Siemens 6AG4104-4CA02-0XX3 – SIMATIC IPC547G Industrial Rack PC
Siemens 6AG4104-4CA02-0XX3 – SIMATIC IPC547G Industrial Rack PC
0.0
Points
Brand:Siemens Item No.:6AG4104-4CA02-0XX3 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 356.6 mm Product Weight:23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens SIMATIC IPC547G is a rack-mounted industrial computer platform designed for automation support, industrial data processing, machine monitoring, and system integration. Its 19-inch, 4U design allows installation in compatible industrial cabinets, while its expansion slots and network interfaces support integration with a variety of industrial devices.
Depending on configuration, the IPC547G family provides Intel processors, DDR4 memory, internal storage, display connections, and hardware-monitoring functions. These capabilities make the platform relevant to both new system integration and maintenance of existing industrial installations.
For 6AG4104-4CA02-0XX3, the exact configuration has not been independently confirmed. Buyers should verify the complete article number and equipment label before relying on a specific processor, storage capacity, operating system, or included accessory.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Product family
SIMATIC IPC547G
Order number
6AG4104-4CA02-0XX3
Product type
Industrial rack PC
Form factor
19-inch, 4U
Processor
Not verified for this exact order number
Motherboard / chipset
Not verified
Installed memory
Not verified
Storage
Not verified
Operating system
Not verified
Ethernet
Two Intel Gigabit Ethernet interfaces on documented family configurations
Front USB
Two USB 3.0 ports on documented family configurations
Rear USB
Configuration-dependent
Display interfaces
DisplayPort and DVI-D on documented motherboard variants
Other interfaces
PS/2 and audio on documented family configurations
Expansion slots
Typically five PCI Express and two PCI
Hardware monitoring
Temperature and fan monitoring on documented family configurations
Watchdog
Available on documented family configurations
Power supply
100–240 V AC on documented configurations
Standard enclosure dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Short enclosure dimensions (W × H × D)
481.4 × 176.6 × 356.6 mm, where applicable
Weight
Approximately 15–23 kg across the family, depending on configuration
Dimensions and weight are family-level specifications. The enclosure type and exact weight of the 0XX3 variant have not been confirmed.
Recommended Related Models
These documented SIMATIC IPC547G variants provide useful comparison points but are not confirmed direct replacements for the 0XX3 order number.
Model
Configuration summary
6AG4104-4CA01-0XX1
Core i5-6500, H110 motherboard, 4 GB DDR4, 1 TB HDD, DisplayPort, DVI-D, and no operating system.
6AG4104-4CA00-0BX2
Core i5-6500, 4 GB DDR4, 1 TB HDD, short enclosure, and Windows 7 Ultimate.
6AG4104-4CA12-1DX1
Core i5-6500, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 10 Enterprise 2016 LTSB.
6AG4104-4DA12-3BX2
Core i7-6700, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 7 Ultimate.
6AG4104-4AA05-3XX0
Pentium G4400, 4 GB DDR4, 1 TB HDD, dual Gigabit Ethernet, and no operating system.
Popular Related Models
Model
Product description
6AG4104-4EN16-3XX0
IPC547G with Pentium G4400, C236 motherboard, 8 GB DDR4, RAID 1 storage using two 1 TB HDDs, and no operating system.
6AG4104-4GN16-4BX0
IPC547G with Core i5-6500, 8 GB RAM, RAID 1 storage, and Windows Server 2012 R2.
6AG4104-4GA12-2DX1
IPC547G with Core i5-6500, C236 motherboard, 8 GB DDR4, 1 TB HDD, DVD±RW, and a PCI Express dual-head graphics card.
6AG4104-4CA04-0BX0
IPC547G with Core i5-6500, 4 GB DDR4, 1 TB HDD, DVD±RW, and redundant dual AC power supplies.
6AG4104-4GK13-1BX2
IPC547G with Core i5-6500, C236 motherboard, 8 GB DDR4, a 480 GB SSD in a front-access interchangeable drive bay, redundant AC power supplies, and Windows 7 Ultimate.
Applications
The Siemens 6AG4104-4CA02-0XX3 is a SIMATIC IPC547G industrial rack PC configured for industrial computing, machine monitoring, and automation support. This order number corresponds to a documented configuration featuring an Intel Core i5-6500 processor, 4 GB DDR4 memory, a 1 TB hard disk drive, and an H110 motherboard.
Typical applications include:
Industrial Automation: Running compatible industrial control and automation software.
Machine Monitoring: Supporting machine-status visualization, diagnostics, and operational monitoring.
Production Data Processing: Collecting, storing, and processing manufacturing data.
HMI and Visualization: Running compatible operator-interface software and supporting connected displays.
Industrial System Integration: Connecting network equipment, peripheral devices, and compatible expansion cards.
Legacy System Maintenance: Maintaining existing installations that rely on the SIMATIC IPC547G platform.
Advantages
Industrial Rack-Mount Construction: A 19-inch, 4U enclosure designed for installation in compatible industrial cabinets.
Intel Core i5 Performance: The four-core Intel Core i5-6500 supports general industrial computing and visualization workloads.
Integrated Graphics: Onboard graphics support compatible display configurations without requiring a separate graphics card for basic use.
Dual Gigabit Ethernet: Two Intel Gigabit Ethernet interfaces provide network connectivity.
Expansion Flexibility: Seven expansion slots, comprising five PCI Express and two PCI slots on the documented platform.
Hardware Monitoring: Temperature and fan monitoring, a watchdog, and a card-retention mechanism support system management.
Windows Compatibility: The listed configuration includes Windows 7 Ultimate 64-bit SP1, which may be relevant to compatible legacy applications.
Technical FAQs
Q1. What type of equipment is the Siemens 6AG4104-4CA02-0XX3? It is intended to be identified as a SIMATIC IPC547G industrial rack PC, but the complete 0XX3 order-number variant could not be independently verified. Confirm the product label before procurement.
Q2. Which processor is installed? The processor for this exact order number remains unconfirmed. Other IPC547G configurations use processors such as the Intel Core i5-6500, but their specifications should not automatically be applied to this variant.
Q3. What memory capacity does it have? The installed memory has not been verified for this exact article number. The IPC547G family includes multiple DDR4 memory configurations.
Q4. Which storage devices are supported? The family was offered with different internal HDD, SSD, and RAID configurations. Confirm the installed storage and controller configuration before planning a replacement.
Q5. What networking capabilities are available? Documented IPC547G configurations include two Intel Gigabit Ethernet interfaces. Exact motherboard and interface details should be confirmed for the unit being supplied.
Q6. Which display connections are supported? Depending on the motherboard, the IPC547G family supports DisplayPort and DVI-D. Some configurations also offer optional graphics expansion cards.
Q7. How many expansion slots are available? Documented IPC547G systems provide seven expansion slots, typically five PCI Express and two PCI slots. Check the exact slot layout and available space before installing additional hardware.
Q8. Does this model include a preinstalled operating system? The operating-system status of the 0XX3 variant is unconfirmed. Verify the original order documentation and any software license supplied with the unit.
Q9. What power supply does the IPC547G use? Documented family configurations support 100–240 V AC. Some versions offer redundant power supplies, so the specific power arrangement should be checked before installation.
Q10. What should be checked before ordering a replacement? Verify the full Siemens order number, processor, motherboard, memory, storage, operating system, expansion hardware, enclosure, and power cable. These details can differ between closely related IPC547G variants.
