Siemens 6AG4104-4CA02-3CX2 – SIMATIC IPC547G Industrial Rack PC
Siemens 6AG4104-4CA02-3CX2 – SIMATIC IPC547G Industrial Rack PC
0.0
Points
Brand:Siemens Item No.: 6AG4104-4CA02-3CX2 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 356.6 mm Product Weight:23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens SIMATIC IPC547G is an industrial rack PC platform designed for automation support, production data processing, machine monitoring, and industrial system integration. Its 19-inch, 4U enclosure supports installation in compatible equipment racks and control cabinets.
Across the product family, configurations offer different Intel processors, DDR4 memory capacities, storage options, display interfaces, and operating systems. Expansion slots and hardware-monitoring features provide flexibility for industrial applications and legacy equipment maintenance.
For the specific order number 6AG4104-4CA02-3CX2, the exact hardware and software configuration remains unverified. Procurement teams should confirm the complete order number and original configuration documentation before using it as a replacement or specifying it for a new installation.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Product family
SIMATIC IPC547G
Order number
6AG4104-4CA02-3CX2
Product type
Industrial rack PC
Form factor
19-inch, 4U
Processor
Not verified for this exact order number
Motherboard / chipset
Not verified
Installed memory
Not verified
Storage
Not verified
Operating system
Not verified
Ethernet
Two Intel Gigabit Ethernet interfaces on documented family configurations
Front USB
Two USB 3.0 ports on documented family configurations
Rear USB
Configuration-dependent
Display interfaces
DisplayPort 1.2 and DVI-D on documented motherboard variants
Other interfaces
PS/2 and audio on documented family configurations
Expansion slots
Typically five PCI Express and two PCI
Hardware monitoring
Temperature and fan monitoring on documented family configurations
Watchdog
Available on documented family configurations
Power supply
100–240 V AC on documented configurations
Standard enclosure dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Short enclosure dimensions (W × H × D)
481.4 × 176.6 × 356.6 mm, where applicable
Weight
Approximately 15–23 kg across the family, depending on equipment
Dimensions, weight, and interface details are family-level specifications and have not been confirmed for the exact 3CX2 variant.
Recommended Related Models
The following documented SIMATIC IPC547G configurations can be used for comparison. They are not confirmed direct replacements for the requested order number.
Model
Configuration summary
6AG4104-4CA02-3XX0
Related IPC547G configuration with Intel Core i5-6500, H110 chipset, 4 GB DDR4, and 1 TB HDD.
6AG4104-4CA01-0XX1
Intel Core i5-6500, H110 motherboard, 4 GB DDR4, 1 TB HDD, DisplayPort, DVI-D, and no operating system.
6AG4104-4CA00-0BX2
Intel Core i5-6500, 4 GB DDR4, 1 TB HDD, short enclosure, and Windows 7 Ultimate.
6AG4104-4DA12-3BX2
Intel Core i7-6700, 8 GB DDR4, 1 TB HDD, DVD±RW, and Windows 7 Ultimate.
6AG4104-4GA12-2DX1
Intel Core i5-6500, C236 motherboard, 8 GB DDR4, 1 TB HDD, DVD±RW, and a PCI Express graphics card.
Popular Related Models
Model
Product description
6AG4104-4CA04-0BX0
IPC547G with Intel Core i5-6500, 4 GB DDR4, 1 TB HDD, DVD±RW, and redundant dual AC power supplies.
6AG4104-4EN16-3XX0
IPC547G with Intel Pentium G4400, C236 motherboard, 8 GB DDR4, RAID 1 storage using two 1 TB HDDs, and no operating system.
6AG4104-4GN16-4BX0
IPC547G with Intel Core i5-6500, 8 GB RAM, RAID 1 storage, and Windows Server 2012 R2.
6AG4104-4GK13-1BX2
IPC547G with Intel Core i5-6500, C236 motherboard, 8 GB DDR4, a 480 GB SSD in a front-access drive bay, redundant AC power supplies, and Windows 7 Ultimate.
6AG4104-4JR42-0XX2
IPC547G with Intel Xeon E3-1275 v5, C236 motherboard, 64 GB DDR4, RAID 1 storage, and a hot-spare drive.
Applications
The Siemens 6AG4104-4CA02-3CX2 could not be independently verified as an exact Siemens configuration. It appears to follow the SIMATIC IPC547G product-number pattern, but the closely related model 6AG4104-4CA02-3XX0 is a different order number and should not be treated as identical.
The following applications are representative of the SIMATIC IPC547G family:
Industrial Automation: Running compatible industrial control and automation applications.
Machine Monitoring: Supporting equipment-status visualization, diagnostics, and operational monitoring.
Production Data Processing: Collecting, processing, and storing manufacturing data.
HMI and Visualization: Hosting compatible operator-interface and process-visualization software.
Industrial System Integration: Connecting industrial networks, peripherals, and compatible expansion cards.
Legacy System Maintenance: Supporting existing installations built around the IPC547G platform.
Advantages
Industrial Rack-Mount Design: The IPC547G family uses a 19-inch, 4U enclosure suitable for compatible industrial cabinets.
Expansion Flexibility: Documented configurations provide seven expansion slots, typically five PCI Express and two PCI slots.
Network Connectivity: Two Intel Gigabit Ethernet interfaces are available on documented family configurations.
Hardware Monitoring: Supported family features include temperature and fan monitoring, a watchdog, and card-retention hardware.
Flexible Configuration Options: Different models within the family were offered with varying processors, memory, storage, and operating systems.
Industrial AC Power: Documented configurations support 100–240 V AC.
Maintenance-Oriented Platform: Rack mounting and expansion options help support integration into established industrial installations.
Technical FAQs
Q1. What is the Siemens 6AG4104-4CA02-3CX2? The exact configuration has not been confirmed in the available product records. It should be verified against the Siemens rating plate or original order documentation before purchase.
Q2. Which processor does this model use? The processor for the 3CX2 variant is unverified. A related IPC547G configuration, 6AG4104-4CA02-3XX0, uses an Intel Core i5-6500, but that specification should not be assumed to apply to this model.
Q3. How much memory is installed? The installed memory capacity and module arrangement remain unconfirmed for this exact order number.
Q4. What storage does the system provide? The IPC547G family includes configurations with internal hard disk drives, SSDs, and selected RAID arrangements. The storage supplied with this variant must be verified.
Q5. Which networking interfaces are available? Documented IPC547G configurations include two Intel Gigabit Ethernet interfaces. The precise motherboard configuration should be confirmed.
Q6. Which display interfaces does the platform support? Depending on the motherboard and graphics configuration, the family supports DisplayPort 1.2 and DVI-D. Exact port availability for this model remains unverified.
Q7. Can the IPC547G accommodate expansion cards? Documented family configurations provide seven expansion slots, typically five PCI Express and two PCI slots. Verify the installed hardware and available slots before adding cards.
Q8. Does this model include an operating system? The operating-system status of the 3CX2 variant has not been confirmed. Check the supplier's configuration details and software licensing.
Q9. What are the power requirements? Documented IPC547G configurations support 100–240 V AC. The exact power-supply arrangement and supplied power cable should be checked.
Q10. What should be verified before ordering? Confirm the full article number, processor, memory, storage, operating system, enclosure, expansion hardware, and power requirements. This is especially important when replacing a unit in an existing automation installation.
