Introduction The Siemens 6AG4104-4CK21-0DX3 is an order-number variant associated with the SIMATIC IPC547G industrial rack PC family. Designed for industrial computing environments, the platform combines a rack-mounted architecture with flexible expansion options and network connectivity for integration into automation infrastructure.
The IPC547G family can support manufacturing data processing, industrial visualization, equipment monitoring, and specialized machine applications. Its expansion capabilities make it adaptable to projects requiring additional communication interfaces or application-specific hardware.
For industrial system integrators, the platform provides a practical foundation for consolidating computing functions within a rack-based installation. Before purchasing this particular variant, confirm the exact processor, memory, storage devices, operating-system configuration, and power-supply arrangement against the complete order number.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Product Family
SIMATIC IPC547G
Model Number
6AG4104-4CK21-0DX3
Product Type
Industrial Rack PC
Form Factor
19-inch, 4U
Processor
Exact configuration requires order-code verification
Memory
Configuration-dependent
Storage
Configuration-dependent
Expansion Slots
5 × PCI Express, 2 × PCI
Ethernet Interfaces
2 × Gigabit Ethernet
USB Connectivity
USB 3.0 and USB 2.0, depending on motherboard configuration
Display Interfaces
DisplayPort and DVI-D on supported configurations
Monitoring Functions
Temperature monitoring, fan monitoring, watchdog
Power Supply
100–240 V AC platform; exact configuration requires verification
Dimensions (W × H × D)
Approximately 481.4 × 176.6 × 446.6 mm
Weight
Approximately 17 kg; exact configuration requires verification
Dimensions and weight are reference values for the IPC547G family rather than independently confirmed measurements for this exact order number. Verify the installed enclosure, storage configuration, and power supply before finalizing installation or shipping arrangements.
Recommended Related Models Model Number
Product Name
6AG4104-4CA12-0DX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, 1 TB HDD
6AG4104-4CB10-0XX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, Dual 1 TB HDD
6AG4104-4DC12-0XX3
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 240 GB SSD
6AG4104-4DD12-0BX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 480 GB SSD
Popular Related Models Model Number
Product Name
6AG4104-4EA00-0XX0
Siemens SIMATIC IPC547G Industrial Rack PC, Pentium G4400, C236 Chipset
6AG4104-4GC21-3DX2
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, Intel AMT Support
6AG4104-4GN16-4BX0
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, RAID 1 Storage
6AG4104-4HA01-0XX3
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, Intel AMT Support
Applications - Industrial Automation: Supports PC-based automation software, supervisory applications, and communication with compatible PLCs and industrial controllers.
- Production Monitoring: Provides a platform for collecting operational data, monitoring equipment status, and displaying manufacturing information in centralized control environments.
- Manufacturing Information Processing: Handles production records, local data processing, and communication between shop-floor equipment and higher-level information systems.
- Machine Integration: Supports compatible expansion hardware for specialized interfaces, measurement equipment, and industrial data-acquisition applications.
- Industrial Visualization: Can run compatible HMI and SCADA software to help operators access process information and coordinate routine production activities.
Advantages - Industrial Rack Design: The SIMATIC IPC547G family uses a 19-inch, 4U chassis suitable for industrial rack installations and compatible control cabinets.
- Expansion Flexibility: Five PCI Express slots and two PCI slots provide options for integrating compatible communication cards, measurement hardware, and application-specific peripherals.
- Integrated Monitoring: Temperature and fan monitoring, watchdog functionality, and system status indicators help support maintenance and equipment supervision.
- Network Connectivity: Dual Gigabit Ethernet interfaces support integration with compatible industrial networks, controllers, and supervisory systems.
- Configurable Platform: The IPC547G family offers several processor, memory, and storage combinations. Confirming the exact order-code configuration helps ensure the selected system meets application requirements.
Technical FAQs Q1. What is the main function of the Siemens 6AG4104-4CK21-0DX3?
It belongs to the SIMATIC IPC547G industrial rack PC series, designed for industrial computing, production monitoring, and PC-based automation. The exact processor and hardware configuration should be verified for this specific order number.
Q2. Which communication protocols can the IPC547G support?
The system can support industrial communication protocols through compatible Ethernet interfaces, drivers, and application software. Protocol availability depends on the installed software and the connected automation equipment.
Q3. Can this industrial PC communicate with Siemens SIMATIC PLCs?
Yes. Compatible SIMATIC PLCs can exchange data with the IPC547G through supported network interfaces and suitable engineering or runtime software.
Q4. Does the IPC547G support PROFINET applications?
PROFINET communication is possible with compatible software and interface configurations. The required components depend on whether the PC is used for engineering, supervisory monitoring, or a specialized communication role.
Q5. Which expansion cards can be installed?
The IPC547G platform provides five PCI Express slots and two PCI slots. Expansion cards must meet the system's electrical, physical, power, and driver compatibility requirements.
Q6. Can the IPC547G run HMI and SCADA software?
Yes. It can run compatible HMI, SCADA, and industrial visualization applications when the hardware and operating system meet the software requirements.
Q7. What hardware monitoring functions are available?
The IPC547G family includes temperature and fan monitoring, watchdog functionality, and system status indicators. These features assist with troubleshooting and routine maintenance.
Q8. Can the system support RAID storage configurations?
Selected IPC547G configurations support RAID arrangements. The available RAID levels depend on the storage controller, installed drives, and system configuration.
Q9. Which operating system should be selected?
The operating system should be chosen according to application compatibility, hardware driver availability, security requirements, and software licensing. Confirm support for the exact installed hardware before deployment.
Q10. What should be checked before commissioning the system?
Verify the hardware configuration, BIOS settings, operating system, communication drivers, network parameters, expansion-card compatibility, and application licenses. Functional testing should be completed before connecting the PC to production equipment.
