The Siemens 6AG4104-4CH02-3XX0 is a SIMATIC IPC547G industrial rack PC configured around an Intel Core i5-6500 processor, 4 GB of DDR4 memory, and a 1 TB hard disk drive. Its 19-inch, 4U rack architecture is designed for industrial computing installations that need expansion flexibility and established network connectivity.
With dual Gigabit Ethernet, multiple expansion slots, onboard display interfaces, and integrated hardware monitoring, this configuration provides a practical foundation for manufacturing data processing, industrial visualization, and PC-based automation applications.
The system is supplied without a preinstalled operating system, allowing integrators to select compatible software for their intended application. For new installations and replacement projects, verify the complete order code and hardware configuration before purchase to ensure the selected system meets the project's performance, connectivity, and maintenance requirements.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Product Family
SIMATIC IPC547G
Order Number
6AG4104-4CH02-3XX0
Product Type
Industrial Rack PC
Processor
Intel Core i5-6500, 4 cores / 4 threads
Base / Turbo Frequency
3.2 GHz / up to 3.6 GHz
Cache
6 MB
Memory
4 GB DDR4-2133 SDRAM
Maximum Supported Memory
Up to 64 GB, subject to configuration
Storage
1 × 1 TB HDD
Optical Drive
Slimline DVD±RW
Chipset
Intel H110
Ethernet
2 × Intel Gigabit Ethernet
Display Interfaces
1 × DisplayPort 1.2, 1 × DVI-D
USB Interfaces
4 × USB 3.0, 4 × USB 2.0
Expansion Slots
5 × PCI Express, 2 × PCI
Power Supply
100–240 V AC, 50/60 Hz
Operating System
Not preinstalled
Form Factor
19-inch, 4U rack PC
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Weight
Approximately 17 kg; confirm against the supplied configuration
Recommended Companion Models Model Number
Product Name
6AG4104-4AA05-3XX0
Siemens SIMATIC IPC547G Industrial Rack PC, Pentium G4400, 4 GB RAM, 1 TB HDD
6AG4104-4GA22-0XX0
Siemens SIMATIC IPC547G Industrial Rack PC, Intel Core i7 Configuration
6AG4104-4CA12-1DX1
Siemens SIMATIC IPC547G Industrial Rack PC, Intel Core i5 Configuration
6AG4104-4DA12-3BX2
Siemens SIMATIC IPC547G Industrial Rack PC, Intel Core i7 Configuration
Frequently Selected Alternatives Model Number
Product Name
6AG4104-4DC22-0EX3
Siemens SIMATIC IPC547G Industrial Rack PC, Intel Core i7 Configuration
6AG4104-4DD20-2BX0
Siemens SIMATIC IPC547G Industrial Rack PC, Intel Core i7 Configuration
6AG4104-2AA02-0EX0
Siemens SIMATIC IPC547D Industrial Rack PC, Pentium Dual-Core G850
6AG4104-1DA14-1BX0
Siemens SIMATIC IPC547C Industrial Rack PC, Dual Gigabit Ethernet Configuration
Where It Excels in Industrial Use - Manufacturing Control and Supervision: Provides a centralized computing platform for production monitoring, industrial visualization, and supervisory applications that coordinate information from connected equipment.
- Production Data Processing: Supports manufacturing data collection, local processing, reporting, and exchange with compatible automation and information systems.
- Industrial Machine Integration: Accommodates compatible expansion cards for specialized interfaces, measurement systems, and machine-related applications.
- Quality Inspection and Monitoring: Can run suitable inspection and monitoring software for production environments where consistent data processing and integration with industrial equipment are important.
- Control Room and Rack Installations: Its 19-inch, 4U enclosure supports organized installation in industrial racks and appropriately ventilated control cabinets.
Key Strengths at a Glance - Intel Core i5 Processing: This configuration uses an Intel Core i5-6500 processor with four cores, four threads, a 3.2 GHz base frequency, and up to 3.6 GHz Turbo frequency.
- Integrated Storage Capacity: The specified configuration includes a 1 TB hard disk drive for operating data, application files, and industrial software.
- Expandable Industrial Architecture: Seven expansion slots provide five PCI Express slots and two PCI slots for compatible application-specific hardware.
- Dual Gigabit Ethernet: Two Intel Gigabit Ethernet interfaces support network integration and communication with compatible industrial equipment.
- Built-In System Monitoring: Temperature monitoring, fan monitoring, watchdog functionality, and card-retention features support routine system supervision and maintenance.
Technical FAQs Q1. Which processor is installed in the Siemens 6AG4104-4CH02-3XX0?
The specified configuration uses an Intel Core i5-6500 processor with four cores, four threads, a 3.2 GHz base frequency, up to 3.6 GHz Turbo frequency, and 6 MB cache.
Q2. How much memory does this configuration support?
The listed configuration includes 4 GB of DDR4-2133 SDRAM. The IPC547G platform supports memory expansion up to 64 GB, subject to motherboard compatibility and the supported memory configuration.
Q3. What storage device is supplied with this model?
This configuration includes one internal 1 TB hard disk drive. Storage expansion or replacement should be checked against the supported drive interfaces and mounting arrangements.
Q4. Which Ethernet interfaces are available?
The system provides two Intel Gigabit Ethernet interfaces using RJ45 connectors. These interfaces support standard Ethernet networking and can be used with compatible industrial communication software.
Q5. Can this IPC547G communicate with Siemens SIMATIC PLCs?
Yes. It can communicate with compatible SIMATIC controllers through supported Ethernet connections and appropriate software, drivers, and communication protocols. The exact setup depends on the PLC and application requirements.
Q6. Which display connections are supported?
The specified platform uses an H110 chipset configuration with onboard DisplayPort and DVI-D interfaces. Additional display outputs may be available through compatible expansion graphics hardware.
Q7. What expansion cards can be installed?
The system provides five PCI Express slots and two PCI slots. Card selection must account for slot characteristics, physical dimensions, power requirements, drivers, and compatibility with the installed operating system.
Q8. Does the system include hardware monitoring functions?
Yes. The IPC547G family includes temperature and fan monitoring, watchdog functionality, and card-retention features. These functions help support hardware supervision and routine maintenance.
Q9. Which operating system should be used?
The supplied configuration is specified without a preinstalled operating system. Select an operating system that supports the installed hardware and required industrial applications, and verify driver availability before deployment.
Q10. What should be checked before replacing an existing industrial PC with this model?
Confirm application compatibility, processor performance, memory requirements, storage capacity, display connections, expansion cards, network settings, operating-system licensing, and cabinet installation requirements before commissioning.
