Siemens 6AG4104-4CA01-0BX3 – SIMATIC IPC547G Industrial Rack PC for Automation Applications
Siemens 6AG4104-4CA01-0BX3 – SIMATIC IPC547G Industrial Rack PC for Automation Applications
0.0
Points
Brand:Siemens Item No.: 6AG4104-4CA01-0BX3 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 356.6 mm Product Weight:23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG4104-4CA01-0BX3 is associated with the SIMATIC IPC547G industrial rack PC product family. Designed for industrial computing installations, the IPC547G platform combines a rack-mounted enclosure with expansion flexibility, integrated network connectivity, and system-monitoring capabilities.
The platform can support production monitoring, industrial data processing, visualization, and communication with connected equipment. Its combination of PCI Express and conventional PCI expansion slots also allows compatible interface cards to be integrated for application-specific requirements.
For maintenance teams and system integrators, configuration matching is essential. Processor performance, memory capacity, storage architecture, operating-system installation, and peripheral interfaces can differ among IPC547G order numbers.
Configuration note: The exact specification record for 6AG4104-4CA01-0BX3 could not be independently confirmed. The specifications below therefore distinguish general IPC547G family characteristics from details that remain unverified for this specific order number.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Product family
SIMATIC IPC547G
Product category
Industrial Rack PC
Order number
6AG4104-4CA01-0BX3
Form factor
19-inch, 4U rack computer
Processor
Not verified for this exact order number
Motherboard chipset
IPC547G family variants include Intel H110 and Intel C236
Memory
DDR4 SDRAM; installed capacity not verified
Storage
HDD and SSD options available within the family
Ethernet
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
Configuration-dependent
Display interfaces
Common variants include DisplayPort 1.2 and DVI-D
Expansion slots
7 total: 5 × PCI Express and 2 × PCI
Monitoring functions
Temperature and fan monitoring
Watchdog
Supported at family level
Power supply
Family configurations support 100–240 V AC; exact arrangement not verified
Standard enclosure dimensions
Approximately 481.4 × 176.6 × 446.6 mm (W × H × D)
Short enclosure dimensions
Approximately 481.4 × 176.6 × 356.6 mm (W × H × D), where applicable
Weight
Approximately 15–23 kg across family configurations; exact unit weight not verified
Operating system
Configuration-dependent; exact installation not verified
Product lifecycle
Confirm availability and service options for the exact order number
Recommended Related Models
The following SIMATIC IPC547G configurations have identifiable hardware specifications and can be used for comparison. They are not necessarily direct replacements for 6AG4104-4CA01-0BX3.
Model
Product description
6AG4104-4AA05-3XX0
SIMATIC IPC547G with Intel Pentium G4400, 4 GB DDR4, 1 TB HDD, H110 chipset, and no preinstalled operating system
6AG4104-4CA01-0XX1
SIMATIC IPC547G with Intel Core i5-6500, 4 GB DDR4, 1 TB HDD, H110 chipset, and no preinstalled operating system
6AG4104-4AA12-2CC2
SIMATIC IPC547G with Intel Pentium G4400, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 10 Enterprise LTSB 2015
6AG4104-4EN16-3XX0
SIMATIC IPC547G with Intel Pentium G4400, C236 chipset, 8 GB DDR4, and RAID 1 using two 1 TB HDDs
6AG4104-4GA12-2DX1
SIMATIC IPC547G with Intel Core i5-6500, C236 chipset, 8 GB DDR4, 1 TB HDD, and a PCIe dual-head graphics card
Popular Related Models
Model
Product description
6AG4104-4DA12-3BX2
SIMATIC IPC547G with Intel Core i7-6700, H110 chipset, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 7 Ultimate
6AG4104-4GN16-4BX0
SIMATIC IPC547G with Intel Core i5-6500, 8 GB RAM, RAID 1 using two 1 TB HDDs, and Windows Server 2012 R2
6AG4104-4CA00-0BX2
SIMATIC IPC547G with Intel Core i5-6500, 4 GB RAM, 1 TB HDD, short enclosure, and Windows 7 Ultimate
6AG4104-4CA04-0BX0
SIMATIC IPC547G with Intel Core i5-6500, 4 GB DDR4, 1 TB HDD, redundant AC power supplies, DVD±RW, and Windows 7 Ultimate
6AG4104-4CA12-1DX1
SIMATIC IPC547G with Intel Core i5-6500, H110 chipset, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 10 Enterprise 2016 LTSB
Applications
The Siemens SIMATIC IPC547G is a 19-inch, 4U industrial rack computer designed for manufacturing, automation, and industrial data-processing environments. With integrated Ethernet connectivity, multiple expansion slots, and hardware-monitoring functions, the platform supports a wide range of industrial computing tasks.
Typical applications include:
Factory automation: Supporting production monitoring, machine supervision, and industrial control applications.
SCADA and HMI systems: Running compatible visualization software and operator-interface applications.
Industrial data processing: Collecting and processing information from manufacturing equipment and connected devices.
Industrial communication: Connecting automation systems through Ethernet and compatible expansion interfaces.
Machine inspection: Supporting suitable machine-vision and inspection applications with compatible hardware.
Legacy system maintenance: Providing a computing platform for existing installations where interface and software compatibility must be preserved.
For replacement projects, verify the full order number and installed configuration before purchasing. The exact hardware specification for 6AG4104-4CA01-0BX3 could not be independently confirmed.
Advantages
Reliable Rack-Mount Integration
The IPC547G family features a 19-inch, 4U enclosure designed for installation in industrial racks and control cabinets. Its standardized form factor supports integration into established automation infrastructure.
Flexible Expansion Capabilities
The platform provides seven expansion slots, comprising five PCI Express slots and two conventional PCI slots. Compatible expansion cards can add communication interfaces, data-acquisition capabilities, and specialized functions.
Integrated Ethernet Connectivity
Two Intel Gigabit Ethernet interfaces support communication with connected industrial equipment and network infrastructure. Additional USB, display, and peripheral connections depend on the installed motherboard and configuration.
Hardware Monitoring Features
Temperature and fan monitoring, watchdog functionality, and card-retention provisions are features of the IPC547G family. These capabilities support system supervision and help maintenance teams manage industrial computing equipment.
Configurable Industrial Computing
The IPC547G family was available in configurations with different processors, memory capacities, storage options, and operating systems. Selecting a suitable configuration can help maintain compatibility with existing applications and industrial peripherals.
Technical FAQs
Q1. What is the Siemens 6AG4104-4CA01-0BX3?
It is an order number in the SIMATIC IPC547G industrial rack PC context. The exact configuration associated with this complete order number has not been independently verified. Confirm the unit's rating plate or Siemens configuration record before procurement.
Q2. Which processor is installed in this model?
The processor for 6AG4104-4CA01-0BX3 remains unverified. Other IPC547G variants use Intel Pentium, Core i5, and Core i7 processors, but the CPU should not be assumed based on a similar order number.
Q3. How many expansion slots does the IPC547G provide?
The IPC547G family provides seven expansion slots: five PCI Express and two conventional PCI. Actual compatibility depends on the motherboard, card dimensions, electrical requirements, and driver support.
Q4. Does the IPC547G support Gigabit Ethernet?
Yes. The family includes two Intel Gigabit Ethernet interfaces. Network features and supported protocols depend on the installed operating system, drivers, and network configuration.
Q5. Which display interfaces are available?
Common configurations include DisplayPort 1.2 and DVI-D. The exact number and arrangement of display outputs depend on the motherboard and any installed graphics card.
Q6. What memory technology does the IPC547G use?
The family uses DDR4 SDRAM. Installed capacity and supported memory arrangements vary by configuration and should be confirmed for the individual unit.
Q7. Can the IPC547G use SSD storage?
Yes. HDD and SSD configurations are available across the family. The drive type, capacity, mounting arrangement, and storage-controller configuration for this order number remain unverified.
Q8. Does the IPC547G support RAID?
Selected configurations support RAID storage. The available RAID level and drive arrangement depend on the storage controller and installed drives. Verify the exact configuration before relying on RAID functionality.
Q9. Which operating systems are compatible with this platform?
Compatibility depends on the installed processor, chipset, drivers, and application requirements. Historical IPC547G configurations were offered with different Windows editions or without a preinstalled operating system. Check driver availability and application support before deployment.
Q10. What should be checked before replacing an existing unit?
Confirm the complete order number, processor, motherboard, memory, storage, operating system, expansion cards, network interfaces, and power-supply configuration. Matching these details helps avoid hardware and software compatibility problems.
