Siemens 6AG4104-4AA02-0BX3 SIMATIC IPC547G Industrial Rack PC

Where It Excels in Industrial Use

• Factory automation: Supports production monitoring, machine-related applications, and industrial control software.
• HMI and SCADA systems: Provides a platform for operator interfaces and supervisory applications.
• Industrial data processing: Handles operational data collection, reporting, and process visualization.
• Machine vision integration: Can accommodate compatible expansion cards and supporting software.
• Legacy system maintenance: Supports continued operation of compatible installations built around older Windows-based applications.
• Control room installations: Its 19-inch rack format simplifies integration into industrial cabinets and equipment racks.

Advantages

Key Strengths at a Glance

• Intel Core i5 processing: The four-core, four-thread Core i5-6500 operates at 3.2 GHz, with a maximum turbo frequency of 3.6 GHz.
• Industrial rack construction: The 4U chassis is designed for installation in standard 19-inch equipment racks.
• Flexible expansion: Seven expansion slots provide five PCI Express slots and two PCI slots.
• Dual Gigabit Ethernet: Two Intel Gigabit Ethernet interfaces support network connectivity.
• Multiple display connections: The H110 motherboard configuration provides DisplayPort 1.2 and DVI-D outputs.
• Integrated optical drive: A slim DVD±RW drive supports compatible optical media.
• Windows 7 platform: The supplied Windows 7 Ultimate 64-bit environment can support applications designed for that operating system.
• Industrial monitoring: Temperature and fan monitoring, watchdog functionality, and card retention support system operation.

Technical FAQs

Q1: What is the Siemens 6AG4104-4AA02-0BX3?

It is a Siemens SIMATIC IPC547G industrial rack PC configured with an Intel Core i5-6500 processor, 4 GB DDR4 memory, a 1 TB hard disk drive, and Windows 7 Ultimate 64-bit.

Q2: What processor does this model use?

The system uses an Intel Core i5-6500 with four cores, four threads, a base frequency of 3.2 GHz, a maximum turbo frequency of 3.6 GHz, and 6 MB cache.

Q3: How much memory is installed?

The specified configuration includes 4 GB DDR4 SDRAM installed as a single 4 GB module. Confirm the motherboard's supported memory configuration before upgrading.

Q4: What storage does the IPC547G include?

This configuration includes one internal 1 TB hard disk drive. Check the installed drive and its condition before reusing the computer in a production environment.

Q5: Which operating system is supplied?

The specified configuration includes Windows 7 Ultimate, 64-bit, with a multilingual interface. Application and driver compatibility should be checked before migrating or reinstalling the system.

Q6: What network interfaces are available?

The IPC547G family provides two Intel Gigabit Ethernet interfaces for industrial network connections and communication with other equipment.

Q7: Which display outputs are provided?

The H110-based configuration includes one DisplayPort 1.2 output and one DVI-D output, using onboard graphics.

Q8: How many expansion cards can the system accommodate?

The chassis provides seven expansion slots: five PCI Express and two PCI. Actual card compatibility depends on card dimensions, interface type, power requirements, and the installed configuration.

Q9: What power supply does this model use?

The IPC547G family supports an industrial AC power supply rated for 100–240 V AC. Confirm the installed power supply and the correct regional power cable before connecting the system.

Q10: What should be checked before replacing this computer?

Verify the processor, memory, storage, operating system, expansion cards, display connections, network interfaces, power supply, and chassis dimensions. Particular attention should be paid to legacy software and hardware compatibility.
