Siemens 6AG4104-4CA02-2BX1 – SIMATIC IPC547G Industrial Rack PC
Siemens 6AG4104-4CA02-2BX1 – SIMATIC IPC547G Industrial Rack PC
0.0
Points
Brand:Siemens Item No.: 6AG4104-4CA02-2BX1 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 356.6 mm Product Weight:23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens SIMATIC IPC547G is a rack-mounted industrial computer designed for industrial automation support, data processing, machine monitoring, and system integration. Its 19-inch, 4U form factor and expansion capability make it suitable for compatible industrial cabinets and equipment racks.
The product family offers multiple hardware configurations with different Intel processors, memory capacities, storage options, display interfaces, and operating systems. Hardware-monitoring functions and network connectivity support its use in established industrial computing environments.
For 6AG4104-4CA02-2BX1, the exact configuration has not been independently confirmed. Procurement teams should verify the product label and original Siemens documentation before specifying this order number for a new installation or replacement project.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Product family
SIMATIC IPC547G
Order number
6AG4104-4CA02-2BX1
Product type
Industrial rack PC
Form factor
19-inch, 4U
Processor
Not verified for this exact order number
Motherboard / chipset
Not verified
Installed memory
Not verified
Storage
Not verified
Operating system
Not verified
Ethernet
Two Intel Gigabit Ethernet interfaces on documented family configurations
Front USB
Two USB 3.0 ports on documented family configurations
Rear USB
Configuration-dependent
Display interfaces
DisplayPort and DVI-D on documented motherboard variants
Expansion slots
Typically five PCI Express and two PCI
Hardware monitoring
Temperature and fan monitoring on documented family configurations
Watchdog
Available on documented family configurations
Power supply
100–240 V AC on documented configurations
Standard enclosure dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Short enclosure dimensions (W × H × D)
481.4 × 176.6 × 356.6 mm, where applicable
Weight
Approximately 15–23 kg across the family, depending on equipment
Dimensions, weight, and interface details are family-level specifications, not verified specifications for the exact 6AG4104-4CA02-2BX1 configuration.
Recommended Related Models
The following documented IPC547G configurations may be useful for comparison. They are not confirmed direct replacements for the requested model.
Model
Configuration summary
6AG4104-4CA01-0XX1
Core i5-6500, H110 motherboard, 4 GB DDR4, 1 TB HDD, DisplayPort, DVI-D, and no operating system.
6AG4104-4CA00-0BX2
Core i5-6500, 4 GB DDR4, 1 TB HDD, short enclosure, and Windows 7 Ultimate.
6AG4104-4AA05-3XX0
Pentium G4400, 4 GB DDR4, 1 TB HDD, dual Gigabit Ethernet, and no operating system.
6AG4104-4DA12-3BX2
Core i7-6700, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 7 Ultimate.
6AG4104-4GA12-2DX1
Core i5-6500, C236 motherboard, 8 GB DDR4, 1 TB HDD, DVD±RW, and a PCI Express graphics card.
Popular Related Models
Model
Product description
6AG4104-4EN16-3XX0
IPC547G with Pentium G4400, C236 motherboard, 8 GB DDR4, RAID 1 storage using two 1 TB HDDs, and no operating system.
6AG4104-4GN16-4BX0
IPC547G with Core i5-6500, 8 GB RAM, RAID 1 storage, and Windows Server 2012 R2.
6AG4104-4GK13-1BX2
IPC547G with Core i5-6500, C236 motherboard, 8 GB DDR4, a 480 GB SSD in a front-access drive bay, redundant AC power supplies, and Windows 7 Ultimate.
6AG4104-4CA04-0BX0
IPC547G with Core i5-6500, 4 GB DDR4, 1 TB HDD, DVD±RW, and redundant dual AC power supplies.
6AG4104-4JR42-0XX2
IPC547G configuration with Xeon E3-1275 v5, C236 motherboard, RAID 1 storage, and a hot-spare drive. Verify the complete order number and configuration with Siemens before procurement.
Applications
The Siemens 6AG4104-4CA02-2BX1 order number could not be independently matched to an exact Siemens configuration. It is therefore important to verify the complete article number before treating any processor, memory, storage, or operating-system details as confirmed.
The following applications describe the SIMATIC IPC547G industrial rack PC family:
Industrial Automation: Running compatible industrial automation and control software.
Machine Monitoring: Supporting equipment status monitoring, diagnostics, and operator visualization.
Production Data Processing: Collecting and processing manufacturing data.
HMI Systems: Hosting compatible human-machine interface and visualization applications.
Industrial Networking: Connecting compatible networked equipment through Ethernet interfaces.
Legacy System Maintenance: Supporting existing installations that use the IPC547G platform.
Advantages
Industrial Rack Design: The 19-inch, 4U platform fits compatible industrial racks and control cabinets.
Expansion Capability: Documented configurations provide seven expansion slots, typically five PCI Express and two PCI slots.
Network Connectivity: Two Intel Gigabit Ethernet interfaces are available on documented family configurations.
Hardware Monitoring: Supported features include temperature and fan monitoring, a watchdog, and card-retention hardware.
Flexible Configuration: The IPC547G family was offered with different processors, memory capacities, storage devices, and operating systems.
Industrial AC Power: Documented versions support 100–240 V AC input.
Maintenance-Oriented Design: Rack installation and expansion options simplify integration into established industrial systems.
Technical FAQs
Q1. What is the Siemens 6AG4104-4CA02-2BX1? The exact configuration for this article number remains unverified. It should be checked against Siemens order documentation or the equipment nameplate before purchase.
Q2. Which processor does this model use? The processor has not been confirmed for this exact order number. The IPC547G family includes configurations with Intel Pentium, Core i5, Core i7, and Xeon processors.
Q3. What memory capacity is installed? The installed memory capacity and module arrangement are unconfirmed. Verify these details before planning a memory upgrade or replacement.
Q4. What storage options are available? IPC547G configurations were offered with internal HDDs, SSDs, and selected RAID arrangements. The supplied storage for this order number requires confirmation.
Q5. Which network interfaces does the platform support? Documented IPC547G configurations include two Intel Gigabit Ethernet interfaces. Confirm the motherboard configuration for the specific unit.
Q6. Which display connections are available? Depending on the motherboard and optional graphics hardware, the family supports DisplayPort and DVI-D display connections.
Q7. Does the IPC547G support expansion cards? Yes. Documented family configurations provide five PCI Express slots and two PCI slots. Check the available slots and electrical compatibility before installing additional hardware.
Q8. Is an operating system included? The operating-system status of the 6AG4104-4CA02-2BX1 has not been verified. Confirm whether the supplied unit includes an operating system and valid licensing.
Q9. What are the power requirements? Documented family configurations support 100–240 V AC, with redundant AC power options available on selected variants. The exact power-supply arrangement should be checked.
Q10. What information is required before ordering? Confirm the complete order number, processor, motherboard, memory, storage, operating system, enclosure, expansion hardware, and power cable. These specifications can vary between IPC547G configurations.
