Siemens 6AG4104-4CA02-0BX3 – SIMATIC IPC547G Industrial Rack PC
Siemens 6AG4104-4CA02-0BX3 – SIMATIC IPC547G Industrial Rack PC
0.0
Points
Brand:Siemens Item No.:6AG4104-4CA02-0BX3 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 446.6 mm Product Weight:23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens SIMATIC IPC547G 6AG4104-4CA02-0BX3 is an industrial rack PC designed for automation environments, industrial data processing, machine monitoring, and equipment integration.
This configuration features an Intel Core i5-6500 processor, 4 GB DDR4 SDRAM, a 1 TB internal hard disk drive, and an H110 motherboard with DisplayPort and DVI-D connectivity. Two Gigabit Ethernet interfaces support network communication, while seven expansion slots provide flexibility for compatible industrial interface cards and other peripherals.
The system also includes a slim DVD±RW drive and Windows 7 Ultimate, 64-bit, Service Pack 1. Its 19-inch, 4U enclosure makes it suitable for compatible rack installations and industrial control cabinets.
For replacement and maintenance projects, buyers should confirm the complete article number, hardware condition, operating-system licensing, and compatibility with existing automation software before purchase.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Product family
SIMATIC IPC547G
Order number
6AG4104-4CA02-0BX3
Product type
Industrial rack PC
Form factor
19-inch rack, 4U
Processor
Intel Core i5-6500
CPU cores / threads
4 cores / 4 threads
Base frequency
3.2 GHz
Maximum turbo frequency
Up to 3.6 GHz
CPU cache
6 MB
Motherboard chipset
Intel H110
Installed memory
4 GB DDR4 SDRAM
Memory configuration
1 × 4 GB, single channel
Storage
1 × 1 TB internal HDD
Graphics
Integrated graphics
Display interfaces
1 × DisplayPort 1.2, 1 × DVI-D
Ethernet
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
2 × USB 3.0, 4 × USB 2.0
Other interfaces
2 × PS/2, audio
Expansion slots
5 × PCI Express, 2 × PCI
Optical drive
Slim DVD±RW
Hardware monitoring
Temperature and fan monitoring
Watchdog
Supported
Operating system
Windows 7 Ultimate, 64-bit, SP1
Enclosure finish
Blue chromated
Power supply
100–240 V AC industrial power supply
Power cable
China version, according to the listed configuration
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Weight
Approximately 15–23 kg across the IPC547G family; exact weight for this configuration not independently confirmed
Recommended Related Models
The following Siemens models offer alternative IPC547G configurations for comparison. Their hardware and software specifications differ, so they should not be treated as direct replacements without compatibility checks.
Model
Description
6AG4104-4CA01-0XX1
Core i5-6500, H110 motherboard, 4 GB DDR4, 1 TB HDD, DisplayPort, DVI-D, and no operating system.
6AG4104-4CA12-1DX1
Core i5-6500, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 10 Enterprise 2016 LTSB.
6AG4104-4CA00-0BX2
Core i5-6500, 4 GB DDR4, 1 TB HDD, short enclosure, and Windows 7 Ultimate.
6AG4104-4DA12-3BX2
Core i7-6700, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 7 Ultimate.
6AG4104-4AA05-3XX0
Pentium G4400, 4 GB DDR4, 1 TB HDD, dual Gigabit Ethernet, and no operating system.
Popular Related Models
Model
Product description
6AG4104-4EN16-3XX0
IPC547G with Intel Pentium G4400, C236 motherboard, 8 GB DDR4, RAID 1 storage using two 1 TB HDDs, and no operating system.
6AG4104-4GN16-4BX0
IPC547G with Intel Core i5-6500, 8 GB RAM, RAID 1 storage, and Windows Server 2012 R2.
6AG4104-4GA12-2DX1
IPC547G with Intel Core i5-6500, C236 motherboard, 8 GB DDR4, 1 TB HDD, DVD±RW, and a PCI Express dual-head graphics card.
6AG4104-4CA04-0BX0
IPC547G with Intel Core i5-6500, 4 GB DDR4, 1 TB HDD, DVD±RW, and redundant dual AC power supplies.
6AG4104-4GK13-1BX2
IPC547G with Intel Core i5-6500, C236 motherboard, 8 GB DDR4, 480 GB SSD in a front-access interchangeable drive bay, redundant AC power supplies, and Windows 7 Ultimate.
Applications
The Siemens 6AG4104-4CA02-0BX3 is a SIMATIC IPC547G industrial rack PC designed for industrial computing, automation support, and machine-level data processing. Its Intel Core i5 processor, internal storage, and expansion capabilities make it suitable for industrial installations that require a rack-mounted computer with established connectivity and peripheral support.
Typical applications include:
Industrial Automation: Running compatible automation software and supporting industrial control environments.
Machine Monitoring: Processing operating data and supporting machine-status visualization.
Production Data Management: Collecting and storing manufacturing information for analysis and traceability.
HMI and Visualization: Supporting compatible human-machine interface software and operator displays.
Industrial System Integration: Connecting networked equipment, peripheral devices, and compatible expansion cards.
Legacy System Maintenance: Providing computing support for existing installations based on the SIMATIC IPC547G platform.
Advantages
Industrial Rack-Mount Design: The 19-inch, 4U enclosure is suitable for installation in compatible industrial cabinets and equipment racks.
Intel Core i5 Processing: The Intel Core i5-6500 processor provides four cores and four threads for general industrial computing workloads.
Integrated Graphics: Onboard graphics support compatible displays without requiring a separate graphics card for basic visualization tasks.
Dual Gigabit Ethernet: Two Intel Gigabit Ethernet interfaces support industrial network connectivity.
Integrated DVD±RW Drive: The listed configuration includes an optical drive for compatible installation media and data-access tasks.
Hardware Monitoring: Temperature and fan monitoring, a watchdog, and card-retention features support system operation and maintenance.
Broad Peripheral Connectivity: USB, PS/2, audio, and display interfaces support a variety of industrial peripherals.
Technical FAQs
Q1. What is the Siemens 6AG4104-4CA02-0BX3? It is a Siemens SIMATIC IPC547G industrial rack PC in a 19-inch, 4U format, configured with an Intel Core i5-6500 processor, 4 GB of DDR4 memory, and a 1 TB hard disk drive.
Q2. Which processor does this model use? The system uses an Intel Core i5-6500 processor with four cores, four threads, a 3.2 GHz base frequency, up to 3.6 GHz turbo frequency, and 6 MB cache.
Q3. How much memory is installed? The listed configuration includes 4 GB DDR4 SDRAM installed as a single 4 GB module, operating in single-channel mode.
Q4. What storage capacity does the IPC547G provide? This configuration includes one internal 1 TB hard disk drive.
Q5. Which network interfaces are available? The system provides two Intel Gigabit Ethernet interfaces for connecting to industrial networks and compatible Ethernet devices.
Q6. Which display outputs are supported? The H110 motherboard configuration provides one DisplayPort 1.2 output and one DVI-D output, using onboard graphics.
Q7. Does this model include an optical drive? Yes. The listed configuration includes a slim DVD±RW drive.
Q8. Which operating system is supplied? This configuration includes Windows 7 Ultimate, 64-bit, Service Pack 1, with a multilingual user interface. Confirm the license and installation status of the physical unit before deployment.
Q9. What expansion options are available? The IPC547G platform provides seven expansion slots, commonly comprising five PCI Express slots and two PCI slots. The installed cards and slot availability depend on the individual system configuration.
Q10. What should be considered when deploying this computer today? Windows 7 Ultimate is a legacy operating system that no longer receives standard security support. Assess application compatibility, cybersecurity requirements, network isolation, and any migration requirements before connecting the computer to a production network.
