Siemens 6AG4104-4CA01-1XX3 – SIMATIC IPC547G Industrial Rack PC
Siemens 6AG4104-4CA01-1XX3 – SIMATIC IPC547G Industrial Rack PC
0.0
Points
Brand:Siemens Item No.:6AG4104-4CA01-1XX3 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 356.6 mm Product Weight:23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens SIMATIC IPC547G is an industrial rack PC platform designed for automation support, industrial data processing, visualization, and system integration. Its 19-inch, 4U enclosure and expansion capabilities make it suitable for installation in compatible industrial cabinets and equipment racks.
Depending on the selected configuration, the IPC547G family offers Intel processors, DDR4 memory, internal storage, Gigabit Ethernet connectivity, and a range of peripheral interfaces. Hardware-monitoring features and expansion slots support integration into industrial computing environments.
For the specific order number 6AG4104-4CA01-1XX3, however, the processor, memory, storage, operating system, and included accessories could not be independently verified. Buyers should confirm these details against the original Siemens documentation or the physical product label before purchase.
Technical Specifications
Note: The table distinguishes general IPC547G family characteristics from details that remain unverified for the exact order number.
Parameter
Specification
Manufacturer
Siemens
Product family
SIMATIC IPC547G
Order number
6AG4104-4CA01-1XX3
Product type
Industrial rack PC
Form factor
19-inch rack, 4U
Processor
Not verified for this exact order number
Motherboard / chipset
Not verified
Installed memory
Not verified
Storage
Not verified
Operating system
Not verified
Ethernet
Two Intel Gigabit Ethernet interfaces on documented family configurations
Front USB
Two USB 3.0 ports on documented family configurations
Rear USB
Configuration-dependent; documented variants include USB 3.0 and USB 2.0
Display interfaces
DisplayPort 1.2 and DVI-D on documented motherboard variants
Other interfaces
PS/2 and audio on documented family configurations
Expansion slots
Commonly 5 × PCI Express and 2 × PCI
Hardware monitoring
Temperature and fan monitoring on documented family configurations
Watchdog
Available on documented family configurations
Power supply
100–240 V AC on documented configurations
Standard enclosure dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Short enclosure dimensions (W × H × D)
481.4 × 176.6 × 356.6 mm, where applicable
Weight
Approximately 15–23 kg across family configurations; exact weight not verified
Recommended Related Models
The following are documented SIMATIC IPC547G variants that can be considered for comparison. They are not confirmed direct replacements for the 6AG4104-4CA01-1XX3.
Model
Description
6AG4104-4CA01-0XX1
IPC547G with Intel Core i5-6500, H110 motherboard, 4 GB DDR4, 1 TB HDD, DisplayPort, DVI-D, and no operating system.
6AG4104-4AA05-3XX0
IPC547G with Intel Pentium G4400, 4 GB DDR4, 1 TB HDD, dual Gigabit Ethernet, and no operating system.
6AG4104-4AA12-2CC2
IPC547G with Intel Pentium G4400, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 10 Enterprise LTSB 2015.
6AG4104-4EN16-3XX0
IPC547G with Intel Pentium G4400, C236 motherboard, 8 GB DDR4, RAID 1 storage, and no operating system.
6AG4104-4DA12-3BX2
IPC547G with Intel Core i7-6700, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 7 Ultimate.
Popular Related Models
Model
Product description
6AG4104-4CA00-0BX2
IPC547G with Intel Core i5-6500, 4 GB DDR4, 1 TB HDD, short enclosure, and Windows 7 Ultimate.
6AG4104-4GA12-2DX1
IPC547G with Intel Core i5-6500, C236 motherboard, 8 GB DDR4, 1 TB HDD, DVD±RW, and a PCI Express dual-head graphics card.
6AG4104-4GN16-4BX0
IPC547G with Intel Core i5-6500, 8 GB RAM, RAID 1 storage, and Windows Server 2012 R2.
6AG4104-4CA04-0BX0
IPC547G with Intel Core i5-6500, 4 GB DDR4, 1 TB HDD, DVD±RW, and redundant dual AC power supplies.
6AG4104-3DB24-3XX0
SIMATIC IPC547E industrial rack PC from an earlier product generation.
Applications
The Siemens 6AG4104-4CA01-1XX3 is referenced as a potential configuration of the SIMATIC IPC547G industrial rack PC family. However, the exact configuration associated with this complete order number could not be independently verified. The following applications describe the IPC547G platform rather than guarantee the specifications of this particular article number.
Industrial Automation: Provides an industrial computing platform for compatible automation software and control applications.
Machine Monitoring: Supports machine-status visualization, process monitoring, and equipment diagnostics.
Production Data Processing: Handles industrial data collection, storage, and processing tasks.
HMI and Visualization: Can run compatible human-machine interface software when the required operating system and software are installed.
Industrial System Integration: Supports network communication and integration with compatible expansion cards and peripherals.
Legacy Equipment Support: May be suitable for maintaining existing installations based on the SIMATIC IPC547G platform.
Advantages
Industrial Rack-Mount Format: The 19-inch, 4U enclosure is designed for integration into compatible industrial cabinets and equipment racks.
Flexible Expansion: Documented IPC547G configurations offer seven expansion slots, typically five PCI Express slots and two PCI slots.
Network Connectivity: Two Intel Gigabit Ethernet interfaces are available on documented family configurations.
Hardware Monitoring: Supported features include temperature and fan monitoring, a watchdog, and a card-retention mechanism.
Peripheral Connectivity: USB, PS/2, audio, and display interfaces support a range of industrial peripherals.
Multiple Hardware Options: The IPC547G family was offered with different processor, memory, storage, graphics, and operating-system configurations.
Industrial Power Input: Documented configurations support 100–240 V AC input.
Maintenance Flexibility: Its rack-mounted design and expansion capability make the platform relevant to established industrial systems.
Technical FAQs
Q1. What is the Siemens 6AG4104-4CA01-1XX3? The exact configuration for this order number has not been confirmed. It should be verified against Siemens documentation or the equipment nameplate before ordering. The IPC547G family is a 19-inch, 4U industrial rack PC platform.
Q2. Which processor does this model use? The processor installed in the exact 6AG4104-4CA01-1XX3 configuration remains unverified. Do not assume that it uses the same processor as a similarly numbered IPC547G variant.
Q3. What memory capacity is installed? The installed memory capacity and module arrangement have not been confirmed for this order number. Check the original configuration record before purchasing memory upgrades.
Q4. What storage options are supported? IPC547G configurations were offered with different storage arrangements, including internal hard disk drives and RAID options on selected variants. The storage supplied with this exact article number requires verification.
Q5. Which Ethernet interfaces are available? Documented IPC547G configurations include two Intel Gigabit Ethernet interfaces. Verify the motherboard specification before relying on particular networking features.
Q6. Which display interfaces does the IPC547G support? Documented motherboard variants include DisplayPort 1.2 and DVI-D. The exact display configuration depends on the installed motherboard and any additional graphics hardware.
Q7. Can the IPC547G accommodate expansion cards? Yes. Documented family configurations provide seven expansion slots, commonly comprising five PCI Express slots and two conventional PCI slots. Check the individual slot arrangement and card compatibility before installation.
Q8. Is an operating system included? The operating-system status of the 6AG4104-4CA01-1XX3 has not been confirmed. Other IPC547G variants were supplied either without an operating system or with selected Windows editions.
Q9. What power supply is used? Documented IPC547G configurations include industrial power supplies supporting 100–240 V AC. The exact supply arrangement and included power cable should be confirmed for this model.
Q10. How can compatibility be checked before replacement? Compare the complete order number, processor, motherboard, memory, storage, expansion cards, operating system, enclosure, and power requirements. This is particularly important when replacing a unit in an established automation system.
