Siemens 6AG4104-4CA00-3BX0 – SIMATIC IPC547G Industrial Rack PC for Automation and Control
Siemens 6AG4104-4CA00-3BX0 – SIMATIC IPC547G Industrial Rack PC for Automation and Control
0.0
Points
Brand:Siemens Item No.: 6AG4104-4CA00-3BX0 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 356.6 mm Product Weight:23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG4104-4CA00-3BX0 is presented in the SIMATIC IPC547G industrial rack PC product context. The IPC547G family was designed for industrial computing applications that require rack-mounted installation, integrated networking, and flexible hardware expansion.
Its combination of PCI Express and conventional PCI slots supports a range of compatible industrial interface cards. Dual Gigabit Ethernet and system-monitoring functions further support its use in production monitoring, industrial data processing, and automation infrastructure.
For applications where rack depth is a concern, selected IPC547G configurations offer a short enclosure. This can help simplify integration into suitable industrial cabinets, provided that cooling, cabling, and maintenance clearances are properly planned.
Configuration note: The exact Siemens specification record for 6AG4104-4CA00-3BX0 could not be independently confirmed. The specifications below describe IPC547G family characteristics and distinguish them from order-specific details that remain unverified.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Product family
SIMATIC IPC547G
Product category
Industrial Rack PC
Order number
6AG4104-4CA00-3BX0
Form factor
19-inch, 4U rack computer
Enclosure type
Standard or short enclosure; exact variant not verified
Processor
Not verified for this exact order number
Motherboard chipset
Family variants include Intel H110 and Intel C236
Memory
DDR4 SDRAM; installed capacity not verified
Storage
HDD and SSD configurations available within the family
Ethernet
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
Configuration-dependent
Display interfaces
Common variants include DisplayPort 1.2 and DVI-D
Expansion slots
7 total: 5 × PCI Express and 2 × PCI
System monitoring
Temperature and fan monitoring
Watchdog
Supported at family level
Power supply
Family configurations support 100–240 V AC; exact arrangement not verified
Standard enclosure dimensions
Approximately 481.4 × 176.6 × 446.6 mm (W × H × D)
Short enclosure dimensions
Approximately 481.4 × 176.6 × 356.6 mm (W × H × D)
Weight
Approximately 15–23 kg across family configurations; exact unit weight not verified
Operating system
Configuration-dependent; exact installation not verified
Product lifecycle
Confirm current availability and service options for the exact order number
Recommended Related Models
The following Siemens models belong to the SIMATIC IPC547G family and have identifiable hardware configurations. They can serve as comparison options, but their specifications should be checked against the requirements of the intended installation.
Model
Product description
6AG4104-4AA05-3XX0
SIMATIC IPC547G with Intel Pentium G4400, 4 GB DDR4, 1 TB HDD, H110 chipset, and no preinstalled operating system
6AG4104-4CA01-0XX1
SIMATIC IPC547G with Intel Core i5-6500, 4 GB DDR4, 1 TB HDD, H110 chipset, and no preinstalled operating system
6AG4104-4AA12-2CC2
SIMATIC IPC547G with Intel Pentium G4400, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 10 Enterprise LTSB 2015
6AG4104-4EN16-3XX0
SIMATIC IPC547G with Intel Pentium G4400, C236 chipset, 8 GB DDR4, and RAID 1 using two 1 TB HDDs
6AG4104-4GA12-2DX1
SIMATIC IPC547G with Intel Core i5-6500, C236 chipset, 8 GB DDR4, 1 TB HDD, and a PCIe dual-head graphics card
Popular Related Models
Model
Product description
6AG4104-4CA00-0BX2
SIMATIC IPC547G with Intel Core i5-6500, H110 chipset, 4 GB RAM, 1 TB HDD, short enclosure, and Windows 7 Ultimate
6AG4104-4DA12-3BX2
SIMATIC IPC547G with Intel Core i7-6700, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 7 Ultimate
6AG4104-4GN16-4BX0
SIMATIC IPC547G with Intel Core i5-6500, 8 GB RAM, RAID 1 using two 1 TB HDDs, and Windows Server 2012 R2
6AG4104-4GK13-1BX2
SIMATIC IPC547G with Intel Core i5-6500, C236 chipset, 8 GB DDR4, 480 GB SSD, redundant AC power supplies, and Windows 7 Ultimate
6AG4104-4CA00-3XX2
SIMATIC IPC547G with Intel Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, short enclosure, and no preinstalled operating system
Applications
The Siemens SIMATIC IPC547G is a rack-mounted industrial computer platform designed for manufacturing, automation, and industrial data-processing environments. Its expansion flexibility, integrated Ethernet interfaces, and system-monitoring capabilities make it suitable for applications that require dependable computing and compatibility with established industrial equipment.
Typical application areas include:
Factory automation: Supporting production monitoring, machine supervision, and industrial control applications.
SCADA and HMI systems: Running compatible visualization software and operator-interface applications.
Industrial data processing: Collecting, analyzing, and storing production and machine data.
Industrial networking: Connecting automation equipment and supervisory systems through Gigabit Ethernet.
Machine vision and inspection: Supporting compatible image-processing applications through suitable expansion cards.
Legacy system maintenance: Replacing or maintaining industrial computers when existing software, interfaces, and hardware requirements must be preserved.
For installations with limited cabinet depth, selected IPC547G configurations feature a short enclosure. The enclosure type for the exact order number 6AG4104-4CA00-3BX0 should be confirmed before installation.
Advantages
Space-Efficient Industrial Installation
The IPC547G family uses a 19-inch, 4U rack-mount design. Selected configurations feature a shorter chassis, making them potentially suitable for cabinets where installation depth is restricted. Adequate ventilation and service clearance remain essential.
Flexible Expansion for Industrial Equipment
The platform provides seven expansion slots: five PCI Express and two conventional PCI. These slots support compatible communication cards, data-acquisition hardware, and other application-specific interfaces.
Integrated Network Connectivity
Two Intel Gigabit Ethernet interfaces support communication with connected industrial devices and network infrastructure. The platform also provides front USB connectivity and additional rear interfaces determined by the motherboard configuration.
Built-In System Monitoring
Temperature and fan monitoring, watchdog functionality, and card-retention provisions are features of the IPC547G family. These capabilities help support system supervision and routine maintenance.
Adaptable Computing Architecture
The IPC547G family was offered with different processors, memory capacities, storage arrangements, and operating systems. This flexibility helps support different industrial workloads, although the exact configuration must be verified before purchase.
Technical FAQs
Q1. What is the Siemens 6AG4104-4CA00-3BX0?
It is an order number presented in the context of the Siemens SIMATIC IPC547G industrial rack PC family. The complete configuration for this specific order number could not be independently confirmed, so the installed hardware should be verified before procurement.
Q2. Which processor does this model use?
The exact processor associated with 6AG4104-4CA00-3BX0 has not been verified. Other IPC547G variants use Intel Pentium, Core i5, and Core i7 processors, but these options should not be treated as confirmation of this particular model's CPU.
Q3. How many expansion slots does the IPC547G provide?
The family provides seven expansion slots: five PCI Express and two conventional PCI. Supported cards depend on the motherboard, slot configuration, electrical requirements, and driver compatibility.
Q4. Does the IPC547G support Gigabit Ethernet?
Yes. The IPC547G family includes two Intel Gigabit Ethernet interfaces. Network features depend on the installed operating system, drivers, and network configuration.
Q5. Which display interfaces are available?
Common configurations include DisplayPort 1.2 and DVI-D. The number and arrangement of display outputs vary with the motherboard, while optional graphics cards may add additional interfaces.
Q6. What type of memory does the IPC547G use?
The family uses DDR4 SDRAM. The installed capacity and supported memory arrangement depend on the specific configuration.
Q7. Can the IPC547G use SSD storage?
Yes. SSD and HDD storage options are available across the family. The exact drive type, capacity, mounting arrangement, and storage-controller configuration must be checked for the individual unit.
Q8. Does the IPC547G support RAID?
Selected configurations support RAID storage. The available RAID level and drive arrangement depend on the installed controller and storage hardware. RAID support should be verified rather than assumed.
Q9. Which operating systems can run on the IPC547G?
Operating-system compatibility depends on the installed hardware, drivers, and application requirements. Historical configurations were offered with different Windows editions or without a preinstalled operating system. Driver availability and software support should be assessed before deployment.
Q10. What should be checked before replacing an existing IPC547G?
Verify the complete order number, processor, motherboard, memory, storage arrangement, operating system, expansion cards, network interfaces, power supply, and chassis type. These details help prevent compatibility issues during installation and commissioning.
