC547G
Product Type
Industrial Rack PC
Mounting Format
19-inch rack, 4U
Processor
Exact configuration to be confirmed
Chipset
Configuration-dependent
Installed Memory
Exact capacity to be confirmed
Internal Storage
Depends on the supplied configuration
Ethernet Interfaces
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
Configuration-dependent USB 3.0 and USB 2.0 interfaces
Display Interfaces
DVI-D and DisplayPort on applicable configurations
Expansion Slots
5 × PCI Express, 2 × PCI
System Monitoring
Temperature and fan monitoring, watchdog
Power Supply
100–240 V AC; exact arrangement to be confirmed
Operating System
Depends on supplied configuration
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm, standard enclosure
Short-Enclosure Dimensions
481.4 × 176.6 × 356.6 mm, where applicable
Net Weight
15–23 kg, depending on equipment
Typical Applications
Industrial automation, visualization, production monitoring, data processing
- Industrial Production Monitoring: Supports compatible industrial software for equipment monitoring, production data review, and operational status visualization, helping manufacturing teams maintain better visibility across production processes.
- PC-Based Automation: Provides a rack-mounted computing platform for industrial applications that require communication with controllers, peripheral devices, and supervisory systems.
- Industrial Data Collection: Supports compatible expansion hardware for collecting and processing data from connected equipment, making it suitable for application-specific monitoring and reporting systems.
- Factory Network Integration: Ethernet connectivity supports integration with industrial networks and engineering workstations, subject to the installed hardware and software configuration.
- Control Room Computing: The rack-mounted design suits centralized installations where industrial computing hardware must be organized alongside network equipment and automation components.
Key Advantages
- Industrial Rack Architecture: The SIMATIC IPC547G platform uses a 19-inch, 4U enclosure designed for integration into industrial racks and equipment cabinets.
- Expansion Flexibility: The platform supports five PCI Express slots and two PCI slots, allowing compatible communication, acquisition, and specialized interface cards to be installed.
- Integrated Network Connectivity: Dual Gigabit Ethernet interfaces support connections to factory networks and compatible industrial computing systems.
- Hardware Monitoring Features: Temperature and fan monitoring, watchdog functionality, and card retainers help support system supervision and operational stability.
- Application-Oriented Configuration: Processor, memory, storage, operating system, and power supply options vary by order number, allowing buyers to select a configuration appropriate to their industrial workload.
Technical FAQs
1. What is the primary function of the Siemens 6AG4104-4AA01-3BX0?
It is identified within the SIMATIC IPC547G industrial rack PC order-number family. The platform is designed for industrial computing tasks such as production monitoring, visualization, data processing, and PC-based automation.
2. Which processor is installed in this configuration?
The exact processor assigned to order number 6AG4104-4AA01-3BX0 requires confirmation against the complete product configuration. Processor specifications should be verified before selecting the system for a workload with defined performance requirements.
3. What communication interfaces does the IPC547G platform support?
The platform provides two Intel Gigabit Ethernet interfaces, front USB 3.0 ports, rear USB connections, PS/2 interfaces, and audio connectivity. The exact rear interface arrangement can vary with the motherboard configuration.
4. Can this industrial PC communicate with Siemens PLCs?
Yes. Compatible SIMATIC PLCs can communicate with the PC through supported Ethernet connections and suitable automation software. Protocol configuration, driver availability, and software licensing should be checked for the target controller.
5. How many expansion cards can the system accommodate?
The IPC547G platform provides seven expansion slots, comprising five PCI Express slots and two PCI slots. Actual card compatibility depends on the motherboard, slot arrangement, electrical requirements, and available operating system drivers.
6. Does the system support hardware monitoring?
Yes. The platform includes temperature and fan monitoring, watchdog functionality, and card retainers. These features help with system supervision and hardware management when supported by the installed configuration and software.
7. Which operating systems are compatible with the IPC547G?
Compatibility depends on the installed processor, chipset, drivers, and supplied software configuration. Confirm the supported operating system and application requirements before commissioning the PC.
8. Can the internal storage be upgraded?
Storage upgrades may be possible using compatible HDD or SSD hardware, depending on the installed drive arrangement and controller. Verify interface compatibility, mounting requirements, firmware support, and data-backup procedures before making changes.
9. What power supply arrangements are supported?
The IPC547G family supports 100–240 V AC power supplies, with redundant power supply options available on selected configurations. The exact power arrangement must be confirmed for the specific order number.
10. What should be checked before purchasing this model as a replacement?
Verify the complete order number, processor, memory, storage, power supply, operating system, expansion cards, and peripheral connections. Matching the IPC547G family name alone does not guarantee direct hardware or software interchangeability.
