Siemens 6AG4104-4CA01-0XX0 – SIMATIC IPC547G Industrial Rack PC for Automation Applications
Siemens 6AG4104-4CA01-0XX0 – SIMATIC IPC547G Industrial Rack PC for Automation Applications
0.0
Points
Brand:Siemens Item No.:6AG4104-4CA01-0XX0 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 356.6 mm Product Weight:23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens SIMATIC IPC547G is a rack-mounted industrial computer platform developed for demanding industrial computing and automation environments. Its 19-inch, 4U enclosure, network interfaces, hardware-monitoring functions, and expansion capability make the family suitable for a range of industrial applications.
The specific configuration of 6AG4104-4CA01-0XX0 could not be confirmed from the available product records. Processor, memory, storage, operating system, power supply, and included accessories should therefore be checked against the original Siemens product label or order documentation before procurement.
For maintenance teams and system integrators, confirming the complete order number is particularly important when sourcing replacement hardware for an existing installation.
Technical Specifications
Important: The table below distinguishes documented IPC547G family characteristics from details that remain unverified for the exact order number.
Parameter
Specification
Manufacturer
Siemens
Product family
SIMATIC IPC547G
Order number
6AG4104-4CA01-0XX0
Product type
Industrial rack PC
Rack format
19-inch, 4U family design
Processor
Not verified for this exact order number
Chipset / motherboard
Not verified for this exact order number
Installed memory
Not verified
Storage
Not verified
Operating system
Not verified
Ethernet
Two Intel Gigabit Ethernet interfaces on documented family configurations
USB interfaces
Configuration-dependent
Display interfaces
DisplayPort and DVI-D on documented motherboard variants
Expansion slots
Family configurations commonly provide 5 PCI Express and 2 PCI slots
Monitoring functions
Temperature and fan monitoring on documented family configurations
Watchdog
Available on documented family configurations
Power supply
Family configurations include 100–240 V AC industrial power supply options
Standard enclosure dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm for the documented standard enclosure
Short enclosure dimensions (W × H × D)
481.4 × 176.6 × 356.6 mm for applicable short-enclosure versions
Weight
Approximately 15–23 kg across family configurations; exact weight not verified
Product lifecycle
Exact lifecycle status for this order number not verified
Recommended Related Models
The following documented IPC547G order numbers may be useful for comparison. They are different configurations, not confirmed direct replacements for 6AG4104-4CA01-0XX0.
Model
General configuration
6AG4104-4CA01-0XX1
IPC547G with Intel Core i5-6500, H110 motherboard, 4 GB DDR4, 1 TB HDD, DisplayPort, DVI-D, and no operating system
6AG4104-4AA05-3XX0
IPC547G with Intel Pentium G4400, 4 GB DDR4, 1 TB HDD, dual Gigabit Ethernet, and no operating system
6AG4104-4AA12-2CC2
IPC547G with Intel Pentium G4400, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 10 Enterprise LTSB 2015
6AG4104-4EN16-3XX0
IPC547G with Intel Pentium G4400, C236 motherboard, 8 GB DDR4, RAID 1 storage, and no operating system
6AG4104-4CA00-0BX2
IPC547G with Intel Core i5-6500, 4 GB DDR4, 1 TB HDD, short enclosure, and Windows 7 Ultimate
Popular Related Models
Model
Product family / configuration
6AG4104-4DA12-3BX2
IPC547G with Intel Core i7-6700, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 7 Ultimate
6AG4104-4GA12-2DX1
IPC547G with Intel Core i5-6500, C236 motherboard, 8 GB DDR4, 1 TB HDD, DVD±RW, and a PCI Express dual-head graphics card
6AG4104-4GN16-4BX0
IPC547G configuration with Intel Core i5-6500, 8 GB RAM, RAID 1 storage, and Windows Server 2012 R2
6AG4104-3DB24-3XX0
SIMATIC IPC547E industrial rack PC, an earlier related platform
Applications
The Siemens 6AG4104-4CA01-0XX0 is referenced as a SIMATIC IPC547G industrial rack PC model number. However, the exact configuration associated with this complete order number could not be independently verified. The following applications describe the SIMATIC IPC547G product family and should be confirmed against the device nameplate or original Siemens documentation before ordering.
Industrial Automation: Supports industrial control and automation software in suitable system configurations.
Machine Control: Can serve as an industrial computing platform for machine monitoring and control applications.
Production Line Monitoring: Supports data collection, visualization, and production monitoring when configured with compatible software.
Industrial Data Processing: Suitable for processing operational data and interfacing with supported industrial equipment.
System Integration: The rack-mounted design and expansion slots support integration into compatible industrial control cabinets.
Legacy System Maintenance: May be relevant for maintaining existing installations built around the SIMATIC IPC547G platform.
Advantages
Industrial Rack-Mount Design: The IPC547G family uses a 19-inch, 4U rack format for industrial installations.
Expansion Flexibility: The family provides seven expansion slots, commonly configured as five PCI Express slots and two PCI slots.
Network Connectivity: Two Intel Gigabit Ethernet interfaces are available on documented family configurations.
Hardware Monitoring: Supported family features include temperature and fan monitoring, a watchdog, and card-retention hardware.
Flexible Peripheral Connections: USB, PS/2, and audio interfaces are provided, with the exact port arrangement depending on the motherboard configuration.
Serviceability: The rack-mounted construction supports integration into industrial cabinets and maintenance environments.
Configuration Options: The IPC547G family was offered with different processors, memory capacities, storage devices, operating systems, and power-supply arrangements.
Technical FAQs
Q1. What type of product is the Siemens 6AG4104-4CA01-0XX0? It is associated by its product-number format with the Siemens SIMATIC IPC547G range, but the exact configuration for this order number has not been confirmed. Verify the complete article number before purchase.
Q2. What is the SIMATIC IPC547G used for? The IPC547G is an industrial rack PC designed for industrial computing tasks such as automation software execution, machine monitoring, data processing, and system integration.
Q3. Which processor is installed in the 6AG4104-4CA01-0XX0? The processor for this exact order number has not been verified. Other IPC547G configurations were available with different Intel processors, so the specification of a similar model should not be assumed to apply.
Q4. How much memory does this model support? The installed memory and supported maximum depend on the specific motherboard and configuration. Check the original Siemens technical documentation for the exact article number before upgrading memory.
Q5. What network interfaces are available on the IPC547G family? Documented family configurations include two Intel Gigabit Ethernet interfaces. Confirm the exact hardware configuration before integrating the PC into a network.
Q6. Does the IPC547G support PCI Express expansion cards? Yes. Documented IPC547G family configurations provide seven expansion slots, commonly comprising five PCI Express slots and two conventional PCI slots. Confirm slot layout and electrical compatibility before installing a card.
Q7. Which video outputs are available? Documented motherboard variants include DisplayPort and DVI-D. The number and arrangement of display outputs depend on the installed motherboard and any optional graphics card.
Q8. Does the product include a preinstalled operating system? The operating system for the 6AG4104-4CA01-0XX0 has not been confirmed. IPC547G configurations were sold with different operating-system options, including versions supplied without an operating system.
Q9. What power supply does the IPC547G use? Documented family configurations use an industrial AC power supply supporting 100–240 V AC. The precise power-supply arrangement and included power cable must be verified for the target order number.
Q10. Is the 6AG4104-4CA01-0XX0 suitable as a replacement for another IPC547G? Potentially, but replacement compatibility depends on the processor, motherboard, storage, expansion cards, operating system, power supply, and enclosure configuration. Compare the complete article numbers and installed hardware before replacing a unit.
