Siemens 6AG4104-4AA01-3XX3 SIMATIC IPC547G Industrial Rack PC
Siemens 6AG4104-4AA01-3XX3 SIMATIC IPC547G Industrial Rack PC
0.0
Points
Brand:Siemens Item No.: 6AG4104-4AA01-3XX3 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 356.6 mm Product Weight:17 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG4104-4AA01-3XX3 is associated with the SIMATIC IPC547G industrial rack PC family, a platform designed for PC-based automation and industrial computing environments. Its rack-mounted architecture, network connectivity, and expansion flexibility make the family suitable for applications that require centralized computing and integration with established industrial equipment.
The IPC547G platform supports production monitoring, industrial visualization, data processing, and specialized applications using compatible expansion hardware. Its combination of PCI Express and conventional PCI slots provides flexibility for installations that rely on additional communication interfaces or dedicated industrial peripherals.
For system integrators and maintenance teams, selecting the correct hardware configuration is essential. Confirming the processor, memory, storage, operating system, and power supply associated with the complete order number helps ensure that the system meets application requirements and can be integrated efficiently.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Order Number
6AG4104-4AA01-3XX3
Product Family
SIMATIC IPC547G
Product Type
Industrial Rack PC
Mounting Format
19-inch rack, 4U
Processor
Exact configuration requires confirmation
Chipset
Configuration-dependent
Installed Memory
Configuration-dependent
Internal Storage
Configuration-dependent
Ethernet Interfaces
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
Configuration-dependent USB 3.0 and USB 2.0 ports
Display Interfaces
DVI-D and DisplayPort on applicable configurations
Expansion Slots
5 × PCI Express, 2 × PCI
System Monitoring
Temperature and fan monitoring, watchdog
Power Supply
100–240 V AC; exact arrangement to be confirmed
Operating System
Depends on supplied configuration
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm, standard enclosure
Short-Enclosure Dimensions
481.4 × 176.6 × 356.6 mm, where applicable
Net Weight
Approximately 17 kg for the standard platform; verify the exact configuration
Typical Applications
Industrial automation, visualization, production monitoring, and data processing
- Manufacturing Process Monitoring: Supports compatible industrial software for production monitoring, equipment status visualization, and operational data management, helping engineering teams maintain a clearer view of manufacturing activities.
- Industrial Automation Computing: Provides a rack-mounted computing platform for PC-based automation tasks that require connections to controllers, industrial peripherals, and supervisory systems.
- Data Acquisition and Equipment Integration: Supports compatible PCI Express and PCI interface cards for connecting specialized hardware used in industrial data collection, communication, and equipment monitoring.
- Factory Network Connectivity: Dual Gigabit Ethernet interfaces support communication with compatible industrial networks, engineering workstations, and production information systems.
- Centralized Control Room Applications: The 19-inch rack architecture enables organized installation alongside network equipment and other industrial computing components.
Key Advantages
- Industrial Rack-Mount Design: The SIMATIC IPC547G platform features a 4U enclosure suitable for industrial cabinets, control rooms, and centralized computing installations.
- Flexible Expansion Architecture: Five PCI Express slots and two PCI slots support a broad range of compatible communication cards and application-specific peripherals.
- Integrated Ethernet Connectivity: Dual Intel Gigabit Ethernet interfaces simplify integration with established industrial networks and connected computing systems.
- Hardware Monitoring Capabilities: Temperature and fan monitoring, watchdog functionality, and card retainers support system supervision and operational reliability.
- Configurable Computing Resources: Processor, memory, storage, and software options across the IPC547G family allow installations to be tailored to their workload and maintenance requirements.
- Practical Maintenance and Integration: The familiar PC architecture simplifies integration with compatible industrial software and makes hardware configuration easier to manage throughout the system lifecycle.
Technical FAQs
1. What is the primary function of the Siemens 6AG4104-4AA01-3XX3?
It belongs to the SIMATIC IPC547G industrial rack PC product family, which is designed for industrial computing, visualization, production monitoring, and PC-based automation applications.
2. Which processor is installed in this model?
The exact processor configuration for order number 6AG4104-4AA01-3XX3 should be confirmed before purchase. The IPC547G family includes Intel Pentium and Core-series processor configurations, depending on the selected order number.
3. Which network interfaces are available on the IPC547G platform?
The platform provides two Intel Gigabit Ethernet interfaces. These support connections to compatible industrial networks, engineering systems, and supervisory applications.
4. Can this industrial PC communicate with Siemens PLCs?
Yes. Compatible Siemens PLCs can communicate with the PC through supported Ethernet interfaces and appropriate automation software. Protocol support, drivers, and licensing depend on the selected application.
5. What expansion options does the system provide?
The IPC547G platform offers seven expansion slots, comprising five PCI Express slots and two PCI slots. Card compatibility depends on the motherboard configuration, available bandwidth, electrical requirements, and driver support.
6. Does the system include hardware monitoring functions?
The IPC547G platform supports temperature and fan monitoring, watchdog functionality, and card retainers. These features help operators supervise system conditions and manage installed expansion hardware.
7. Which operating systems can be used?
Operating system compatibility depends on the installed processor, chipset, drivers, and supplied configuration. Confirm software support and licensing before deploying industrial automation or visualization applications.
8. Can the storage configuration be upgraded?
Compatible HDD and SSD upgrades may be possible, depending on the installed drive arrangement and storage controller. Check interface compatibility, mounting requirements, and data migration procedures before modifying the system.
9. What power supply arrangements are available?
The IPC547G family supports 100–240 V AC power supplies, with redundant power options available on selected configurations. Verify the power supply installed in the exact unit before connecting it to the facility electrical system.
10. What should be checked before ordering a replacement unit?
Verify the complete order number, processor, memory, storage, power supply, operating system, expansion cards, and peripheral connections. This helps prevent compatibility problems when replacing an existing industrial computer.
