Brand:Siemens Item No.:6AG4104-4AA02-0XX1 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 446.6 mm Product Weight:23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens SIMATIC IPC547G is designed for industrial computing environments where expansion flexibility, network connectivity, and rack integration are important. Its 4U chassis and broad selection of interface options make the platform suitable for production monitoring, visualization systems, industrial data processing, and specialized automation applications.
The 6AG4104-4AA02-0XX1 model should be identified using its complete order number and equipment label. Although the IPC547G family specifications provide a useful reference, the processor, installed memory, storage capacity, operating system, and optional hardware should not be inferred solely from the family name.
When sourcing this unit for maintenance or system integration, compare its installed configuration with the requirements of the application. This helps ensure that replacement hardware supports the existing software, communication interfaces, and expansion cards.
Technical Specifications
Parameter
Specification
Brand
Siemens
Product family
SIMATIC IPC547G
Model number
6AG4104-4AA02-0XX1
Product type
Industrial Rack PC
Form factor
19-inch, 4U
Processor
Exact configuration requires verification
Memory
Exact capacity requires verification
Storage
Type and capacity require verification
Front USB interfaces
2 × USB 3.0
Ethernet
2 × Intel Gigabit Ethernet
Other interfaces
Family-level configuration includes 2 × PS/2 and audio
Expansion slots
Family configuration: 5 × PCI Express, 2 × PCI
Monitoring
Temperature and fan monitoring
Watchdog
Supported by the IPC547G family
Power supply
100–240 V AC; confirm installed supply and options
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm for the standard enclosure
Weight
15–23 kg, depending on equipment
Operating system
Requires configuration verification
Installation
Rack-mounted; horizontal or vertical installation supported by the family
The dimensions and weight shown are family-level specifications for the standard enclosure. Confirm the exact configuration and enclosure variant before planning installation or shipment.
Industrial automation: Runs compatible applications for machine monitoring, production coordination, and factory operations.
HMI and SCADA: Supports operator interfaces, supervisory control, and process visualization.
Data acquisition: Provides a computing platform for collecting, processing, and displaying production data.
Industrial networking: Connects to Ethernet-based automation equipment and plant information systems.
Legacy equipment integration: Expansion slots can accommodate compatible interface cards used in established installations.
Control-room computing: The rack-mounted chassis fits standard industrial cabinets and equipment racks.
Advantages
Key Strengths at a Glance
19-inch rack design: A 4U enclosure suited to industrial cabinets and control rooms.
Flexible expansion: The IPC547G family supports five PCI Express slots and two PCI slots.
Dual Ethernet connectivity: Two Intel Gigabit Ethernet interfaces support industrial network communication.
Front-access USB: Two front-facing USB 3.0 ports simplify connection of service devices and peripherals.
Industrial monitoring: Temperature and fan monitoring help operators assess system conditions.
Watchdog functionality: Supports monitoring of application or system operation.
Configurable hardware: Processor, memory, storage, and software options vary by order number.
Multiple installation options: The family supports horizontal or vertical installation and can be prepared for telescopic rails.
Technical FAQs
Q1: What is the Siemens 6AG4104-4AA02-0XX1?
It is an order number associated with the Siemens SIMATIC IPC547G industrial rack PC family. The exact hardware configuration should be confirmed before ordering.
Q2: What applications can the IPC547G support?
It can support compatible industrial automation, HMI, SCADA, production monitoring, and data-processing applications.
Q3: What type of enclosure does the IPC547G use?
The IPC547G uses a 19-inch, 4U rack-mount enclosure designed for industrial equipment racks and control cabinets.
Q4: How many expansion slots are available?
The family provides seven expansion slots: five PCI Express and two PCI. Check the installed configuration and card compatibility before adding hardware.
Q5: Does the IPC547G support Gigabit Ethernet?
Yes. The family includes two Intel Gigabit Ethernet interfaces for connecting to industrial networks and other Ethernet-enabled devices.
Q6: Which USB interfaces are available?
Two USB 3.0 ports are available on the front. Rear USB port types and quantities depend on the motherboard configuration.
Q7: Does the system support hardware monitoring?
The IPC547G family includes temperature and fan monitoring, watchdog functionality, and a card-retention mechanism.
Q8: Can additional interface cards be installed?
Yes, provided the card is compatible with the available PCI Express or PCI slots, the operating system, and the system's electrical and mechanical requirements.
Q9: What power supply does the IPC547G use?
The family supports a 100–240 V AC power supply, with redundant power supply options available on selected configurations. Verify the installed supply before connecting or replacing the unit.
Q10: What should be checked before selecting a replacement?
Confirm the full order number, processor, RAM, storage, operating system, power supply, rear interfaces, expansion cards, and chassis dimensions. These details are important for maintaining compatibility with the existing industrial application.
