The Siemens 6AG4104-4CJ11-4BX3 is an order-number variant associated with the SIMATIC IPC547G industrial rack PC family. This platform is designed for industrial computing environments where flexible expansion, network connectivity, and integration with established automation systems are important.
Its rack-mounted architecture supports centralized deployment of manufacturing software, production monitoring tools, industrial visualization, and specialized computing applications. Expansion capabilities allow system integrators to adapt the platform to application-specific interface and data-processing requirements.
For plant operators and engineering teams, the IPC547G family offers a practical foundation for consolidating industrial computing functions. Before ordering or replacing equipment, confirm the exact processor, memory, storage, operating-system, and power-supply configuration associated with the complete model number.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Product Family
SIMATIC IPC547G
Model Number
6AG4104-4CJ11-4BX3
Product Type
Industrial Rack PC
Form Factor
19-inch, 4U
Processor
Exact configuration requires order-code verification
Memory
Configuration-dependent
Storage
Configuration-dependent
Expansion Slots
5 × PCI Express, 2 × PCI
Ethernet Interfaces
2 × Intel Gigabit Ethernet
Front USB Interfaces
2 × USB 3.0
Additional Connectivity
USB 2.0, display, PS/2, and audio interfaces, depending on motherboard configuration
Monitoring Functions
Temperature monitoring, fan monitoring, watchdog
Power Supply
100–240 V AC platform; exact supply configuration requires verification
Dimensions (W × H × D)
430 × 177 × 446 mm, standard enclosure
Short-Enclosure Dimensions (W × H × D)
430 × 177 × 356 mm, where applicable
Weight
Exact configuration weight requires confirmation; depends on installed hardware
The dimensions describe the standard IPC547G enclosure family. The exact weight and equipment configuration should be confirmed before planning cabinet installation, transportation, or replacement work.
Recommended Related Models Model Number
Product Name
6AG4104-4DA11-0BX3
Siemens SIMATIC IPC547G Industrial Rack PC, Intel Xeon E3-1275 v5 Configuration
6AG4104-4GN16-4BX0
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, 8 GB RAM, RAID 1 Storage
6AG4104-4CH01-5HX3
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, Removable 1 TB HDD Configuration
6AG4104-4CA12-0DX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, 1 TB HDD Configuration
Popular Related Models Model Number
Product Name
6AG4104-4CB10-0XX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, Dual 1 TB HDD Configuration
6AG4104-4DA12-0XX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700 Configuration
6AG4104-4DC22-0EX3
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7 Configuration with SSD Storage
6AG4104-5JD12-3BX0
Siemens SIMATIC IPC547J Industrial Rack PC, Industrial Computing Configuration
Applications - Factory Automation and Process Supervision: Provides an industrial computing platform for supervisory software, equipment monitoring, and production applications that exchange data with compatible PLCs and controllers.
- Manufacturing Data Processing: Supports local processing, collection, and organization of production information, helping integrate shop-floor equipment with higher-level manufacturing systems.
- Industrial HMI and SCADA: Can host compatible operator interfaces, visualization tools, and monitoring applications for centralized access to process information.
- Machine Integration and Inspection: Supports compatible PCI Express and PCI expansion cards for industrial communication, measurement, machine monitoring, and specialized inspection tasks.
- Control Room Computing: The rack-mounted architecture suits centralized industrial installations that require organized equipment integration, convenient servicing, and expansion flexibility.
Advantages - Space-Efficient Rack Design: The SIMATIC IPC547G family uses a 19-inch, 4U enclosure for integration into suitable industrial racks and control cabinets.
- Flexible Expansion Options: Five PCI Express slots and two PCI slots accommodate compatible communication cards, data-acquisition hardware, and application-specific peripherals.
- Integrated Hardware Monitoring: Temperature and fan monitoring, watchdog functionality, and status indicators support system supervision and routine maintenance.
- Industrial Network Connectivity: Dual Gigabit Ethernet interfaces enable communication with compatible controllers, industrial devices, and supervisory systems.
- Configurable Computing Platform: The IPC547G range offers multiple hardware configurations, allowing integrators to match processing, storage, and connectivity requirements to the intended application.
Technical FAQs Q1. What is the main purpose of the Siemens 6AG4104-4CJ11-4BX3?
It is identified by an order number in the SIMATIC IPC547G industrial rack PC family. The platform is intended for industrial software, production monitoring, data processing, and PC-based automation applications. The exact hardware configuration should be confirmed for this specific variant.
Q2. How does the IPC547G communicate with industrial controllers?
It supports Ethernet connectivity and compatible communication software. Protocols, drivers, and network settings must be selected according to the connected controller and the application's requirements.
Q3. Can the IPC547G communicate with Siemens SIMATIC PLCs?
Yes. It can exchange data with compatible SIMATIC PLCs through supported network interfaces and suitable engineering or runtime software. The specific communication capabilities depend on the installed software and system configuration.
Q4. Does the IPC547G support PROFINET?
PROFINET communication can be implemented when suitable software, drivers, and compatible interfaces are available. The required configuration depends on the intended communication role and automation architecture.
Q5. Which expansion cards can be installed?
The IPC547G platform provides five PCI Express slots and two PCI slots. Individual cards must meet the appropriate electrical, physical, power, driver, and operating-system requirements.
Q6. Can the system run HMI and SCADA applications?
Yes. Compatible HMI, SCADA, and supervisory software can run on the system when its hardware and operating system satisfy the application's requirements. Software licensing and communication-driver compatibility should be checked before deployment.
Q7. What diagnostic functions are available?
The IPC547G family includes temperature and fan monitoring, watchdog functionality, and system status indicators. These features help maintenance personnel monitor operating conditions and troubleshoot certain hardware issues.
Q8. What should be considered when selecting a storage configuration?
Storage selection should account for capacity, performance, drive interfaces, data retention, and recovery requirements. RAID availability depends on the installed controller and drive arrangement, and independent backups remain essential.
Q9. How can the IPC547G be integrated into an existing factory network?
Integration typically involves configuring network addresses, installing the appropriate communication software, validating data exchange, and applying suitable access controls to connected automation systems.
Q10. Which maintenance practices help support reliable operation?
Maintain adequate ventilation, inspect cooling components, monitor system diagnostics, apply validated software updates, and periodically test backup and recovery procedures. Maintenance schedules should reflect the installation environment and workload.
