Introduction The Siemens 6AG4104-4CH11-2BX3 is an order-number variant associated with the SIMATIC IPC547G industrial rack PC family. This platform is designed for industrial computing applications that require flexible expansion, network connectivity, and integration with established automation infrastructure.
With its rack-mounted architecture and support for compatible expansion hardware, the IPC547G family can serve as a foundation for production monitoring, industrial visualization, manufacturing data processing, and specialized machine applications. Integrated monitoring functions also help maintenance personnel supervise hardware conditions and plan routine servicing.
For system integrators and plant operators, the platform offers a practical way to consolidate computing tasks within an industrial installation. The exact processor, memory, storage arrangement, operating system, and power-supply configuration of the 6AG4104-4CH11-2BX3 should be verified against the complete order number before procurement or replacement.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Product Family
SIMATIC IPC547G
Model Number
6AG4104-4CH11-2BX3
Product Type
Industrial Rack PC
Form Factor
19-inch, 4U
Processor
Exact configuration requires order-code verification
Memory
Configuration-dependent
Storage
Configuration-dependent
Expansion Slots
5 × PCI Express, 2 × PCI
Ethernet Interfaces
2 × Intel Gigabit Ethernet
USB Connectivity
USB 3.0 and USB 2.0; port allocation depends on motherboard configuration
Display Interfaces
DisplayPort and DVI-D on supported motherboard configurations
Monitoring Functions
Temperature monitoring, fan monitoring, watchdog
Power Supply
100–240 V AC platform; exact supply configuration requires verification
Standard Dimensions (W × H × D)
430 × 177 × 446 mm
Short-Enclosure Depth
356 mm, where applicable
Weight
Approximately 17 kg for the standard IPC547G configuration
The dimensions and weight are reference specifications for the IPC547G family. Actual weight and configuration details can vary with the installed drives, expansion hardware, and power-supply arrangement. Confirm the specific unit before finalizing cabinet clearances or shipping requirements.
Recommended Related Models Model Number
Product Name
6AG4104-4DA11-0BX3
Siemens SIMATIC IPC547G Industrial Rack PC, Intel Core i7 Configuration
6AG4104-4GN11-2DX2
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, 8 GB RAM, RAID 1 Storage
6AG4104-4GN16-4BX0
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, 8 GB RAM, RAID 1 Storage, Windows 7 Ultimate
6AG4104-4CH11-1DX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500 Configuration
Popular Related Models Model Number
Product Name
6AG4104-4CA12-0DX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, 1 TB HDD
6AG4104-4CB10-0XX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, Dual 1 TB HDD Configuration
6AG4104-4CH01-5HX3
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, Removable 1 TB HDD Configuration
6AG4104-4DA12-0XX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700 Configuration
Where It Excels in Industrial Use - Industrial Automation and Supervision: Supports PC-based automation software, production monitoring, and supervisory applications that exchange data with compatible PLCs and industrial equipment.
- Manufacturing Data Processing: Provides a centralized computing platform for collecting production information, processing operational data, and supporting manufacturing reports.
- Industrial Visualization: Can run compatible HMI, SCADA, and operator dashboard applications to present equipment status and process information.
- Machine Integration: Expansion slots accommodate compatible interface cards and specialized hardware for machine monitoring, data acquisition, and industrial communication.
- Control Room Computing: The rack-mounted form factor suits centralized industrial installations where structured hardware deployment, service access, and system expansion are important.
Key Strengths at a Glance - Industrial Rack Architecture: The SIMATIC IPC547G family uses a 19-inch, 4U chassis designed for integration into industrial equipment racks.
- Flexible Expansion: Five PCI Express slots and two PCI slots support compatible communication, measurement, and application-specific cards.
- Integrated Hardware Monitoring: Temperature and fan monitoring, watchdog functionality, and system status indicators help maintenance teams supervise operation.
- Dual Gigabit Ethernet: Two Ethernet interfaces support connectivity with compatible controllers, industrial networks, and higher-level systems.
- Configuration-Specific Performance: Processor, memory, storage, and operating-system details depend on the exact order number and should be verified before deployment.
Technical FAQs Q1. What is the primary function of the Siemens 6AG4104-4CH11-2BX3?
This model belongs to the SIMATIC IPC547G industrial rack PC family, which is designed to run industrial software, manufacturing applications, production monitoring systems, and PC-based automation workloads.
Q2. How does the IPC547G communicate with Siemens SIMATIC PLCs?
Communication can be established through supported Ethernet interfaces and compatible Siemens engineering or runtime software. The required protocols and drivers depend on the connected PLC and application architecture.
Q3. Does the IPC547G support PROFINET communication?
PROFINET communication can be implemented when suitable software, drivers, and compatible interfaces are available. The required configuration depends on the intended communication role and automation system design.
Q4. Which expansion cards are compatible with the IPC547G?
The platform provides five PCI Express slots and two PCI slots. Each expansion card must meet the relevant electrical, physical, power, and operating-system compatibility requirements.
Q5. Can this industrial PC run HMI and SCADA software?
Yes. It can run compatible HMI and SCADA applications when the selected software supports the installed hardware and operating system. Application licensing and communication-driver requirements should be verified before deployment.
Q6. What diagnostic functions are available for system maintenance?
The IPC547G family includes temperature and fan monitoring, watchdog functionality, and system status indicators. These features support operational supervision and help identify certain hardware-related problems.
Q7. Can the IPC547G be used for industrial data acquisition?
Yes. Compatible acquisition cards, network interfaces, and software can collect, process, and transfer data from industrial instruments, controllers, and production equipment.
Q8. What should be considered when configuring industrial storage?
Storage selection should account for capacity, data access requirements, drive compatibility, and recovery objectives. RAID functionality depends on the installed controller and drive arrangement, and independent backups remain necessary.
Q9. How can the IPC547G be integrated into an existing factory network?
Integration generally requires configuring network addresses, installing compatible communication software, validating connectivity, and applying appropriate access controls to the connected automation and information systems.
Q10. Which factors help maintain stable long-term operation?
Adequate ventilation, regular inspection of cooling components, hardware-status monitoring, validated software updates, and tested backup procedures help support dependable operation in industrial environments.
