Siemens 6AG4104-4CA02-3CX0 – SIMATIC IPC547G Industrial Rack PC
Siemens 6AG4104-4CA02-3CX0 – SIMATIC IPC547G Industrial Rack PC
0.0
Points
Brand:Siemens Item No.:6AG4104-4CA02-3CX0 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 356.6 mm Product Weight:23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens SIMATIC IPC547G is a rack-mounted industrial computer platform designed for industrial automation support, production data processing, machine monitoring, and system integration. Its 19-inch, 4U format allows installation in compatible industrial cabinets, while its expansion slots and network interfaces support integration with industrial peripherals.
The IPC547G family was available in multiple hardware configurations, including different Intel processors, memory capacities, storage devices, and operating-system options. These variations make it important to verify the complete order number when purchasing equipment for a specific application.
For 6AG4104-4CA02-3CX0, the exact configuration remains unverified. Buyers should confirm the hardware specification and supplied accessories against Siemens documentation or the equipment nameplate before placing an order.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Product family
SIMATIC IPC547G, exact variant unconfirmed
Order number
6AG4104-4CA02-3CX0
Product type
Industrial rack PC
Form factor
19-inch, 4U family design
Processor
Not verified
Motherboard / chipset
Not verified
Installed memory
Not verified
Storage
Not verified
Operating system
Not verified
Ethernet
Two Intel Gigabit Ethernet interfaces on documented family configurations
Front USB
Two USB 3.0 ports on documented family configurations
Rear USB
Configuration-dependent
Display interfaces
DisplayPort 1.2 and DVI-D on documented motherboard variants
Other interfaces
PS/2 and audio on documented family configurations
Expansion slots
Typically five PCI Express and two PCI
Hardware monitoring
Temperature and fan monitoring on documented family configurations
Watchdog
Available on documented family configurations
Power supply
100–240 V AC on documented configurations
Standard enclosure dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Short enclosure dimensions (W × H × D)
481.4 × 176.6 × 356.6 mm, where applicable
Weight
Approximately 15–23 kg across the family, depending on configuration
Dimensions, weight, and interface details are family-level information and have not been confirmed for the exact 3CX0 variant.
Recommended Related Models
The following documented IPC547G configurations provide useful alternatives for comparison. They are not confirmed direct replacements for the requested model.
Model
Configuration summary
6AG4104-4CA02-3XX0
Related IPC547G configuration listed with Intel Core i5-6500, 4 GB DDR4, 1 TB HDD, and an H110 motherboard.
6AG4104-4CA01-0XX1
Intel Core i5-6500, H110 motherboard, 4 GB DDR4, 1 TB HDD, DisplayPort, DVI-D, and no operating system.
6AG4104-4CA00-0BX2
Intel Core i5-6500, 4 GB DDR4, 1 TB HDD, short enclosure, and Windows 7 Ultimate.
6AG4104-4AA05-3XX0
Intel Pentium G4400, 4 GB DDR4, 1 TB HDD, dual Gigabit Ethernet, and no operating system.
6AG4104-4DA12-3BX2
Intel Core i7-6700, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 7 Ultimate.
Popular Related Models
Model
Product description
6AG4104-4CA04-0BX0
IPC547G with Intel Core i5-6500, 4 GB DDR4, 1 TB HDD, DVD±RW, and redundant dual AC power supplies.
6AG4104-4GA12-2DX1
IPC547G with Intel Core i5-6500, C236 motherboard, 8 GB DDR4, 1 TB HDD, DVD±RW, and a PCI Express dual-head graphics card.
6AG4104-4EN16-3XX0
IPC547G with Intel Pentium G4400, C236 motherboard, 8 GB DDR4, RAID 1 storage using two 1 TB HDDs, and no operating system.
6AG4104-4GN16-4BX0
IPC547G with Intel Core i5-6500, 8 GB RAM, RAID 1 storage, and Windows Server 2012 R2.
6AG4104-4GK13-1BX2
IPC547G with Intel Core i5-6500, C236 motherboard, 8 GB DDR4, a 480 GB SSD in a front-access drive bay, redundant AC power supplies, and Windows 7 Ultimate.
Applications
The Siemens 6AG4104-4CA02-3CX0 appears to be a variant of the SIMATIC IPC547G industrial rack PC, but I could not confirm the exact 3CX0 configuration in the available product records. The closely related model 6AG4104-4CA02-3XX0 is listed as an IPC547G with an Intel Core i5-6500 processor, 4 GB DDR4 memory, and a 1 TB HDD. These specifications should not automatically be attributed to the requested 3CX0 variant.
Typical applications of the IPC547G platform include:
Industrial Automation: Running compatible automation and industrial control software.
Machine Monitoring: Supporting equipment status visualization and diagnostic applications.
Production Data Processing: Collecting, processing, and storing manufacturing data.
HMI and Visualization: Hosting compatible operator-interface software and display applications.
Industrial System Integration: Connecting industrial networks, peripheral devices, and expansion cards.
Legacy System Maintenance: Supporting established installations built around the IPC547G platform.
Advantages
Rack-Mount Design: The IPC547G family uses a 19-inch, 4U enclosure for installation in compatible industrial racks.
Industrial Connectivity: Documented configurations include dual Gigabit Ethernet and multiple USB interfaces.
Expansion Flexibility: The platform offers seven expansion slots, typically five PCI Express and two PCI slots.
Hardware Monitoring: Documented family features include temperature and fan monitoring, a watchdog, and card-retention hardware.
Configurable Hardware: Different IPC547G variants were offered with different processors, memory capacities, storage arrangements, and operating systems.
Industrial Power Input: Documented configurations support 100–240 V AC.
Maintenance Suitability: The rack format and expansion options support integration into existing industrial systems.
Technical FAQs
Q1. What is the Siemens 6AG4104-4CA02-3CX0? The exact configuration has not been independently verified. The order number appears related to the SIMATIC IPC547G industrial rack PC family, but the complete product label should be checked before procurement.
Q2. Which processor is installed? The processor for the 3CX0 variant is unconfirmed. A closely related 3XX0 configuration uses an Intel Core i5-6500, but that specification should not be assumed to apply to this model.
Q3. What memory capacity does it have? The installed memory capacity is unverified for this exact order number. Check the original Siemens configuration record or physical unit.
Q4. What storage options are available? The IPC547G family includes configurations with internal HDDs, SSDs, and selected RAID arrangements. The storage supplied with this variant remains unconfirmed.
Q5. Which networking interfaces are supported? Documented IPC547G configurations include two Intel Gigabit Ethernet interfaces. Confirm the exact motherboard and port configuration for the unit.
Q6. Which display connections are available? Documented motherboard variants include DisplayPort 1.2 and DVI-D. The actual arrangement depends on the motherboard and any installed graphics card.
Q7. Can the system accommodate expansion cards? The documented IPC547G platform provides seven expansion slots, typically five PCI Express and two PCI slots. Verify available slots and compatibility before installation.
Q8. Does this model include a preinstalled operating system? The operating-system status of 6AG4104-4CA02-3CX0 has not been confirmed. Verify whether the supplied unit includes an operating system and a valid license.
Q9. What are the power requirements? Documented IPC547G configurations support 100–240 V AC. The specific power-supply arrangement and included cable should be confirmed.
Q10. What should buyers verify before ordering? Confirm the complete order number, processor, motherboard, memory, storage, operating system, enclosure, and power requirements. This is particularly important when sourcing a replacement for an existing industrial system.
