Introduction The Siemens 6AG4104-4DA02-0XX3 belongs to the SIMATIC IPC547G industrial rack PC family, developed for industrial computing applications that require flexible connectivity and integration with existing automation infrastructure.
Its rack-mounted architecture supports centralized deployment of industrial visualization, manufacturing data processing, equipment monitoring, and specialized computing software. The available expansion slots allow compatible communication and measurement hardware to be incorporated into application-specific installations.
For industrial operators and system integrators, the IPC547G provides a configurable platform for consolidating computing tasks in a structured rack environment. Before procurement, confirm the exact processor, memory, storage, operating-system, and power-supply configuration of this order number to ensure compatibility with the intended application.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Product Family
SIMATIC IPC547G
Model Number
6AG4104-4DA02-0XX3
Product Type
Industrial Rack PC
Form Factor
19-inch, 4U
Processor
Exact configuration requires order-code verification
Memory
DDR4-2133 SDRAM; installed capacity requires verification
Storage
Exact drive configuration requires verification
Chipset
Exact motherboard configuration requires verification
Ethernet Interfaces
2 × Intel Gigabit Ethernet
USB Interfaces
USB 3.0 and USB 2.0, depending on motherboard configuration
Display Interfaces
DisplayPort and DVI-D on supported configurations
Expansion Slots
5 × PCI Express, 2 × PCI
Monitoring Functions
Temperature monitoring, fan monitoring, watchdog
Power Supply
100–240 V AC platform; exact configuration requires verification
Dimensions (W × H × D)
430 × 177 × 446 mm
Short-Enclosure Dimensions (W × H × D)
430 × 177 × 356 mm, where applicable
Weight
Approximately 17 kg; exact configuration requires verification
Dimensions and weight are reference values for the SIMATIC IPC547G enclosure family. The exact hardware configuration and net weight should be confirmed before ordering, installation, or replacement.
Recommended Related Models Model Number
Product Name
6AG4104-4DA01-0BX0
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 4 GB RAM, 1 TB HDD, Windows 7 Ultimate
6AG4104-4DA11-0BX3
Siemens SIMATIC IPC547G Industrial Rack PC, Xeon E3-1275 v5 Configuration
6AG4104-4DA12-2EX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 8 GB RAM, 1 TB HDD, Windows 10 Enterprise 2016 LTSB
6AG4104-4GA22-0XX0
Siemens SIMATIC IPC547G Industrial Rack PC, Intel Core i7 Configuration
Popular Related Models Model Number
Product Name
6AG4104-4CA12-0DX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5 Configuration
6AG4104-4CB10-0XX1
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5 Configuration with Dual HDD Storage
6AG4104-4DD01-0XX3
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7-6700, 480 GB SSD
6AG4104-4GN16-4BX0
Siemens SIMATIC IPC547G Industrial Rack PC, Core i5-6500, RAID 1 Storage
Applications - Industrial Automation and Process Control: Supports compatible automation software, supervisory applications, and communication with PLCs and industrial controllers in manufacturing environments.
- Production Data Management: Provides a centralized computing platform for collecting production data, processing operational information, and supporting manufacturing reports.
- HMI and SCADA Integration: Runs compatible industrial visualization software to help operators monitor equipment status, review process information, and coordinate production activities.
- Machine Integration and Data Acquisition: Supports compatible expansion cards for specialized interfaces, industrial measurement, and machine-monitoring applications.
- Industrial Control Room Operations: The rack-mounted design suits centralized computing installations where structured hardware deployment and convenient maintenance are essential.
Advantages - Intel Core i7 Computing Platform: The SIMATIC IPC547G family supports Intel Core i7-6700 configurations, offering four cores, eight threads, and a maximum Turbo frequency of 4.0 GHz.
- Flexible Hardware Expansion: Five PCI Express slots and two PCI slots provide options for compatible communication cards, measurement devices, and application-specific peripherals.
- Reliable Network Integration: Dual Intel Gigabit Ethernet interfaces support communication with compatible automation equipment and industrial networks.
- Integrated Diagnostic Functions: Temperature and fan monitoring, watchdog functionality, and system status indicators help maintenance teams identify potential hardware issues.
- Configurable Storage and Software: The IPC547G platform supports different storage and operating-system configurations, allowing system integrators to select a setup appropriate for the intended industrial workload.
Technical FAQs Q1. What is the primary function of the Siemens 6AG4104-4DA02-0XX3?
It is an order-number variant associated with the SIMATIC IPC547G industrial rack PC family. The platform is designed for industrial computing, manufacturing data processing, visualization, and automation-related applications.
Q2. Which processor is installed in this model?
The IPC547G family includes Intel Core i7-6700 configurations. The exact processor installed in the 6AG4104-4DA02-0XX3 should be confirmed against its complete product configuration.
Q3. Which memory technology does the IPC547G support?
The platform supports DDR4-2133 SDRAM, with memory configurations ranging from 4 GB to 64 GB. The installed capacity depends on the specific hardware variant.
Q4. Can the system communicate with Siemens SIMATIC PLCs?
Yes. Compatible SIMATIC PLCs can exchange data with the PC through supported Ethernet interfaces and suitable engineering or runtime software.
Q5. Does the IPC547G support PROFINET?
PROFINET communication can be implemented with compatible software and interfaces. The appropriate configuration depends on the controller, communication role, and automation architecture.
Q6. Which expansion cards are supported?
The platform provides five PCI Express slots and two PCI slots. Each card must satisfy the system's interface, electrical, physical, power, and driver compatibility requirements.
Q7. Which network interfaces are available?
The IPC547G family provides two Intel Gigabit Ethernet interfaces with RJ45 connectors. These support communication with compatible industrial networks, controllers, and supervisory systems.
Q8. Can the system use RAID storage?
Selected configurations support RAID arrangements using compatible storage controllers and drives. The available RAID levels depend on the installed hardware and configuration.
Q9. What diagnostic features are available for maintenance?
Temperature and fan monitoring, watchdog functionality, and system status indicators help maintenance personnel supervise hardware operation and investigate certain system faults.
Q10. What should be checked before commissioning the IPC547G?
Confirm processor and memory configuration, storage compatibility, operating-system support, expansion-card requirements, communication drivers, network settings, and application licensing before integrating the PC into a production environment.
