Siemens 6AG4104-4CA01-0XX3 – SIMATIC IPC547G Industrial Rack PC
Siemens 6AG4104-4CA01-0XX3 – SIMATIC IPC547G Industrial Rack PC
0.0
Points
Brand:Siemens Item No.:6AG4104-4CA01-0XX3 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 446.6 mm Product Weight:23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens SIMATIC IPC547G 6AG4104-4CA01-0XX3 is a rack-mounted industrial computer designed for industrial environments requiring a combination of computing performance, network connectivity, and hardware expansion.
The identified configuration features an Intel Core i5-6500 processor, 4 GB of DDR4 memory, a 1 TB internal HDD, and an H110 motherboard with DisplayPort and DVI-D connectivity. Its dual Gigabit Ethernet interfaces and seven expansion slots support integration with compatible industrial peripherals and equipment.
With its 19-inch, 4U enclosure, the IPC547G is suited to industrial cabinets, machine systems, and established automation installations. When sourcing this model, buyers should verify the complete article number and physical configuration, particularly if the unit is intended as a replacement for equipment already in service.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Product family
SIMATIC IPC547G
Order number
6AG4104-4CA01-0XX3
Product type
Industrial rack PC
Form factor
19-inch rack, 4U
Processor
Intel Core i5-6500
CPU cores / threads
4 cores / 4 threads
Base / turbo frequency
3.2 GHz / up to 3.6 GHz
CPU cache
6 MB
Motherboard chipset
Intel H110
Installed memory
4 GB DDR4 SDRAM, 1 × 4 GB
Storage
1 × 1 TB internal HDD
Graphics
Integrated graphics
Display interfaces
1 × DisplayPort 1.2, 1 × DVI-D
Ethernet
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
2 × USB 3.0, 4 × USB 2.0
Other interfaces
2 × PS/2, audio; additional details depend on configuration
Expansion slots
5 × PCI Express, 2 × PCI
Monitoring functions
Temperature and fan monitoring
Watchdog
Supported
Power supply
100–240 V AC
Operating system
No operating system in the listed configuration
Enclosure finish
Blue chromated enclosure
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm, standard enclosure
Weight
Approximately 15–23 kg across the IPC547G family, depending on equipment; exact weight not confirmed
Recommended Related Models
The following models are related SIMATIC IPC547G configurations with documented differences in hardware or installed software.
Model
Description
6AG4104-4CA01-0XX1
IPC547G with Intel Core i5-6500, 4 GB DDR4, 1 TB HDD, H110 motherboard, DisplayPort, DVI-D, and no operating system; listed with a European power cable.
6AG4104-4CA00-0BX2
IPC547G with Intel Core i5-6500, 4 GB DDR4, 1 TB HDD, short enclosure, and Windows 7 Ultimate; listed with a US power cable.
6AG4104-4CA12-1DX1
IPC547G with Intel Core i5-6500, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 10 Enterprise 2016 LTSB; listed with a European power cable.
6AG4104-4DA12-3BX2
IPC547G with Intel Core i7-6700, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 7 Ultimate.
6AG4104-4AA05-3XX0
IPC547G with Intel Pentium G4400, 4 GB DDR4, 1 TB HDD, and no operating system.
Popular Related Models
Model
Product description
6AG4104-4EN16-3XX0
IPC547G with Intel Pentium G4400, C236 motherboard, 8 GB DDR4, RAID 1 storage using two 1 TB HDDs, and no operating system.
6AG4104-4GN16-4BX0
IPC547G configuration with Intel Core i5-6500, 8 GB RAM, RAID 1 storage, and Windows Server 2012 R2.
6AG4104-4GA12-2DX1
IPC547G with Intel Core i5-6500, C236 motherboard, 8 GB DDR4, 1 TB HDD, DVD±RW, and a PCI Express dual-head graphics card.
6AG4104-4CA04-0BX0
IPC547G with Intel Core i5-6500, 4 GB DDR4, 1 TB HDD, DVD±RW, and a redundant dual AC power-supply arrangement.
6AG4104-3DB24-3XX0
SIMATIC IPC547E industrial rack PC, an earlier related platform.
Applications
The Siemens 6AG4104-4CA01-0XX3 is a SIMATIC IPC547G industrial rack PC designed for industrial computing, automation support, and integration into control cabinets. Available product information identifies a configuration built around an Intel Core i5-6500 processor, making it suitable for established industrial applications that require reliable computing and expansion flexibility.
Typical applications include:
Industrial Automation: Running compatible automation software and supporting industrial control systems.
Machine Monitoring: Processing machine status information and supporting operator monitoring applications.
Production Data Management: Collecting, processing, and storing production data.
Industrial Visualization: Supporting HMI and visualization software compatible with the installed operating system.
System Integration: Connecting industrial peripherals, network equipment, and compatible expansion cards.
Legacy Equipment Maintenance: Supporting existing installations that depend on the SIMATIC IPC547G platform.
Advantages
Industrial Rack-Mount Construction: The 19-inch, 4U design supports installation in compatible industrial cabinets and equipment racks.
Intel Core i5 Processing: The identified configuration uses a Core i5-6500 quad-core processor for general industrial computing tasks.
Flexible Expansion: Seven expansion slots provide options for compatible PCI Express and PCI cards.
Dual Gigabit Ethernet: Two Ethernet interfaces support industrial network connections and communication with connected systems.
Integrated Hardware Monitoring: Temperature and fan monitoring, a watchdog, and card-retention features support system management.
Multiple Peripheral Interfaces: Front USB ports and rear USB, PS/2, audio, and display connections support a range of peripheral devices.
Industrial AC Power: The documented configuration uses a 100–240 V AC power supply.
Established Platform: The IPC547G is suitable for maintaining compatible legacy systems where the existing hardware and software environment must be preserved.
Technical FAQs
Q1. What is the Siemens 6AG4104-4CA01-0XX3? It is a Siemens SIMATIC IPC547G industrial rack PC in a 19-inch, 4U format.
Q2. Which processor is used in this configuration? Available product information identifies an Intel Core i5-6500 processor with four cores and four threads, a 3.2 GHz base frequency, up to 3.6 GHz turbo frequency, and 6 MB cache.
Q3. How much memory is installed? The listed configuration has 4 GB DDR4 SDRAM installed as a single 4 GB module. Confirm the memory configuration of the physical unit before upgrading or purchasing.
Q4. What storage capacity does the system provide? The listed configuration includes one internal 1 TB hard disk drive.
Q5. Which network interfaces are available? The IPC547G family configuration includes two Intel Gigabit Ethernet interfaces for network communication.
Q6. What display interfaces are provided? The identified H110 motherboard configuration provides one DisplayPort 1.2 interface and one DVI-D interface, using onboard graphics.
Q7. How many expansion slots does the IPC547G provide? The documented platform provides seven expansion slots: five PCI Express slots and two conventional PCI slots. Check card dimensions, slot type, and system compatibility before installation.
Q8. Does this configuration include an operating system? The available product description specifies that the configuration is supplied without a preinstalled operating system. Verify the supplied unit and licensing requirements before deployment.
Q9. What input voltage does the industrial PC support? The documented configuration uses a 100–240 V AC industrial power supply. The applicable power cable and regional requirements should be checked before installation.
Q10. What should be checked before replacing an existing IPC547G? Compare the full order number, processor, motherboard, memory, storage, expansion cards, operating system, enclosure, and power-cable requirements. Similar IPC547G models may have different hardware and software configurations.
